2.
LOAD WIRING DIAGRAM
負荷配線図
2-3 SINGLE CONVEYOR UNIT
シングルコンベアユニット
EJM9DB-10-203-00
-M610
M1_K323
-M611 L1 Left Transfer Motor (Moving Side)
M
M
M2_K323
-M629 L1 Width Adjustment Axis Motor
M9_K323
M
B4_K323
-B121R L1 Support Pin Detection (Receiver)
-B121T
L1 Support Pin Detection (Projector)
B5_K323
-B123 L1 Width Adjustment Axis Single Mode ORG Detection
B1_K323
-B1020 L1 Left Side PCB Detection 1
-B1021 L1 Left Side PCB Detection 2
-B1022 L1 Mount Position #2 PCB Detection 4
-B1023 L1 Mount Position #2 PCB Detection 5
-K323
B3_K323
L1 Left Transfer Motor (Fixed Side)
PDG14040A
M3_K323
M4_K323
-M612 L1 Mount Position #2 Transfer Motor (Fixed Side)
M
M
-M613 L1 Mount Position #2 Transfer Motor (Moving Side)
Single Conveyor (Rear Reference)
Single Conveyor (Front Reference)
CN Board
:Transfer #1(Front)
-M613
M1_K323
-M612 L1 Mount Position #2 Transfer Motor (Moving Side)
M
M
M2_K323
B2_K323
-B1020 L1 Left Side PCB Detection 1
-B1021 L1 Left Side PCB Detection 2
-K323
B3_K323
L1 Mount Position #2 Transfer Motor (Fixed Side)
PDG14040A
M3_K323
M4_K323
-M611 L1 Left Transfer Motor (Fixed Side)
M
M
-M610 L1 Left Transfer Motor (Moving Side)
CN Board
:Transfer #1(Front)
-B1030 L1 Mount Position #1 PCB Detection 1
-B1031 L1 Mount Position #1 PCB Detection 2
-B1030 L1 Mount Position #1 PCB Detection 1
-B1031 L1 Mount Position #1 PCB Detection 2
1
1
1
1
1
Panasonic Smart Factory Solutions Co.,Ltd. パナソニック スマートファクトリーソリューションズ株式会社
Name
Drawing No.
Loc. No.
F4K1020-05A
1 2 3 4 5 6 7 8
A
B
C
D
E
F
1 2 3 4 5 6 7 8
A
B
C
D
E
F
Page. No.
Single Conveyor Unit (NPM-WX)
(Block Diagram 1)
MTKA012759+002AC
P002
