Troubleshoo ting • Hidden slide – see not es page Issue 2: July 2007
Event Log Analysis
•
A good troubleshooting tool
•
Check for error messages
•
Check knowledge base for error code
Issue 2: July 2007
•
Check knowledge base for error code
definitions
•
Check what happened leading up to the
problem
Objective 17: Complete activities in your workbook
Troubleshooting
•
Hidden slide – see notes page
Issue 2: July 2007
Pneumatics
•
The Pneumatic module consists of the following
sub-assemblies:
– Solenoid bank at rear
Issue 2: July 2007
– Solenoid bank on print carriage
– Regulators
• Mains input
• Chase clamp
• Board clamp
• Paste dispenser
• Snuggers
– Mains pressure sensor
