YSM40_PartList - 第42页
6 5 Servo - I/O BOX (FL) Head KLF-1307 4 29 28 27 15 22 23 24 26 23 6 2 3 23 23 23 7 27 22 26 27 17 20 22 22 1 1 32 18 21 31 33 27 19 1 30 27 16 14 25 19 5 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-d…
5
5
Head (FL)
Head
KLF-1304
27
26
31
6
8
8
33
32
4
19
21
5
4
5
21
29
7
20
20
6
30
29
15
3
11
18
9
10
18
22
17
14
13
2
12
12
15
19
16
28
28
28
24
23
27
26
34
1
25
23
16
35
36
37
35
38
36
37
38
9
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M7411-01 PLATE,BASE 1 Sulcular shapes are different NG MK90117-2013/10/11
KLF-M7411-00 PLATE,BASE 1
2 KLF-M741P-00 COVER,HEAD 1
3 KLF-M741R-00 BLOCK,HEAD 1
4 KLF-M742C-00 SPRING,RETURN 2
5 KLF-M742K-00 GUIDE, SPRING 2
6 KLF-M742R-00 BRKT.,CABLE 2
7 KLF-M74C1-00 COVER,CABLE 1
8 KLF-M74Y0-00 LABEL,HEAD SERIAL 2
9
KLF-M7143-01 KEY,PARALLEL 1 NG MK90117-2013/10/11
KLF-M7143-00 KEY PARALLEL 2
10 90112-02J008 BOLT HEX.SOCKET HEAD 4
11 90990-01J038 BOLT,HEX.SOCKET HEAD 2
12 90990-01J058 BOLT,HEX.SOCKET HEAD 8
13 91312-03008 BOLT HEX.SOCKET HEAD 2 M3X8
14 91312-03010 BOLT HEX.SOCKET HEAD 2 M3X10
15 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
16 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
17 91312-05014 BOLT HEX.SOCKET HEAD 4 M5X14
18 91312-05018 BOLT HEX.SOCKET HEAD 8 M5X18
19 91317-04008 BOLT HEX.SOCKET HEAD 2 M4X8
20 92012-04008 BOLT,BUTTON HEAD 4 M4X8
21 92017-04008 BOLT,BUTTON HEAD 4 M4X8
22 99480-05010 PIN,PARALLEL 4
23
KLF-M7451-A1 VALVE,ASSY. 2 OK MLY0002-2015/1/22
KLF-M7451-A0 VALVE,ASSY. 2
24 KLF-M654C-00 SENSOR PRESS. ASSY 1
25 $PF-M3 PLUG 1
26 $TS6-01M
JOINT 2
27 $TSH6-M5M JOINT 4
28 $UT6M JOINT 4
29 99480-04012 PIN,PARALLEL 2
30 KLF-M74S0-00 Z1 AXIS ASSY. 1
31 KLF-M74S0-10 Z2 AXIS ASSY. 1
32 KLF-M74R0-00 R1 AXIS ASSY. 1
33 KLF-M74R0-10 R2 AXIS ASSY. 1
34 KLF-M74C0-00 SERVO I/O BOX ASSY. 1
35 KLF-M7153-00 VALVE 6 Spare
36 KLF-M7156-00 FILTER 2 Spare
37 90166-02JA04 SCREW PAN HEAD 4 Spare
6
5
Servo - I/O BOX (FL)
Head
KLF-1307
4
29
28
27
15
22
23
24
26
23
6
2
3
23
23
23
7
27
22
26
27
17
20
22
22
11
32
18
21
31
33
27
19
1
30
27
16
14
25
19
5
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M741J-00 BASE,VALVE 1
2 KLF-M741L-00 STAY,BASE 1
3 KLF-M741M-00 STAY,COVER 1
4 KLF-M741N-00 BRACKET,CONNECTOR 1
5 KLF-M741V-00 STAY,BKT. 1
6 KLF-M741W-00 BRKT,CABLE Z MOTOR 1
7
KLA-M5802-15 HEAD SERVO UNIT ASSY 1 OK MK60057-2013/7/3
KLA-M5802-14 HEAD SERVO UNIT ASSY 1
8
9
10
11
12
13
14 KLF-M6185-00 FAN MOTOR ASSY. 1
15 KLF-M7191-01 BOX,SERVO BRD. 1
16 KLF-M7196-00 BASE,FAN MOTOR 1
17 KLF-M71C6-00 BRACKET,SERVO BOX 1
18 KLF-M71C7-00 BRACKET,JOINT 1
19 KLF-M71CB-00 PLATE,NUT 2
20 KLF-M71CE-00 CLAMP,CONNECTOR 1
21 90990-23J030 GROMMET 5
22 91312-03006 BOLT HEX.SOCKET HEAD 8 M3X6
23 91312-03008 BOLT HEX.SOCKET HEAD 9 M3X8
24 91312-03010 BOLT HEX.SOCKET HEAD 2 M3X10
25 91312-03020 BOLT,HEX.SOCKET HEAD 4 M3X20
26 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
27 91312-04008 BOLT HEX.SOCKET HEAD 9 M4X8
28 92012-04006 BOLT, BUTTON HEAD 2 M4X6
29 92012-04008 BOLT,BUTTON HEAD 2 M4X8
30 $NK-3N NYLON CLIP 1
31 $TS6-01 JOINT 5
32 $TSM8-01 JOINT 5
33 $UP6 PLUG 1
34
7
5
Z-axis Assy (FL)
Head
KLF-1307
22
16
22
15
8
2
22
21
18
14
13
11
12
3
27
21
29
24
17
28
21
20
9
7
23
31
26
26
1
10
19
4
5
30
6
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7412-00 PLATE,HEAD 1
2 KLF-M7414-00 HOLDER,MOTOR Z 1
3 KLF-M7421-01 BALL SCREW 1
4 KLF-M7422-00 GUIDE,Z AXIS 1
5 KLF-M7423-00 BLOCK,SCREW 1
6 KLF-M742A-00 DAMPER 1 1
7 KLF-M742B-00 DAMPER 2 1
8 KLF-M748B-01 COUPLING 1
9 KJX-M7C15-00 HOLDER,BEARING 1
10 KJX-M7C2C-00 PLATE,HOLDER BRG. 1
11 KLH-M7C2A-00 BEARING 1
12 KLH-M7C2G-00 PLATE,BEARING 1
13 KLH-M7C2N-00 LOCK NUT,SCREW 1
14 KLH-M7C2P-00 SPACER 2
15 90K24-032003 AC SERVO MOTOR Z1 1 Z1
16 90K24-032004 AC SERVO MOTOR Z2 1 Z2
17 90933-02J624 BEARING 1
18 90990-02J004 SET SCREW 2
19 91312-03005 BOLT HEX.SOCKET HEAD 3 M3X5
20 91312-03008 BOLT HEX.SOCKET HEAD 6 M3X8
21 91312-03010 BOLT HEX.SOCKET HEAD 8 M3X10
22 91312-03014 BOLT,HEX.SOCKET HEAD 8 M3X14
23 91312-03018 BOLT HEX.SOCKET HEAD 2 M3X18
24 91312-03020 BOLT,HEX.SOCKET HEAD 4 M3X20
26 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
27 91312-04020 BOLT HEX.SOCKET HEAD 4 M4X20
28 99009-04400 CIRCLIP 1
29 99480-03008 PIN,PARALLEL 2
30 99480-04010 PIN PARALLEL: 4X10 4
31 99480-04012 PIN,PARALLEL 2
