YSM40_PartList - 第23页
9 3 Clamp FES46 ARM / Cam Follower Feeder Holder KLF-1307 9 9 9 7 3 13 10 8 22 18 14 14 17 25 4 23 1 1 1 1 26 25 19 23 21 15 6 5 1 17 9 7 24 24 12 16 12 16 20 20 15 15 18 18 8 18 19 23 25 26 15 1 15 21 22 10 25 23 14 14 …
8
3
Clamp FES46 Cylinder / Guide
Feeder Holder
KLF-1307
16
1
16
2
23
23
19
20
35
27
27
9 7
7
26
26
27
27
27
3
3
3
3
36
36
18
16
16
30
30
15
23
29
22
8
33
4
4
28
17
25
12
5
5
2
32
24
24
24
9
23
29
14
10
21
6
4
17
25
33
1
4
11
28
24
13
34
31
13
34
31
19
20
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M3772-01
PLATE,BASE L 1
NG
MK30019-2013/3/13
KLF-M3772-00 PLATE,BASE L 1
2
KLF-M3772-51 PLATE,BASE R 1 NG MK30019-2013/3/13
KLF-M3772-50 PLATE,BASE R 1
3
KLF-M3778-01 BRKT.,CYLINDER 4 OK MKX0074-2013/11/22
KLF-M3778-00 BRKT.,CYLINDER 4
4 KLF-M377B-00
CAM FOLLOWER 4
5 KLF-M377C-00 CYLINDER 2
6 KLF-M377D-00 BOLT,STOPPER 1
7 KLF-M377H-01 GUIDE,FOLLOWER 2
8 KLF-M377K-00 STOPPER,V 1
9 KLF-M377L-00 JOINT,CYLINDER. 2
10 KLF-M377P-00 BLOCK,STOPPER 1
11 KLF-M377S-00 GUIDE,HNS. L 1
12 KLF-M377S-50 GUIDE,HNS. R 1
13
KLF-M377U-02 BRKT.,SENSOR 2 L=60mm NG MJ00227-2012/10/30
KLF-M377U-01 BRKT.,SENSOR 2 L=55mm
14
KLF-M377V-01 BRKT.,SENSOR 2L 1 H=27mm NG MJ00227-2012/10/30
KLF-M377V-00 BRKT.,SENSOR 2L 1 H=22mm
15
KLF-M377V-51
BRKT.,SENSOR 2R 1 H=27mm NG MJ00227-2012/10/30
KLF-M377V-50 BRKT.,SENSOR 2R 1 H=22mm
16
KLF-M377W-01 COVER,SENSOR 2 NG MK30019-2013/3/13
KLF-M377W-00 COVER,SENSOR 2
17 KHY-M3AA6-00 SAFETY PAD 2
18 90K41-001620 LABEL,CAUTION 1
19 $SC4-01A SPEED CONTROLLER 2
20 $TL4-01 JOINT 2
21 90112-10J020 BOLT HEX SOCKET HEAD 2
22 90112-10J030 BOLT HEX.S.H.:M10X30 2
23
91312-03005 BOLT HEX.SOCKET HEAD 4 M3X5 OK MK30019-2013/3/13
91312-03005 BOLT HEX.SOCKET HEAD 12 M3X5
24 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
25 91312-04012 BOLT,HEX.SOCKET HEAD 4 M4X12
26 91312-05020 BOLT HEX.SOCKET HEAD 4 M5X20
27 91312-06012 BOLT HEX.SOCKET HEAD 16 M6X12
28 91312-08060 BOLT HEX.SOCKET HEAD 6 M8X60
29
92902-04200 WASHER PLAIN 4 NG MJ00227-2012/10/30
92902-03200 WASHER PLAIN 4
30 92902-04200 WASHER PLAIN 4
31 98502-03010 SCREW PAN HEAD (+) 4
32 99480-05018 PIN,PARALLEL 1
33 99480-08020 PIN PARALLEL: 8X20 2
34 KLF-M654A-00 SENSOR,FDR FLT ASSY 1
35 KLF-M654B-00 SEN.FES CLAMP ASSY 1
36 91312-04005 BOLT HEX.SOCKET HEAD 8 NG MK30019-2013/3/13
9
3
Clamp FES46 ARM / Cam Follower
Feeder Holder
KLF-1307
9
9
9
7
3
13
10
8
22
18
14
14
17
25
4
23
11
11
26
25
19
23
21
15
6
5
1
17
9
7
24
24
12
16
12
16
20
20
15
15
18
18
8
18
19
23
25
26
15
1
15
21
22
10
25
23
14
14
17
17
11
11
5
6
4
13
2
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M3771-00 BASE,LINK 2
2 KLF-M3773-00 ARM,CLAMP L 1
3 KLF-M3773-50 ARM,CLAMP R 1
4 KLF-M3774-00 HOLDER,ARM 2
5 KLF-M3775-00 LINK,CLAMP MAIN 2
6 KLF-M3776-00 BASE,LINK 2 2
7 KLF-M3777-00 HOLDER,FOLLOWER 2
8 KLF-M3779-00 CLAMP,FOLLOWER 2
9 KLF-M377B-00 CAM FOLLOWER 2
