YSM40_PartList - 第75页
2 9 Blow Station ( Up-Down) Blow Station KLF-1307 28 3 23 13 40 19 12 9 32 40 13 27 1 1 26 33 29 37 38 30 39 8 4 20 1 10 25 41 14 22 36 31 20 39 35 36 34 15 36 7 17 5 24 16 2 6 36 18 7 21 No. Part No. Part Name Q'ty…
1
9
Blow Station ( Fix )
Blow Station
KLF-1307
14
15
11
5
8
7
2
12
1617
17
17
17
6
9
12
12
3
10
13
14
15
4
1
1
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M9901-00 BASE,B.STN. 2
2 KLF-M9902-00 BRACKET,VALVE 1
3 KLF-M9903-00 BLOCK,BLOW ST. 1
4 KLF-M9904-00 PLATE 1
5 KLF-M9906-A0 VALVE ASSY. 1
6 KGR-M9934-01 INLINE FILTER 1
7 K40-M8598-10 PLUG 1 1
8 $TL6-02 JOINT 1
9 $TS6-01 JOINT 1 M3X5
10 $PF PLUG 1
11 91312-03025 BOLT,HEX.SOCKET HEAD 2 M3X25
12 91312-04008 BOLT HEX.SOCKET HEAD 10 M4X8
13 91312-04014 BOLT HEX.SOCKET HEAD 2 M4X14
14 91312-04025 BOLT HEX.SOCKET HEAD 2 M4X25
15 91312-06040 BOLT HEX.SOCKET HEAD 4 M6X40
16 $UB0640-BK URETHANE TUBE 1 (250mm)
17 $UB1065-BK URETHANE TUBE 1 (1400mm)
2
9
Blow Station ( Up-Down)
Blow Station
KLF-1307
28
3
23
13
40
19
12
9
32
40
13
27
11
26
33
29
37
38
30
39
8
4
20
1
10
25
41
14
22
36
31
20
39
35
36
34
15
36
7
17
5
24
16
2
6
36
18
7
21
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 $NK-2N NYLON CLIP
1
2 $SSU4 SPEED CONTROLLER
2
3 $TS4-M5M JOINT
2
4 $TS6-01M JOINT
1
5 $TSH6-02 JOINT
1
6
$ULA4M JOINT
2
7 $ULA6M JOINT
2
8 90112-02J005 BOLT HEX,SOCKET HEAD
4
9 90990-08J020 SCREW, PAN HEAD
6
10 90990-11J003 SCREW, PAN HEAD W/W
1
11 90990-41J158 COLLAR
2
12 91312-03006 BOLT HEX,SOCKET HEAD
2
13 91312-03010 BOLT HEX,SOCKET HEAD
8
14 91312-03014 BOLT HEX,SOCKET HEAD
2
15 91312-03020 BOLT HEX,SOCKET HEAD
2
16 91312-03025 BOLT HEX,SOCKET HEAD
2
17 K40-M8598-10 PLUG 1
1
18 KGR-M9934-01 INLINE FILTER
1
19 KLF-M7335-00 GUIDE,LINEAR
4
20 KLF-M9901-10 BASE,BLOW ST.
2
21 KLF-M9902-10 BRACKET,VALVE
1
22 KLF-M9903-10 BLOCK,BLOW ST.
1
23 KLF-M9905-10 PLATE,BLOW ST.1
1
24 KLF-M9906-A0 VALVE ASSY.
1
25 KLF-M9907-10 PLATE,BLOW ST.2
1
26 KLF-M9909-10 BLOCK,CYLINDER
1
27 KLF-M9910-10 STOPPER,BLOW ST.2
1
28 KLF-M9911-10 COVER,BLOW ST.1
1
29 KLF-M9912-10 STOPPER,BLOW ST.1
1
30 KLF-M9914-A0 CYL.BLOW ST.ASSY.
1
31 KLF-M9924-10 COVER,BLOW ST.2
1
32 KLF-M9925-10 PLATE,CYLINDER
1
33 KLF-M9926-10 JOINT,CYL.
1
34 KLF-M9930-10 COVER,HNS.1
1
35 KLF-M9931-10 COVER,HNS.2
1
36 91312-04006 BOLT HEX,SOCKET HEAD
8
37 91312-04025 BOLT HEX,SOCKET HEAD
2
38 91312-06045 BOLT HEX,SOCKET HEAD
4
39 98902-03006 SCREW BINDING HEAD
10
40 99480-03010 PIN,PARALLEL
4
41 $PF PLUG
1
3
9
Dump Box
Blow Station
KLF-1710
7
2
4
3
7
6
6
7
6
6
1
5
7
6
6
6
6
7
2
4
3
7
6
6
7
6
6
1
5
7
6
6
6
6
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M99D0-01 DUMP BOX ASSY.
4
2 KLF-M99D1-02 DUMP BOX
4
3 KLF-M99D2-02 DIFFUSE PLATE
4
4 KMB-M99D4-00 STAY,DUMP BOX 1
2
5 KMB-M99D5-00 STAY,DUMP BOX 2
2
6
90990-01J098 BOLT HEX,SOCKET HEAD
16
7 90990-41J150 COLLAR
8
