Excellent Modular Component Placer EXCEN Series EXCEN PRO(M)/(D)/(L) Technical Reference - 第250页
Page +$1:+$ 244 EXCEN PRO(M) EXCEN PRO(D ) EXCEN PRO(L) Base Frame (1/2) 1 23 3 4 6 21 15 16 9 10 11 12 2 1 2 7 8 14 18 17 17 17 22 15 5
Page
+$1:+$
243
Y Frame - EXCEN PRO(D)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 MC13-001095 LM GUIDE-SHS25V2SSC1E+2066LH-II;.,. 4
2 EP08-001003 MOTOR,ELECTRIC-LINEAR MOTOR MAGNET;CDM30 8
3 FC28-001065 LINEAR SCALE UNIT-ST708A-1600A-R 2
4 FC30-000968A PLATE-Y_STOPPER_PLATE 2
5 FC07-003630A BLOCK-MTED-Y004A_STOPPER_BLOCK 2
6 RM01-003743A BAR-MTED-Y002A_STOPPER_HEX_BAR;AL6061 4
7 FC36-001062A SHEET-MTED-Y003A_SHEET 2
8 FC30-004787A PLATE-MTED-Y001A_CABLEVEYOR_GUIDE 2
9 FC09-007421A BRACKET-MTED-Y005A_E_REGULATOR_BKT 2
10 FC30-004788A PLATE-MTED-Y006A_GUIDE_SUPPORT1 1
11 MC08-001014 CHAIN-TKR0200W50R55(55L+PIK+PKA) 2
Page
+$1:+$
244
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Base Frame (1/2)
1
23
3
4
6
21
15
16
9
10
11
12
2
1
2
7
8
14
18
17
17
17
22
15
5
Page
+$1:+$
245
Base Frame (1/2)
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Reference
1 EP06-900166 KOLLMORGEN_DRIVER S20360-SRS (X_AXIS) 2
2 EP06-900156 KOLLMORGEN_DRIVER S20660-SRS (Y_AXIS) 2
3 FC09-002000A BRACKET-AMP_BOARD_BKT 1
4 AM03-006209A ASSY,BOARD-FIBER AMP CONNECTOR BOARD AS 4
5 AM03-006531D ASSY,ELECTRIC-V1P CPU BOX_ASSY 1 AM03-006531A / AM03-006531B
EP06-901050 POWER SUPPLY 1 PCSF-350P-X2S1
AM03-017615C ASSY,BOARD-NCIO BOARD ASSY 1 AM03-017615A / AM03-017615B
AM03-014332B CABLE ASSY-CPU-BOX 12V POWER 1
6 AM03-009557F ASSY,ELECTRIC-SMALL SILL BOX ASSY 1 AM03-009557B/ AM03-009557C/ AM03-009557D/ AM03-009557E
EP06-001062 SUPPLY,POWER,AC-ACDC-PLA100F-24;24,4.3,2 1 EP06-000041
7 AM03-007786A CABLE ASSY-V1+ NOISE FILTER ASSY 1
8 FC09-004218A BRACKET-MTV1PP-FR103A-BUT_DRIVER_BKT 1 FC09-002032A/ FC09-002037A
9 EP06-001010 BUT_DRIVER 4 EP06-000460/ EP06-000474/ EP06-000477/ EP06-001001
10 AM03-012037A ASSY,BOARD-G7SA-2A2B RELAY BOARD 4 EP18-000006/ EP18-000007
11 EP23-000014 TRANSFORMER,POWER-3phase5.7KVA(JI993) 1
12 HP11-000059 PUMP-PUMP KHA400A-301-G1 1
13 AM03-009556F ASSY,BOARD-SILL PCB BOARD ASSY 1 AM03-009556B/ AM03-009556C/ AM03-009556D/ AM03-009556E
14 AM03-001692A ASSY,ETC,IMS-V RT BOARD ASSY 1
15 ASSY ASSY,ETC,IMS-MMI VISION BOARD ASSY 1
FC32-001001 PROTECTOR,HEAT-EXPRESS CB_HEATSINK(ALKO) 1 FC32-000001
CD05-000015 MOTHERBOARD,CPU-Express-CB;embedded 1
AM03-014828B ASSY,BOARD-COMX-ACL VER1.0C 1
EP10-003331 MEMORY-TS256MS64V1N DDR3;2GB 1 EP10-002577
CD03-000060 HARD DRIVE-TS64GSSD630 1
16 ASSY ASSY,ETC,IMS-V RT BOARD ASSY 1
EP10-000055 MEMORY-CF Card - 8G;8G,ET1:ETC 1
AM03-000046 ASSY,ETC,IMS-MEN CPU BOARD 6U PANEL 1
EP10-900133 F14_3U_CPCI_BOARD 02F014_01 1
17 EP06-000211 BOARD,COMMUNICATION-ZMP;400MHz 3
18 CD05-000050 MODULE,MEMORY-MZ-7TD120Z;SSD,540BPS 1
