YSM40_PartList - 第52页
1 6 Nozzle Nozzle KLF-1307 26 NOZZLE 601A ASSY . 27 28 30 NOZZLE 602A ASSY . 32 NOZZLE 603 ASSY . 33 NOZZLE 64A/604A ASSY . 21 34 NOZZLE 65A/605A ASSY . NOZZLE 66A/606A ASSY . 36 35 31 28 29 37 38 29 1 NOZZLE 501A ASSY .…
15
5
Rotary shaft Assy (HS)
Head
KLF-1307
6
17
5
4
2
3
7
18
16
20
19
23
22
24
25
21
6
1
5
4
2
3
7
8
16
10
9
13
12
14
15
11
35
36
6
26
5
4
2
3
7
27
16
29
28
32
31
33
34
30
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7040-A2 ROTARY SHAFT ASSY.1 1
2 KLF-M7042-01 HOLDER,MAIN 1
3
KLF-M701S-00 SHAFT A,NOZZLE 1 Diameter A rank MK00062-2013/10/21
KLF-M702S-00 SHAFT B,NOZZLE 1 Diameter B rank MK00062-2013/10/21
KLF-M703S-00 SHAFT C,NOZZLE 1 Diameter C rank MK00062-2013/10/21
4 KLF-M7046-00 SPRING 8
5 KLF-M7047-02 BLOCK,RETURN 8
6 KLF-M704F-00 NEEDLE PIN 1 This parts need press t and training.
7 KG7-M7137-A0 LEAF SPRING 8
8 KLF-M704W-10 PLATE,SPRING 1 1
9 KLF-M704W-20 PLATE,SPRING 2 1
10 KLF-M704W-30 PLATE,SPRING 3 1
11 KLF-M704W-40 PLATE,SPRING 4 1
12 KLF-M704W-50 PLATE,SPRING 5 1
13 KLF-M704W-60 PLATE,SPRING 6 1
14 KLF-M704W-70 PLATE,SPRING 7 1
15 KLF-M704W-80 PLATE,SPRING 8 1
16 90990-08J016 SCREW,PAN HEAD 8
17
KLF-M7040-B2 ROTARY SHAFT ASSY.2 1
18 KLF-M704W-90 PLATE,SPRING 9 1
19 KLF-M704W-A0 PLATE,SPRING 10 1
20 KLF-M704W-B0 PLATE,SPRING 11 1
21 KLF-M704W-C0 PLATE,SPRING 12 1
22 KLF-M704W-D0 PLATE,SPRING 13 1
23 KLF-M704W-E0 PLATE,SPRING 14 1
24 KLF-M704W-F0 PLATE,SPRING 15 1
25
KLF-M704W-G0 PLATE,SPRING 16 1
26 KLF-M7040-C2 ROTARY SHAFT ASSY.3 1
27 KLF-M704W-H0 PLATE,SPRING 17 1
28 KLF-M704W-J0 PLATE,SPRING 18 1
29 KLF-M704W-K0 PLATE,SPRING 19 1
30 KLF-M704W-L0 PLATE,SPRING 20 1
31 KLF-M704W-M0 PLATE,SPRING 21 1
32 KLF-M704W-N0 PLATE,SPRING 22 1
33 KLF-M704W-P0 PLATE,SPRING 23 1
34 KLF-M704W-R0 PLATE,SPRING 24 1
35 KLF-M704A-01 SPRING HOLDER ASSY. 1
36 KLF-M704B-00 SPRING 1
1
6
Nozzle
Nozzle
KLF-1307
26
NOZZLE 601A ASSY.
27
28
30
NOZZLE 602A ASSY.
32
NOZZLE 603 ASSY.
33
NOZZLE 64A/604A ASSY.
21
34
NOZZLE 65A/605A ASSY. NOZZLE 66A/606A ASSY.
36
35
31
28
29
37
38
29
1
NOZZLE 501A ASSY.
2
3
10
NOZZLE 512A ASSY.
11
3
12
NOZZLE 513A ASSY.
13
3
17
18
14
NOZZLE 503A/514A ASSY.
15
16
4
NOZZLE 502A ASSY.
5
3
6
NOZZLE 510A ASSY.
7
3
8
NOZZLE 511A ASSY.
9
3
20
19
NOZZLE 504A/515A ASSY.
21
17
18
22
NOZZLE 506A/515A ASSY. NOZZLE 507A/518A ASSY.
