YSM40_PartList - 第38页
2 5 R-axis Assy (MU) Head KLF-1210 12 13 21 34 24 25 35 36 27 27 29 29 3 1 22 22 22 14 22 4 5 34 21 9 35 1 1 36 23 33 23 33 20 19 15 20 19 15 21 34 24 27 35 36 35 10 22 23 23 6 6 16 16 18 28 17 27 27 26 34 21 8 27 36 30 …
1
5
Head (MU)
Head
KLF-1307
17
25
7
20
20
12
4
29
30
15
15
9
19
28
24
24
21
23
23
18
10
2
1
26
19
19
19
22
6
8
11
27
16
5
20
3
28
13
14
31
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M71K0-00 Z AXIS ASSY.1 2
2 KLF-M71L0-00 Z AXIS ASSY.2 2
3
KLF-M715A-A1 VALVE,ASSY. 1 OK MLY0002-2015/1/22
KLF-M715A-A0 VALVE,ASSY. 1
4 KLF-M7150-B0 VALVE,PRESS. 1
5 KLF-M7109-00 BASE,VALVE 1
6 KLF-M71C1-00 COVER,CABLE 1
7 KLF-M71C4-00 BRACKET,CONNECTOR 1
8 KLF-M71C8-00 BRACKET,COVER 1
9 KLF-M71C9-01 COVER,HEAD 1
10 KLF-M71CD-00 CLAMP,HARNESS 2
11 KLF-M71Y0-00 LABEL,HEAD SERIAL 2
12 KLF-M7152-00 VALVE, SPARE 1 Spare
13 KLF-M7153-00 VALVE 1 Spare
14 KLF-M7154-00 JOINT 1 Spare
15 90990-01J058 BOLT,HEX.SOCKET HEAD 6
16 90990-46J007 BOLT,THIN HEAD 4
17 97602-04306 SCREW,BIN.HEAD W/W. 4
18 98902-03004 SCREW BINDING HEAD 6
19 91312-04005 BOLT HEX.SOCKET HEAD 8 M4X5
20 91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
21 91312-04016 BOLT,HEX.SOCKET HEAD 4 M4X16
22 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
23 91312-04045 BOLT HEX.SOCKET HEAD 16 M4X45
24 91312-05012 BOLT HEX.SOCKET HEAD 8 M5X12
25 $NK-4N NYLON CLIP 4
26 KLF-M712A-00 TUBE(TUS0425N) 6
27 KLF-M712B-00 TUBE(TUS0425N) 4
28 KLF-M712C-00 TUBE(TUS0425N) 10
29
KLF-M712D-00 TUBE(TUS0425N) 4
30 $UB0850-R URETHANE TUBE 2 (200mm)
31 KLF-M7153-10 VALVE 1 Spare MK10136-2013/2/1
2
5
R-axis Assy (MU)
Head
KLF-1210
12
13
21
34
24
25
35
36
27
27
29
29
3
1
22
22
22
14
22
4
5
34
21
9
35
11
36
23
33
23
33
20
19
15
20
19
15
21
34
24
27
35
36
35
10
22
23
23
6
6
16
16
18
28
17
27
27
26
34
21
8
27
36
30
30
7
34
34
31
32
37
34
34
31
37
7
34
34
31
37
13
12
2
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7101-00 HOUSING,HEAD 1
2 KLF-M7102-00 PLATE,R MOTOR 1
3 KLF-M7113-00 PLATE 2,BRG. 1
4 KLF-M7114-00 PLATE 3,BRG. 10
5 KLF-M7118-00 PLATE 4,BRG. 1
6 KLF-M7125-00 BRACKET,STOPPER 2
7 KLF-M7126-00 SHAFT,TENSION 3
8 KLF-M7127-00 BLOCK 1,ADJUST 1
9 KLF-M7128-00 BLOCK 2,ADJUST 1
10 KLF-M7129-00 BLOCK 3,ADJUST 1
11 KLF-M7130-00 BLOCK 4,ADJUST 1
12 KLF-M7131-00 BELT 1 2
13 KLF-M7132-00 BELT 2 2
14 KLF-M7133-00 SHEET,SCREEN 1
15 KLF-M7134-00 PULLEY,R MOTOR 2
16 KLF-M7139-00 STOPPER R 2
17 90KB0-113503 AC SERVO MOTOR R1 1
18 90KB0-113504 AC SERVO MOTOR R2 1
19 KGV-M7157-00 BLOCK2,STOPPER R 2
20 KHN-M7132-00 BLOCK1 STOPPER 2
21 KV8-M7115-00 SHAFT 1,TENSION 4
22 91312-03006 BOLT HEX.SOCKET HEAD 28 M3X6
23 91312-03010 BOLT HEX.SOCKET HEAD 6 M3X10
24 91312-03012 BOLT,HEX.SOCKET HEAD 4 M3X12
25 91312-03030 BOLT,HEX.SOCKET HEAD 2 M3X30
26 91312-03035 BOLT,HEX.SOCKET HEAD 2 M3X35
27 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
28 91312-05018 BOLT HEX.SOCKET HEAD 2 M5X18
29 98702-03006 SCREW FLAT HEAD 14
30 92A08-04304 SET SCREW M4X4 4
31 99009-07800 CIRCLIP : 3
32 99480-04008 PIN,PARALLEL:4X8 2
33 90990-19J016 NEEDLE,PIN 2
34 90990-25J016 BEARING 20
35 92902-03200 WASHER PLAIN 8
36 92902-04200 WASHER PLAIN 4
37 90990-28J157 WASHER,PLAIN 3
3
5
Head Shaft Assy (MU)
Head
KLF-1210
9
9
10
10
14
15
17
15
9
9
10
10
14
15
16
15
9
9
10
10
14
15
16
15
9
9
10
10
14
15
16
15
9
9
10
10
14
15
16
15
1
9
13
11
12
9
10
10
2
3
4
5
6
13
11
12
13
11
12
13
11
12
2
5
6
5
6
2
1
1
4
3
13
11
12
13
11
12
7
7
8
8
8
8
14
15
17
15
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7106-A0 HEAD SHAFT 1 ASSY. 2
2 KLF-M7106-B0 HEAD SHAFT 1 ASSY. 2
3 KLF-M7106-C0 HEAD SHAFT 1 ASSY. 1
4 KLF-M7106-D0 HEAD SHAFT 1 ASSY. 1
5 KLF-M7107-A0 HEAD SHAFT 2 ASSY. 2
6 KLF-M7107-B0 HEAD SHAFT 2 ASSY. 2
7 KLF-M711S-A0 SHAFT 1,SPARE 1 Spare
8 KLF-M712S-A0 SHAFT 2,SPARE 1 Spare
9 KG7-M7137-A0 LEAF SPRING 20
10 90990-08J016 SCREW,PAN HEAD 20
11 91317-03005 BOLT HEX.SOCKET HEAD 10 M3X5
12 90990-36J007 WASHER,SEAL 10
13 $TSH4-M5M JOINT 4
14 90990-17J053 O-RING 12
15 90990-08J016 SCREW,PAN HEAD 12
16 KLF-M7105-00 HOLDER,NOZZLE 4
17 KLF-M7105-10 HOLDER,NOZZLE 2 V-groove
