MODEL DL-G50
1012-003
41
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
NA-8
701 6301517599 SPACER 2 806NA-210-401 211E1030
702 6301517605 COLLAR 2 806NA-210-402
216A1450
705 6301517513 SHAFT 4 806NA-210-325
213A1406
706 6300011388 BEARING,RADIAL 8 806NA-210-326
222D0017
707 6301524726 BLOCK 1 806NA-210-405
211G5034
708 6301524733 BLOCK 1 806NA-210-406
211G5035
709 6301524740 BLOCK 1 806NA-210-407
211G5036
710 6301524757 BLOCK 1 806NA-210-408
211G5037
711 6301521220 PULLEY,TIMING 8 806NA-210-409
223Q0696
712 6301517315 PLATE 1 806NA-210-212
211DC327
713 6301237145 SENSOR,PELEC 1 -B4401
806NR-110-110 23G00243
714 6300011418 BEARING,RADIAL 2 806NA-210-214
222D0020
715 6301479088 GUIDE,SLIDE 1 806NA-210-215
222C0125
716 6301513881 PLATE 2 806NR-1
10-115 211DC279
717 6301522630 BLOCK 1 806NR-1
10-116 211G5022
718 6301522647 BLOCK 1 806NR-1
10-118 211G5023
719 6301489209 COLLAR 2 806NR-1
10-034 216A1414
720 6301527598 BRACKET 1 806NA-210-220
211FB723
721 6301241340 MOTOR,AC-SERVO 1 -M43
806NA-210-221 4M150196
722 6301486758 BRACKET 1 806NA-210-222
211FB174
723 6301521206 PULLEY,TIMING 1 806NA-210-223
223Q0694
724 6301521190 PULLEY,TIMING 1 806NA-210-224
223Q0693
725 6301487717 BELT,TIMING 1 806NA-210-225
223L0332
728 6301517377 BRACKET 2 806NA-210-228
211FB530
729 6301480633 PULLEY,FLAT 2 806NA-210-229
223M0055
730 6300765731 BEARING,RADIAL 4 806NA-210-230
222D0298
731 4110007805 RING C 20 2 806NA-210-231
221K0084
732 6300011371 BEARING,RADIAL 4 806NA-210-232
222D0016
733 6301521282 PULLEY,TIMING 2 806NA-210-233
223Q0699
734 6301236780 BELT,TIMING 2 806NA-210-234
223L0261
735 6301527611 BRACKET 1 806NA-210-235
211FB725
736 6301527963 COLLAR 1 806NA-210-236
216A1466
738 6301673974 CYLINDER 1 806NA-210-418
224C0617
739 6301465258 BLOCK 1 806NA-210-419
211G4605
740 6300465556 PIPE FITTINGS 1 806NA-210-420
225F0253
741 6300484656 PIPE FITTINGS 1 806NA-210-421
225F0261
742 6301522647 BLOCK 1 806NL-210-1
18 211G5023
743 6301498287 BRACKET 1 806NA-210-413
211FB305
744 6301498270 BRACKET 1 806NA-210-414
211FB304
745 6301481760 BELT,TIMING 2 806NA-210-415
223L0327
746 6301517797 BRACKET 1 806NA-210-426
211FB540
747 6301513881 PLATE 2 806NL-210-1
15 211DC279
748 6301522630 BLOCK 1 806NL-210-1
16 211G5022
749 6301489209 COLLAR 2 806NL-210-034
216A1414
750 6301237145 SENSOR,PELEC 1 -B4102
806NL-210-110 23G00243
751 6301512549 BOLT,HEX-SCT 4 M2.5X25
221A0370
752 6300007510 BOLT,HEX-SCT 2 M3X8
221A0006
753 6300007602 BOLT,HEX-SCT 4 M4X6
221A0015
754 6300007626 BOLT,HEX-SCT 6 M4X10
221A0017
755 6300007633 BOLT,HEX-SCT 2 M4X12
221A0018
MODEL DL-G50
1012-003
42
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
NA-8
756 6300007671 BOLT,HEX-SCT 2 M4X25 221A0022
758 6300007756 BOLT,HEX-SCT 6 M5X12
221A0030
759 6300007763 BOLT,HEX-SCT 4 M5X16
221A0031
760 6300007770 BOLT,HEX-SCT 12 M5X20
221A0032
761 4110511708 SCR TRS 4X6 4 M4X6
TRS 221E0532
762 6300082296 SET SCREW 2 M4X4 SET
221C0027
763 6300008937 SET SCREW 2 M4X12 SET
221C0006
764 4111409905 NUT HEX 3 2 M3
221F0079
765 4111410307 NUT HEX 4 2 M4
221F0082
766 4111416606 WASHER SPR 2.5 4 SW2.5
221H0279
767 4111412806 WASHER SPR 3 2 SW3
221H0281
768 4111412905 WASHER SPR 4 14 SW4
221H0284
769 4111416705 WASHER SPR 5 26 SW5
221H0287
770 4111413001 WASHER SPR 6 8 SW6
221H0289
771 4111413803 WASHER V 2.5X6.5X0.5 4 FW2.5
221H0310
772 4111415807 WASHER F 3X6X0.5 2 FWS3
221H0338
774 4111415906 WASHER F 4X8X0.8 4 FWS4
221H0340
775 4111414008 WASHER V 4X9X0.8 10 FW4
221H0315
776 4111414107 WASHER V 5X10X1 24 FW5
221H0318
777 6300010220 WASHER 2 BW5
221H0005
778 6300007794 BOLT,HEX-SCT 4 M5X30
221A0034
779 4111414305 WASHER V 6X12.5X1.6 8 FW6
221H0320
780 6300007893 BOLT,HEX-SCT 8 M6X20
221A0044
