YSM40_PartList - 第85页
1 1 1 Set Up ST on MC FDR KLF-1308 30 32 33 10 31 31 17 13 24 3 23 26 26 1 1 8 12 31 25 25 14 37 38 39 35 36 28 28 20 20 22 22 22 16 16 31 34 15 18 6 22 2 19 27 31 19 27 31 9 22 29 21 29 29 21 21 4 7 1 5 No. Part No. Par…
8
10
Cutter Carriage
2
Tape Cutter
KLF-1308
40
30
38
24
30
38
24
16
32
27
9
8
9
33
18
26
14
36
28
7
44
9
27
14
26
37
29
7
31
9
8
34
10
41
1
22
15
12
9
11
22
31
9
12
15
19
17
8
6
3
13
21
39
5
14
23
9
25
4
14
39
5
17
35
18
42
2
20
8
43
43
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 90172-00J050
WASHER, EXTL, TOOTHED
4
2 90172-00J060 WASHER, EXTL, TOOTHED 2
3 90933-01J902 BEARING 1
4 90990-16J006 NUT, U & NUT, SELF LOCKING 1
5 90990-28J011 WASHER,PLAIN 2
6
90990-41J157 COLLAR
1
7 91312-04016 BOLT HEX,SOCKET HEAD 6
8 91312-05008 BOLT HEX,SOCKET HEAD 16
9 91312-05010 BOLT HEX,SOCKET HEAD 18
10 91312-05012 BOLT HEX,SOCKET HEAD 4
11 91312-05016 BOLT HEX,SOCKET HEAD 13
12 91312-05018 BOLT HEX,SOCKET HEAD 6
13 91312-06014 BOLT HEX,SOCKET HEAD 4
14 91312-06016 BOLT HEX,SOCKET HEAD 2
15 KGF-M1734-00 BUSH MAIN 2
16 KLF-M3TE5-00 PLATE,BASE 1
17 KLF-M3TE6-00 BRKT.,PLATE TOP 2
18 KLF-M3TEA-00 ARM,MAIN 2
19 KLF-M3TEB-00 BASE,ARM 1
20 KLF-M3TED-00 NUT SCREW THRE. 1
21 KLF-M3TEE-00 SCREW THREADS 1
22 KLF-M3TEF-00 SHAFT AR 2
23 KLF-M3TEG-00 PLATE,TOP 1
24 KLF-M3TEJ-00 HOLDER,SHAFT 2
25 KLF-M3TEL-00 PLATE,BRG. 1
26 KLF-M3TEN-00 PIN,LOCATE 2
27 KLF-M3TEU-00 PAD,ARM 2
28 KLF-M3TEV-00 BLOCK,L STOPPER 1
29 KLF-M3TEW-00 BLOCK,R STOPPER 1
30 KLF-M3TEX-00 DAMPER A 2
31 KLF-M3TEY-00 DAMPER B 2
32 KLF-M3TF1-00 FRAME,MAIN 1
33 KLF-M3TF2-00 BRACKET,L 1
34 KLF-M3TF3-00 BRACKET,R 1
35 KLF-M3TF4-00 BRACKET,ARM 1
36 KLF-M3TF5-00 GUIDE,L LEVER 1
37 KLF-M3TF6-00 GUIDE,R LEVER 1
38 91312-06020 BOLT HEX,SOCKET HEAD 8
39 91312-08016 BOLT HEX,SOCKET HEAD 2
40 92012-06010 BOLT BUTTON HEAD 2
41 92902-05600 WASHER,PLAIN 4
42 92902-06200 WASHER,PLAIN 2
43 92A08-05306 SCREW SET 8
44 99480-06014 PIN,PARALLEL 4
1
11
Set Up ST on MC
FDR
KLF-1308
30
32
33
10
31
31
17
13
24
3
23
26
26
11
8
12
31
25
25
14
37
38
39
35
36
28
28
20
20
22
22
22
16
16
31
34
15
18
6
22
2
19
27
31
19
27
31
9
22
29
21
29
29
21
21
4
7
1
5
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-MD101-00 FEEDER PLATE 1
2 KLF-MD102-00 COVER,HNS 1
3 KLF-MD103-00 COVER,SIDE 1
4 KLF-MD104-00 CLAMP PLATE 1
5 KLF-MD105-00 FEEDER STOPPER 1
6 KLF-MD106-00 CONNECTOR PLATE 1
7 KLF-MD107-00 COVER,BACK 1
8 KLF-MD108-00 COVER 1
9 KLF-MD1B0-00 SWITCH ASSY 1
10 KLF-MD111-00 RAIL GUIDE 16P 1
11 KLF-MD112-00 PLATE, UNDER COVER 1
12 KLF-MD113-00 HUNGER 1
13
Delete MK10084-2013/1/23
KLF-MD114-00 PLATE 1
14 KLF-MD1C0-00 SCREW,STAD 1
15 KHY-M372M-00 REELHOLDER EQUIP. 2
16 KHJ-MD115-00 PIN,HUNG R 2
