YSM40_PartList - 第90页
1 13 Exterior , etc. 1 Exterior , etc. KLF-1308 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KLF-M4899-20 LIGHT 1 ASSY 1 L=1850 mm R.Y .G. KLF-M4899-30 LIGHT 1 ASSY 1 L=1900 mm R.Y .G. KLF-M4899-…
1
12
Controller
Controller
KLF-1308
15
4
5
5
4
11
10
14
6
7
8
12
12
3
3
2
2
1
1
12
8
13
12
9
9
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLA-M5840-02 SERVO BOARD ASSY 1
2 KLA-M5840-12 SERVO BOARD ASSY 1
3 KLA-M5880-02 D.POWER UNIT ASSY 1
4 KLA-M11B0-01 LABEL,CONTROLLER 1
5 90K41-001390 LABEL,WARNING 1
6 KLA-M4209-70 SYSTEM UNIT ASSY 1
7
KLA-M4530-00 REMOTE IF BOARD ASSY 1 YSM40-4
KLA-M4530-10 REMOTE IF BOARD ASSY 1 YSM40-2
8 KHL-M441H-03 VISION BOARD ASSY 2
9 KLA-M4510-01 MOTHER BOARD ASSY 2
10 KLA-M4250-01 BACKPLANE BOARD ASSY 1
11 KLA-M4262-00 LABEL,CONTROLLER 1
12 97602-04308 SCREW,PAN HEAD W/W 12
13 90116-12JA10 SCREW,PAN HEAD W/W 2
14 90K41-001630 LABEL,CAUTION 1
15 KLA-M4255-10 FLASH DISK 4G 1
1
13
Exterior, etc. 1
Exterior, etc.
KLF-1308
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KLF-M4899-20 LIGHT 1 ASSY 1 L=1850 mm R.Y.G.
KLF-M4899-30 LIGHT 1 ASSY 1 L=1900 mm R.Y.G.
KLF-M4899-40 LIGHT 1 ASSY 1 L=2000 mm R.Y.G.
KLF-M4899-50 LIGHT 1 ASSY 1 L=2100 mm R.Y.G.
KLF-M4899-60 LIGHT 1 ASSY 1 L=2200 mm R.Y.G.
KLF-M4899-70 LIGHT 1 ASSY 1 L=2300 mm R.Y.G.
KLF-M4899-80 LIGHT 1 ASSY 1 L=1850 mm C.G.B.
KLF-M4899-90 LIGHT 1 ASSY 1 L=1900 mm C.G.B
KLF-M4899-A0 LIGHT 1 ASSY 1 L=2000 mm C.G.B
KLF-M4899-B0 LIGHT 1 ASSY 1 L=2100 mm C.G.B
KLF-M4899-C0 LIGHT 1 ASSY 1 L=2200 mm C.G.B
KLF-M4899-D0 LIGHT 1 ASSY 1 L=2300 mm C.G.B
2
KGS-M4896-01 ERROR LIGHT ASSY 2 YAMAHA
KHG-M4896-01 ERROR LIGHT ASSY 2 CE
3 KLF-M669V-00 HNS, SWITCH ACTIVE 2
4 KLF-M669V-20 HNS, SWITCH START 2
5 KLF-M669V-50 HNS, SWITCH RESET 2
6 KGK-M5381-00 EMG PLATE 2
7 KLF-M3992-00 SWITCH, SELECT 2
8 KLF-M669V-10 HNS, SWITCH READY 2
9
KLF-M669V-30 HNS, SWITCH STOP 2 YAMAHA
KLF-M669V-60 HNS, SWITCH STOP 2 CE
10
KLF-M669V-40 HNS, SWITCH ERR, CLR. 2 YAMAHA
KLF-M669V-70 HNS, SWITCH ERR, CLR. 2 CE
11 KLF-M5138-00 SWITCH, EMG SET 2
12 KLF-M6555-A0 LANE SELECT ASSY 2
13 KKX-M8596-A0 PRESSURE GAUGE 1
14 KLF-M8596-A0 PRESSURE GAUGE 1
15 KLC-M6554-00 MAIN SWITCH 1
16
KLF-M5150-20 KEYBOARD/PAD E 1 OK MNY0045-2016/12/19
KLF-M5150-B0
KEYBOARD/BALL E 1 NG MN50060-2016/5/23
KLF-M5150-110 KEYBOARD/PAD E 1 Fig 2 NG MK10106-2013/1/24
KLF-M5150-10 KEYBOARD/MOUSE E 1 Fig 1
17
KLF-M5119-01 TOUCH LCD ASSY 2 NG H017662-2013/1/11
KLF-M5119-00 TOUCH LCD ASSY 2
18 KLF-M516A-00 TOUCH PEN 2
19 KLF-M138H-00 BRACKET 1 2
20 KHM-M9939-00 GROMET 2
21
KLF-M138J-01 BALL CHAIN 2 OK MK10063-2013/1/23
KLF-M138J-00 BALL CHAIN 2
22 KLF-M138K-00 RING 4
1
17
3
8
18
19,20,21,22
9
10
14
13
6
12
4
5
11
16
7
2
15
OLD
16
16
Fig 1
Fig 2
2
13
Exterior, etc. 2
Exterior, etc.
KLF-1308
5
6
12
11
7
8
22
16
17 18 19
3
1
2
20
13
14
15
21
10
9
4
9
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M6511-10 MAIN BREAKER,1 1
2 KM8-M539M-10 PROTECTOR ACCESSARY 1
3 KHN-M643A-00 TERMINAL,POWER 4
4
KHA-M6513-01 CIRCUIT PROTECTOR,1P 2 OK MJ00200-2012/10/23
KHA-M6513-01 CIRCUIT PROTECTOR,1P 4
5 KHA-M6514-20 CIRCUIT PROTECTOR,4_ 1
6 KHN-M653E-00 BREAKER,1 2
7
KH4-M6515-31 CIRCUIT PROTECTOR,2P 1 4-Beam
KHN-M653E-00 BREAKER,1 1 2-Beam
8 KKE-M6513-00 CIRCUIT PROTECTOR,1P 1
9 KHN-M6513-21 CIRCUIT PROTECTOR,1P 2
10
KLF-M6513-00 CIRCUIT PROTECTOR,1P 2 NG MJ00213-2012/10/29
KHN-M6513-11 CIRCUIT PROTECTOR,1P 2
11 KH1-M539M-41 PROTECTOR ACCES.1P 9
12 KH1-M539M-31 PROTECTOR ACCES.2P 1
13 KHN-M6513-01 CIRCUIT PROTECTOR,1P 1
14 KH1-M539M-41 PROTECTOR ACCES.1P 1
15 KLF-M537F-00 SAFETY RELAY 1
16 KLF-M4580-00 I/O CONV.BOARD ASSY 1
17 KHN-M6561-00 POWER SUPPLY 1 1
18 KLF-M6561-00 POWER SUPPLY 1 1
19 KKE-M6561-10 POWER SUPPLY 1 1
20 KLF-M91E2-A0 CONV.CONT.BOX SET 1
21 KLA-M459X-00 BATT UNIT ASSY 2
22 KKX-M6513-00 CIRCUIT PROTECTOR,1P 2 OK MJ00200-2012/10/23
