YSM40_PartList - 第20页
6 3 Reel Holder Feeder Holder KLF-1307 21 21 21 21 23 24 7 20 3 3 3 3 26 21 25 1 3 12 5 5 5 26 25 21 4 2 4 10 13 16 16 16 16 14 5 5 1 1 17 17 22 22 18 18 9 8 15 1 1 14 14 21 21 21 24 23 6 20 19 13 12 5 5 10 10 19 3 OLD O…
5
3
Cover FES46 Base / Sensor
Feeder Holder
KLF-1307
17
9
20
24
7
26
1
21
18
17
17
10
10
29
18
17
8
21
26
27
7
24
20
22
13
29
13
27
12
28
28
15
15
5
2
2
19
16
19
16
1
3
3
23
5
23
25
25
4
4
6
6
11
14
14
21
21
22
OLD
12
11
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M374K-00 PLUNGER 2 OK MK10033-2013/1/21
KLF-M3747-00 PLUNGER 2
2 KLF-M3748-00 WASHER 4
3 KLF-M374A-00 BASE,CLAMP 2
4 KLF-M374B-00 LEVER,CLAMP 2
5 KLF-M374C-00 SPRING,CLAMP 2
6 KLF-M374F-00 STOPPER,ARM 2
7 KLF-M374L-00 BRKT.,SENSOR 2
8 KLF-M374U-00 COVER,SENSOR R 1
9 KLF-M374U-50 COVER,SENSOR L 1
10 KLF-M374V-00 COVER,HNS. 2
11
KLF-M374Y-01 BASE,ARM R 1 Damper position movement NG MK10033-2013/1/21
KLF-M374Y-00 BASE,ARM R 1
12
KLF-M374Y-51 BASE,ARM L 1 Damper position movement NG MK10033-2013/1/21
KLF-M374Y-50 BASE,ARM L 1
13 KLF-M652W-00 SENSOR COVER DI ASSY 2
14 KHJ-MC10S-01 PIN,LOCATE 1 2
15 KHJ-MC289-00 PIN,CLAMP 2
16 90440-01J030 CIRCLIP(E) 2
17 90990-10J008 SCREW,BINDING HEAD 8
18
Delete MK30146-2013/3/27
90990-11J001 SCREW PAN HEAD W/W 4
19 90990-28J038 WASHER,PLAIN 2
20 91312-03004 BOLT HEX.SOCKET HEAD 4 M3X4
21 91312-04005 BOLT HEX.SOCKET HEAD 8 M4X5
22 91312-06012 BOLT HEX.SOCKET HEAD 6 M6X12
23 91609-25008 PIN,SPRING 2
24 92902-03600 WASHER PLAIN 4
25 92A08-03303 SET SCREW M3X3 2
26 95302-06600 NUT HEXAGON 2
27 97602-03310 SCREW,PAN HEAD W/W 2
28 99480-04014 PIN,PARALLEL 2
29
Delete MK30146-2013/3/27
$NK-3N NYLON CLIP 4
6
3
Reel Holder
Feeder Holder
KLF-1307
21
21
21
21
23
24
7
20
3
3
3
3
26
21
25
1
3
12
5
5
5
26
25
21
4
2
4
10
13
16
16
16
16
14
5
5
11
17
17
22
22
18
18
9
8
15
11
14
14
21
21
21
24
23
6
20
19
13
12
5
5
10
10
19
3
OLD
OLD
6
7
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M3R03-00 BRKT.,REEL HOLDER R 1
2 KLF-M3R04-00 BRKT.,REEL HOLDER L 1
3 KLF-M3R09-00 SHAFT,ROLLER 6
4 KLF-M3R12-00 COLLAR 2
5 KHY-M3R15-00 ROLLER 100
6
KLF-M3R01-02 PLATE,SIDE R 1 NG MJ90079-2012/12/13
KLF-M3R01-01 PLATE,SIDE R 1
7
KLF-M3R02-02 PLATE,SIDE L 1 NG MJ90079-2012/12/13
KLF-M3R02-01 PLATE,SIDE L 1
8 KLF-M3R05-00 GUIDE,PATITION 1
9 KLF-M3R08-00 COVER,UNDER 1
10 KLF-M3R10-01 REEL HOLDER 23
11 KLF-M3R13-00 COLLAR 2
12 KLF-M3R14-00 COLLAR 2
13 KHY-M3R14-11 WASHER 22
14 KHY-M3R16-00 PARTITION 11
15 KHY-M3R22-00 GUIDE,PARTITION 5
16 KHY-M3R23-00 COLLAR,PARTITION 23
17 91312-03004 BOLT HEX.SOCKET HEAD 6 M3X4