17 KHJ-M4484-02 FDR.ST.BOARD ASSY 1
18 KLF-M66TE-10 HNS,F.CTRL - FDR. 1
19 90172-00J030 WASHER, EXTL.TOOTHED 4
20 90172-00J040 WASHER, EXTL.TOOTHED 4
21
90172-00J060 WASHER, EXTL.TOOTHED 6 MK10084-2013/1/23
90172-00J060 WASHER, EXTL.TOOTHED 8
22 90990-12J001 SCREW BIN.HEAD W/W 12
23 90990-23J029 GROMMET 1
24 91312-03006 BOLT HEX. SOCKET HEAD 2 M3X6
25 91312-04008 BOLT HEX. SOCKET HEAD 4 M4X8
26
Delete MK10084-2013/1/23
92012-06016 BOLT, BUTTON HEAD 4
27 92902-03200 WASHER PLAIN 4
28 92902-04200 WASHER PLAIN 4
29
92902-06200 WASHER PLAIN 6 MK10084-2013/1/23
92902-06200 WASHER PLAIN 8
30 98702-03008 SCREW FLAT HEAD 7
31 98902-03004 SCREW BINDING HEAD 14
32 98902-03008 SCREW BINDING HEAD 2
33 98902-04006 SCREW BINDING HEAD 2
34
98902-06010 SCREW BINDING HEAD 4 NG MK10084-2013/1/23
98902-06008 SCREW BINDING HEAD 4
35 KHJ-MD210-00 FOOT 6
36 91312-03008 BOLT HEX. SOCKET HEAD 6
37 KLF-MD123-00 SHAFT 1
38 KLF-MD126-00 BRKT, SHAFT 1
39 92012-03005 BOLT, BUTTON HEAD 4
12
20
38
19
16
38
28
43
42
37
43
42
37
37
34
23
6
33
32
30
28
41
38
2
10
9
35
3
8
13
29
31
14
7
37
36
21
37
36
18
22
24
5
1
11
37
38
15
25
17
37
26
27
4
38
40
39
38
11
2
FDR Power ST
FDR
KLF-1210
No. Part No. Part Name Q'ty Remarks
Compati. Revision No.-date
1 KHJ-MD201-00 FEEDER PLATE 1
2 KHJ-MD202-00 SIDE PLATE, L 1
3 KHJ-MD203-00 SIDE PLATE, R 1
4 KHJ-MD204-00 CLAMP PLATE 1
5 KHJ-MD205-00 FEEDER STOPPER 1
6 KHJ-MD206-00 CONNECTOR PLATE 1
7 KHJ-MD207-00
UNDER COVER
1
8
KHJ-MD208-00
BACK COVER 1
9 KHJ-MD209-00 BASE PLATE 1
10 KHJ-MD210-00 FOOT 4
11 KJJ-M371R-000 RAIL GUIDE 16P 1
12 KHJ-MD212-00 BKT. SWITCH 1
13 KHJ-MD213-00 REEL HOLDER, FIX. 1
14 KHJ-MD214-00 REEL HOLDER, MOVE 1
15 KHJ-MD110-00 LABEL, PITCH 1
16 KHJ-M4484-02 FDR. ST. BOARD ASSY 1
17 KHJ-M4486-00 PITCH LED BOARD ASSY 1
18 KJ3-M6511-00 CIRCUIT PROTECTOR, 1 1
19 KHJ-M537A-00
NOISE FILTER
1
20
KHJ-M6561-10
POWER SUPPLY 1 1
21
KHJ-M661B-01 HNS, AC IN 2
1
22 KHJ-M662A-00 HNS, CP DC24V 1
23 KHJ-M662B-00 HNS, LAMP 1
24 KHJ-M662C-000 HNS, BRD.PWR 1
25 KHJ-M663C-00 HNS, PITCH UP 1
26 KHJ-M663D-00 HNS, PITCH DOWN 1
27 KHJ-M663E-00 HNS, PITCH SET 1
28 KHY-M66TE-00 HNS, F. CTRL-FDR. 1
29
KJ3-M662A-00 HNS, AC IN 1 1 Abroad parts
KJ3-M661A-00 HNS, AC IN 1 1 Domestis parts
30 KHJ-MD215-001 LABEL, SERIAL 1
31 KHA-M5184-11 SEAL, LABEL 1
32 KHY-M6417-00 SEAL, CE 1
33 KHY-M372M-00 SCREW, STAD 2
34 90563-03J100 SPACER BOLT 4
35 92902-03200 WASHER PLAIN 4
36
98902-03004 SCREW BINDING HEAD 4
37 98902-03005 SCREW BINDING HEAD 28
38 98902-04006 SCREW BINDING HEAD 10
39 98702-03006 SCREW FLAT HEAD 8
40 91312-03006 BOLT HEX. SOCKET HEAD 3 M3X8
41 91312-03008 BOLT HEX. SOCKET HEAD 4 M3X7
42 90990-11J003 SCREW, PAN HEAD W/W 16
43 $NK-3N NYLON CLIP 12