10 KLF-M377E-00 STEP SCREW 2
11 KLF-M377F-00 PIN,HINGE 4
12 KLF-M377M-00 PAD 4
13 KLF-M377N-00 HOLDER,CLAMPER 2
14 KLF-M378C-00 BRKT.,CLAMP FIX 4
15 KKU-M1138-00 CAM FOLLOWER 6
16 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
17 91312-05010 BOLT HEX.SOCKET HEAD 8 M5X10
18 91312-05016 BOLT HEX.SOCKET HEAD 12 M5X16
19 91312-06025 BOLT HEX.SOCKET HEAD 4 M6X25
20 91312-06035 BOLT HEX,SOCKET HEAD 4 M6X35
21 91312-08030 BOLT HEX.SOCKET HEAD 6 M8X30
22 92902-05200 WASHER PLAIN 2
23
90152-05J06 SCREW,SET 4 OK MJ90041-2012/9/7
92A08-05306 SCREW,SET 4
24 95602-08100 NUT U 2
25 99480-04010 PIN PARALLEL: 4X10 8
26 99480-08020 PIN PARALLEL: 8X20 4
1
4
X-axis Motor / Sensor / Cover
Moving-axis
KLF-1307
17
9
D
A
B
C
15
14
33
13
42
12
10
11
38
43
38
32
20
33
39
33
8
40
45
2
33
Type B, C
Type B, C
45
26
27
28
29
41
41
18
34
7
4
39
39
39
6
3
5
39
39
35
24
23
21
22
30
39
31
16
18
1
37
36
47
44
25
33
19
Type B, C
46
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M227B-01 COVER,2-XA BS 1 OK MK30064-2013/3/18
KLF-M227B-00 COVER,2-XA BS 1
2
KLF-M227B-51 COVER,2-XB BS 1 Type B, C OK MK30064-2013/3/18
KLF-M227B-50 COVER,2-XB BS 1 Type B, C
3 KLF-M227C-00 COVER,3-1 BS 1
4 KLF-M227C-50 COVER,3-1 BS 1 Type B, C
5
KLF-M227E-00 STAY,1
1
6
KLF-M227F-00 COVER,3-2 BS 1
7 KLF-M227F-50 COVER,3-2 BS 1 Type B, C
8
Delete OK MK30064-2013/3/18
KLF-M227J-01 PLATE,GREASE CAP 1
9 KLF-M2221-A0 X AD MOTOR ASSY 1
10
KLF-M2221-00 HOLDER,X MOTOR 1
11 90KA1-703303 AC SERVO MOTOR 1
12 KLF-M2222-00 PULLEY X2 1
13 KLF-M224V-00 BRKT.,A FAN X-M 1
14 KLF-M6185-A0 FAN MOTOR ASSY 1
15 KGN-M4187-00 FAN GUARD 1
16 KLF-M2208-00 COVER,2 X 1
17 KLF-M2224-00 BELT X 1
18 KLF-M2233-00 BRKT.,SENSOR 2
19 KLF-M2249-00 BRKT.,A M-HNS. 1
20 KLF-M224W-00 COVER,XA MOTOR 1
21
KLF-M227A-01 COVER,1A BS 1 Notch=72x6mm NG MJ90002-2012/9/7
KLF-M227A-00 COVER,1 BS 1 Notch=67x6mm
22 KLF-M227K-00 PLATE, B 1
23 KLF-M227L-00 FLAT W 1
24 KLF-M227N-00 PLATE, W 1
25 KLF-M2676-00 BRKT.,X MOTOR HOLDER 1
26 KLF-M653A-00 SEN.SB X ORG ASSY 1
27 KLF-M653B-00 SEN.SB X OT1 ASSY 1
28 KLF-M653C-00 SEN.SB X OT2 ASSY 1
29 KLF-M653E-00 SENSOR X SAFE ASSY 1
30 90990-41J134 COLLAR 2
31 90K41-001730 LABEL,CAUTION 1
32 91312-04006 BOLT HEX.SOCKET HEAD 3 M4X6
33 91312-04008 BOLT HEX.SOCKET HEAD 5 M4X8
34 91312-04010 BOLT,HEX.SOCKET HEAD 8 M4X10
35 91312-04012 BOLT,HEX.SOCKET HEAD 2 M4X12
36 91312-04025 BOLT HEX.SOCKET HEAD 1 M4X25
37 91312-04030 BOLT HEX.SOCKET HEAD 4 M4X30
38 91312-05016 BOLT HEX.SOCKET HEAD 4 M5X16
39 98902-04008 SCREW BINDING HEAD 16
40
Delete MK30064-2013/3/18
97602-04306 SCREW,BIN.HEAD W/W. 10
41 90990-11J005 SCREW,PAN HEAD W/W 4
42 92A08-04306 SCREW, SET 2
43 92902-05200 WASHER PLAIN 2
44 95302-04600 NUT HEXAGON 1
45 97602-03108 SCREW PAN HEAD W/W 8
46
KLF-M227A-51 COVER,1B BS 1 Notch=72x6mm NG MJ90002-2012/9/7
KLF-M227A-50 COVER,1 BS 1 Notch=67x6mm
47 90990-01J098 BOLT HEX.SOCKET HEAD 2 MJX0037-2012/11/9