18 91312-03012 BOLT,HEX.SOCKET HEAD 11 M3X12
19 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
20 91312-05008 BOLT HEX.SOCKET HEAD 4 M5X8
21 92012-06010 BOLT,BUTTON HEAD 12
22 92902-03200 WASHER PLAIN 6
23 92902-04200 WASHER PLAIN 4
24 92902-05200 WASHER PLAIN 4
25 92902-06600 WASHER PLAIN 12
26 90990-46J006 BOLT,THIN HEAD 8
7
3
Carriage FES46
Feeder Holder
KLF-1307
33
33
43
43
43
3
33
31
44
1
47
49
52
32
48
24
40
40
40
40
40
40
50
21
47
42
30
9
39
39
32
48
8
24
18
11
5
38
27
9
42
21
30
47
49
29
33
33
43
43
43
44
31
34
12
51
33
4
47
40
45
45
45
45
45
22
19
20
45
45
36
36
36
36
40
40
40
41
46
41
46
41
46
41
46
14
15
15
16
16
17
13
37
35
45
45
36
36
23
36
36
50
52
40
2
36
8
34
12
28
26
38
10
18
6
53
53
33
33
25
7
25
5
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M3721-00 FRAME,L 1
2 KLF-M3721-50 FRAME,R 1
3 KLF-M3722-00 PANEL,CART L 1
4 KLF-M3722-50 PANEL,CART R 1
5 KLF-M3723-00 SPACER,ARM 2
6 KLF-M3724-00 COVER,CART L 1
7 KLF-M3724-50 COVER,CART R 1
8 KLF-M3725-00 PLATE,CAM 2
9 KLF-M3726-00 TAPE 4
10 KLF-M3727-00 ARM,SUB L 1
11 KLF-M3727-50 ARM,SUB R 1
12 KLF-M3728-00 PULL 2
13 KLF-M3729-A0 BASE,SUB ASSY. 1
14
KLF-M3729-01 BASE 1 OK MJ80071-2012/8/10
KLF-M3729-00 BASE 1
15 KLF-M372A-00 CASTER 2
16 KLF-M372B-00 CASTER 2
17 KLF-M372C-00 CHAIN 1
18 KLF-M372D-00 STEP SCREW 2
19 KLF-M372E-00 RIB,L 1
20 KLF-M372E-50 RIB,R 1
21 KLF-M372G-00 CAM FOLLOWER 4
22 KLF-M372H-00 RIB,L 2 1
23 KLF-M372H-50 RIB,R 2 1
24 KLF-M372J-00 BRACKET,BOLT 2
25 KLF-M372K-00 COVER,ADJUST 2
26 KLF-M372M-00 COVER,SUB ARM L 1
27 KLF-M372M-50 COVER,SUB ARM R 1
28 KLF-M372N-00 BRACKET,FIX L 1
29 KLF-M372N-50 BRACKET,FIX R 1
30 KKU-M1138-00 CAM FOLLOWER 4
31 KL3-M1348-10 GAS SPRING 2
32 90990-01J073 BOLT,HEX.SOCKET HEAD 2
33
90990-12J001 SCREW BIN.HEAD W/W 32 OK KJ90041-2012/9/7
90990-12J001 SCREW BIN.HEAD W/W 40
34 90990-41J047 COLLAR 2
35 90172-00J040 WASHER,EXTL.TOOTHED 1
36 90172-00J060 WASHER,EXTL.TOOTHED 22
37 91312-04006 BOLT HEX.SOCKET HEAD 1 M4X6
38 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
39 91312-06010 BOLT HEX.SOCKET HEAD 4 M6X10
40 91312-06012 BOLT HEX.SOCKET HEAD 30 M6X12
41 91312-08008 BOLT HEX.SOCKET HEAD 16 M8X8
42 91312-08012 BOLT HEX.SOCKET HEAD 12 M8X12
43 91312-08016 BOLT HEX.SOCKET HEAD 6 M8X16
44 91312-08025 BOLT HEX.SOCKET HEAD 2 M8X25
45 92902-06200 WASHER PLAIN 22
46 92902-08200 WASHER,PLAIN 16
47 95602-08100 NUT U 8
48 95302-08700 NUT HEXAGON 2
49 99480-04014 PIN,PARALLEL 4
50 99480-06012 PIN,PARALLEL 4
51 KLF-M373A-00 LABEL,BARCODE 1
52 KW3-M925L-00 LABEL,CONV. 1
53 92012-04006 BOLT, BUTTON HEAD 8 OK KJ90041-2012/9/7
