YSM40_PartList - 第66页
9 7 Clamp Board 1 (Before Y28724) Conveyor KLF-1307 8 9 12 7 5 4 1 1 1 1 10 15 or 16 6 2 4 7 5 1 1 10 13 17 18 17 17 18 18 14 3 7 5 8 6 4 9 12 5 1 1 13 14 4 1 1 1 3 7 20 19 19 20 No. Part No. Part Name Q'ty Remarks …
8
7
Frame Assy
Conveyor
KLF-1307
14
12
13
13
13
13
3
2
1
18
11
11
20
12
6
14
6
14
16
17
16
7
16
8
16
16
15
7
16
17
17
17
8
4
16
8
16
17
17
8
4
4
16
16
15
7
19
19
19
20
3 2
2 3
10 9
9 10
17
4
4
15
16
17
16
7
4
15
10
9
5
14
5
1
1
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M9121-02 FRAME,CONVEYOR 4 OK MK50017-2013/6/6
KLF-M9121-01 FRAME,CONVEYOR 4 NG MJX0201-2012/12/4
KLF-M9121-A0 FRAME SUB ASSY. 4
2
KLF-M9130-A2 GUIDE SUB ASSY. 2 OK MK40124-2013/5/7
KLF-M9130-A1 GUIDE SUB ASSY. 2 OK MK20026-2013/2/14
KLF-M9130-A0 GUIDE SUB ASSY. 2
3
KLF-M9130-B2 GUIDE SUB ASSY. 2 OK MK40124-2013/5/7
KLF-M9130-B1 GUIDE SUB ASSY. 2 OK MK20026-2013/2/14
KLF-M9130-B0 GUIDE SUB ASSY. 2
4 KLF-M913A-A0 PULLEY,ASSY. 8
5 KGA-M9113-00 GUIDE 1,END 4
6 KGA-M9114-00 GUIDE 2,END 4
7 KGS-M9140-A0 PULLEY CONV. ASSY. 4
8 KGY-M9140-A0 PULLEY CONV. ASSY. 4
9
KLF-M9122-01 PLATE 1A,GUIDE 2 OK MJ90044-2012/9/12
KLF-M9122-00 PLATE 1A,GUIDE 2
10
KLF-M9122-11 PLATE 1A,GUIDE 2 OK MJ90044-2012/9/12
KLF-M9122-10 PLATE 1A,GUIDE 2
11
KLF-M9123-01 PLATE 2,GUIDE 4 OK MJ90044-2012/9/12
KLF-M9123-00 PLATE 2,GUIDE 4
12 91312-03006 BOLT HEX.SOCKET HEAD 16 M3X6
13 91312-03008 BOLT HEX.SOCKET HEAD 20 M3X8
14 91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
15 91312-05020 BOLT HEX.SOCKET HEAD 4 M5X20
16 92902-05200 WASHER PLAIN 20
17 92902-05600 WASHER PLAIN 16
18 95302-03700 NUT HEXAGON 48
19 KLF-M9120-A0 FRAME ASSY. 2
20 KLF-M9120-B0 FRAME ASSY. 2
9
7
Clamp Board 1 (Before Y28724)
Conveyor
KLF-1307
8
9
12
7
5
4
11
11
10
15 or 16
6
2
4
7
5
11
10
13
17
18
17
17
18
18
14
3
7
5
8
6
4
9
12
5
11
13
14
4
11
1
3
7
20
19
19
20
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M9261-00 STAY,BOARD CLAMP 1 1
2 KLF-M9261-10 STAY,BOARD CLAMP 2 1
3 KLF-M926D-00 PLATE,BOARD CLAMP 2
4 KLF-M926E-00 SPRING PLUNGER 4
5 KLF-M926F-00 HOLDER,PLUNGER 4
6 KLF-M926L-00 PIN,ECCENTRIC 2
7 95302-06600 NUT HEXAGON 4
8 90169-02JB04 SCREW, BINDING HEAD 12
9 90990-28J060 WASHER,PLAIN 4
10 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
11 91312-04014 BOLT HEX.SOCKET HEAD 8 M4X12
12 92012-03005 BOLT BUTTON HEAD 4
13 92012-04006 BOLT, BUTTON HEAD 8
14 92902-04600 WASHER PLAIN 8
15 KLF-M9120-A0 FRAME ASSY. 2
16 KLF-M9120-B0 FRAME ASSY. 2
17 KLF-M9260-10 CP BOARD 1 SUB ASSY. 2
18 KLF-M9260-20 CP BOARD 2 SUB ASSY. 2
19 KLF-M9260-30 CP BOARD 3 SUB ASSY. 2
20 KLF-M9260-40 CP BOARD 4 SUB ASSY. 2
10
7
Clamp Board 2 (Before Y28724)
Conveyor
KLF-1307
10
19
7
5
8
6
4
9
12
5
11
13
14
4
11
11
1
3
7
8
9
12
7
5
4
11
11
15 or 16
6
2
4
7
5
11
10
13
20
14
3
18
17
17
18
20
19
19
20
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M9261-00 STAY,BOARD CLAMP 1 1
2 KLF-M9261-10 STAY,BOARD CLAMP 2 1
3 KLF-M926D-00 PLATE,BOARD CLAMP 2
4 KLF-M926E-00 SPRING PLUNGER 4
5 KLF-M926F-00 HOLDER,PLUNGER 4
6 KLF-M926L-00 PIN,ECCENTRIC 2
7 95302-06600 NUT HEXAGON 4
8 90169-02JB04 SCREW, BINDING HEAD 12
9 90990-28J060 WASHER,PLAIN 4
10 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
11 91312-04014 BOLT HEX.SOCKET HEAD 8 M4X12
12 92012-03005 BOLT BUTTON HEAD 4
13 92012-04006 BOLT, BUTTON HEAD 8
14 92902-04600 WASHER PLAIN 8
15 KLF-M9120-A0 FRAME ASSY. 2
16 KLF-M9120-B0 FRAME ASSY. 2
17 KLF-M9260-10 CP BOARD 1 SUB ASSY. 2
18 KLF-M9260-20 CP BOARD 2 SUB ASSY. 2
19 KLF-M9260-30 CP BOARD 3 SUB ASSY. 2
20 KLF-M9260-40 CP BOARD 4 SUB ASSY. 2