23
16
24
20
25
29
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7710-A0 NOZZLE,501A ASSY. 1 (HS,MU)
2 KLF-M7711-00 BODY,NOZZLE 501 1
3 KLF-M7713-00 SPRING,NOZZLE 6
4 KLF-M7720-A0 NOZZLE,502A ASSY. 1 (HS,MU)
5 KLF-M7721-00 BODY,NOZZLE 502 1
6 KLF-M87A0-A0 NOZZLE,510A ASSY. 1 (HS,MU)
7 KLF-M87A1-00 BODY,NOZZLE 510 1
8 KLF-M8710-A0 NOZZLE,511A ASSY. 1 (HS,MU)
9 KLF-M8711-00 BODY,NOZZLE 511 1
10 KLF-M8720-A0 NOZZLE,512A ASSY. 1 (HS,MU)
11 KLF-M8721-00 BODY,NOZZLE 512 1
12
KLF-M8730-A1 NOZZLE,513A ASSY. 1 (HS,MU) OK MK20138-2013/3/4
KLF-M8730-A0 NOZZLE,513A ASSY. 1
13
KLF-M8731-01 BODY,NOZZLE 513 1 OK MK20138-2013/3/4
KLF-M8731-00 BODY,NOZZLE 513 1
14 KLF-M8740-A0 NOZZLE,503A/514A AS. 1 (MU)
15 KHY-M7741-00 BODY,NOZZLE 303/314 1
16 KHN-M7713-00 SPRING 2
17 KHN-M7714-00 PIN 2
18 KHN-M7715-00 CLIP 2
19 KLF-M8750-A0 NOZZLE,504A/515A AS. 1 (MU)
20 KGS-M7742-00 LABEL,NOZZLE 2
21 90990-17J013 O-RING 1
22 KLF-M8770-A0 NOZZLE,506A/517A AS. 1 (MU)
23 KHY-M7771-00 BODY,NOZZLE 306/317 1
24 KLF-M8780-A0 NOZZLE,507A/518A AS. 1 (MU)
25 90990-17J014 O-RING 1
26 KLS-M7710-A0 NOZZLE 601A ASSY. 1 (FL)
27 KLS-M7711-00 BODY,NOZZLE 601 1
28 KLS-M7713-00 SPRING 1
29 90990-19J019 NEEDLE,PIN 1
30 KLS-M7720-A0 NOZZLE 602A ASSY. 1 (FL)
31 KLS-M7721-00 BODY,NOZZLE 602 1
32 KLS-M7730-A0 NOZZLE 603A ASSY. 1 (FL)
33 KV7-M7740-A0 NOZZLE 64A/604A AS. 1 (FL)
34 KV7-M7750-A0 NOZZLE 65A/605A AS. 1 (FL)
35 KV7-M7760-00 NOZZLE 66A/606A 1 (FL)
36 90990-17J015 O-RING 1
37 KLS-M7714-00 SPRING 1 (FL)
38 KLS-M7731-00 BODY,NOZZLE 603 1 (FL)
2
6
Nozzle Change (Holder)
Nozzle
KLF-1307
24
24
22
2
23
25
13
12
17
1
11
21
10
7
6
5
22
22
22
22
20
15
4
8
18
19
9
14
16
3
3
26
27
OLD
3
3
FL Type
MU Type
31
30
25
32
33
34
28
29
8
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M9661-A0 NOZZLE HOLDER ASSY. 1
2 KLF-M9662-00 PLATE,CLAMP 1
3
KLF-M9663-01 SHEET,CLAMP GUIDE 2 NG MK10026-2013/1/21
KLF-M9663-00 SHEET,CLAMP GUIDE 2
4 KLF-M9664-00 PLATE,JOINT,CYL. 1
5 KLF-M9665-00 PLATE 1 1
6 KLF-M9666-00 PLATE 2 1
7 KLF-M9667-00 PLATE 3 1
8 KLF-M9668-00 PLATE 4 1
9 KLF-M9655-00 BLOCK,STOPPER 1
10 KHY-M9621-A0 BASE,NOZZLE D ASSY. 8
11 KHY-M9621-B0 BASE,NOZZLE D 1
12 KKS-M9622-A1 SPACER3 ASSY. 4
13 KKS-M9622-01 SPACER HOLDER 3 1
14 KKU-M184K-00 CYLINDER (MBDAS) 1
15 KGS-M9604-00 JOINT CYL. 1
16
KJD-M1740-00 SPEED CONTROLLER 2 MK30085-2013/3/26
Delete MK10028-2013/1/22
$SC4-M3MA SPEED CONTROLLER 2
17 KKE-M9608-00 PIN,SLIDE 2
18 90112-2AJ006 BOLT,HEX.SOCKET HEAD 1
19 90112-2AJ010 BOLT,HEX.S.H:M2.5X10 2
20 90112-2AJ020 BOLT HEX.SOCKET HEAD 2
21 92012-03006 BOLT,BUTTON HEAD 2
22 91312-03008 BOLT HEX.SOCKET HEAD 8 M3X8
23 91312-04025 BOLT HEX.SOCKET HEAD 2 M4X25
24 98902-03008 SCREW BINDING HEAD 8
25 91312-03006 BOLT HEX.SOCKET HEAD 2
26 KLF-M653S-00 SENSOR ANC OPEN ASSY 1
27 KLF-M653S-10 SENSOR ANC CL. ASSY 1
28 KLF-M9681-A0 NOZZLE HOLDER ASSY. 1
29 KLF-M9682-00 PLATE,CLAMP 1
30 KLF-M9684-00 PLATE 1 1
31 KLF-M9685-00 PLATE 2 1
32 KLF-M968B-00 SPACER,NOZZLE 1 1
33 KLF-M968B-A0 SPACER1 ASSY. 2
34 90112-2AJ005 BOLT,HEX.SOCKET HEAD 1
