Station Software 708.1 SP2 / Version Description Ausgabe 10/2015 Edition

708.1 SP1 Station Software Version

The 708.1 SP1 station software version contains all error corrections of the previous 701.xx –

708.1 versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-110371401 A nozzle got lost from the C&P20 P placement head during production but no

error message was displayed.

D1-112147342 The tape pocket measurement was too sensitive to lead deviations.

D1-112994843 Sporadically, the unknown HW error 0xF1 (DP axis) error message

was displayed.

D1-113336101 Some Reference Designators for some panels were missing in the traceability

system.

D1-114567701 Acknowledge of the buzzer was displayed even if the hardware was not

available on the machine.

D1-114583749 CA placement machine: the inspection of the chuck fiducials started although

it was deactivated.

D1-114679621 The software hung up when an error occurred during inkspot recognition.

D1-114940801

D17845-4407

There was no response from the MTC after a pickup error.

D1-115259384 After a product changeover, an unknown placement state (40020) was

reported endlessly for one component.

D1-115338650 Pitch too small error message was not reset after the manual correction

of the pitch.

D1-115304849 eSW: when production was continued after pressing the "stop" button and

opening the hood, the machine always executed a reference run.

708.1 HF04

D1-113666801 eSW: the transportation of the board into lane 1 or 2 via button on the GUI

failed if the cable of the advanced PCB interface was disconnected and

reconnected.

D1-114932601 eSW: there was a problem unloading a board if the length was between 930

and 985 mm.

D1-114932653 eSW: the conveyor lane width could not be adjusted because it had been set

too wide.

D1-114963801

D1-114935001

A collision of 2 gantries was reported.

D1-114999701 eSW: vacuum system: 30503 Supply pressure for pressure

control valve is missing

D1-115121901 Temperature compensation was not working correctly with C&P20 P

placement heads.

D1-115135201 eSW: the 3D-coplan module could not be measured. Windows hung up at the

first measurement.

D1-115160309 With HF3 some placement positions were out of the travel range.

Station Software 708.1 SP2 / Version Description Ausgabe 10/2015 Edition

708.1 HF03

D1-110371401 A nozzle from CP20P was lost during production.

D1-114077541 During production the lamp was blinking green. It should be green without

blinking.

D1-114530901 eSW: the communication between station and power supply was interrupted.

No answer from the main distributor for the subsystem.

D1-114557044 The software hung up when the trays were activated in the MTC.

D1-114641601 SX2 with DLM head at production area 2 and outer table: the nozzle changer

could not be configured with this machine configuration.

D1-114690122 When the component fiducial was taught the component shape wass not

visible.

D1-114734343 eSW: there was a transportation problem with boards between 245 and 240

mm length.

D1-114742101 The head could not reject component and not recover from error.

D1-114742141 There was an unhandled exception 30016.

D1-114785791

D1-114773701

D1-114817203

eSW: during production the machine stopped without an error message.

D1-114861301 The saving of the mapping data was improved.

D1-114872601 The tape cutter for gantry 2 wass not working and there was no error

message.

D1-114892301 eSW: machine zero point calibration was not possible.

D17931-3006 Communication problem with IPTE feeder after station software upgrade from

707 to 708.1.

708.1 HF02

D1-111491649 If the machine transferred a board to the next machine an error popped up for

1-2 seconds.

D1-112649181 Component sensor data on CPP could not be saved.

D1-112842103

D1-113896701

The nozzle scan failed if a component stuck on the nozzle.

D1-113386001

D1-113581429

D1-113718801

D1-114617201

D1-114627749

If you opened the cover there was no light in the machine. Update for

machines without cover lock.

D1-113809401 eSW: MGCU was not identified correctly.

D1-113930001 eSW: the application 1 for the Y axis was missing.

D1-113959701 After teaching and saving the placement position the component position had

still an offset.

D1-113970149 Unexpected software malfunction - restart necessary.

Station Software 708.1 SP2 / Version Description Ausgabe 10/2015 Edition

D1-113982801 After the update from 708.0 to 708.1 all existing offset values in "manual

correction" were set to 0.

D1-114074881 After a restart of the machine gantry 1 reported the error that the z axis could

not be moved into a safe position.

D1-114100101

D1-114102501

The calibration of the head and the cameras failed.

D1-114416401 The machine stopped without error message when the height of the tray was

not correct.

D17710-4601 There were sporadic pauses when the head was identifying ink spots.

D17839-6712 Some components of location 2 and location 3 (for CPP head) were omitted.

D17936-3901 eSW: short tape handling in 8mm X feeder could not be activated.

D1-114557001 Sporadically, the error message 40034 CAUTION: Do not move

gantry! Head has lost a nozzle

was displayed.

D1-114422801 Taking out and in a board several times led to an unhandled exception error

when the board fiducials should be checked.

D1-113220101 The hourly performance in SIPLACE Explorer showed a high running time

value for a particular hour, but the PCB count was 0. There was no waiting or

blocked time during this hour.

708.1 HF01

D1-109834623 eSW: it was sporadically possible to change the pitch and the pickup position

on the feeder display although this was locked.

D1-111491609 Machine 2 restarted the station software; machine 1 was still in production.

Board was transferred to machine 2 and cancelled there.

D1-113015101 The machine stopped (because there was a component at the nozzle after

placement), but did not show any error.

D1-113386001

D1-113581429

D1-113718801

If you opened the cover there was no light in the machine.

D1-113392301 Error 40027: Support pin recognition failed.

The calibration did not function because of an error and the support pins could

not be used uncalibrated.

D1-113566601 The software hung up; there was an unhandled exception error on the screen.

D1-113567441

The board was marked as "not placed" in PA1 and PA2 (white circle instead of

green circle).

D1-113581209 Virtual keyboard could not be enabled or disabled anymore.

D1-113581249 After upgrade, the calibration for reference corner was missing.

D1-113632401

If value "0" was entered in the Cameras – test illumination menu (gantry 4

with CPP head and IC camera), the software hung up.

D1-113649001

D1-113815401

D1-113839049

The number of the gantry or of the table insert was not shown within the

machine configuration.

D1-113654101 eSW: the machine referenced the axis after opening the cover.
