Nodes List the nodes in the orde r they appear in the CAN bus chai n Node __ Nextmove ES Node __ Node __ Node __ Node __ Issue 2: July 2007 Objective 15: Complete details in workbook Node __ Main Machine I/O Node __ Node…

Servo / Stepper Motor nodes

•

Servo node 6 – Rising Table*

Issue 2: July 2007

* Either separate BG9010 or integral node depending on motor type

•

Servo node 6 – Rising Table*

•

Servo node 7 – Print Carriage

•

Servo node 8 - Camera X (rotary only)

•

Servo node 9 - Camera Y (rotary only)

•

Stepper node 10 – Paste dispense (option)

•

Servo Node 11 – Board stop node (RTC)

•

Stepper Node 12 – Moving Rail (RTC)

•

Servo Node 13 – Paste Management for ‘Big Red’

Nodes

List the nodes in the order they appear in the CAN bus chain

Node __ Nextmove ES

Node __

Issue 2: July 2007

Objective 15: Complete details in workbook

Node __ Main Machine I/O

Node __

Nodes

List the nodes in the order they appear in the CAN bus chain

Node 1 Nextmove ES

Node 6 Rising Table

Node 10 Paste Dispenser (optional)

Node 3 Print Carriage I/O

Node 7 Print Carriage Motor

Issue 2: July 2007

Node 2 Main Machine I/O

Node 11 Board Load Motor (RTC, optional)

Node 12 Rail Width Stepper (RTC, optional)

Node 4 Screen Clean I/O (optional)

Node 9 Camera Y Motor (710, optional)

Node 8 Camera X Motor (710, optional)
