64 Technical Data Maneuvering Radii for MTC Maneuvering radius R 900 mm Distance L1: Machine center to outer edge of MTC 1938 mm Distance L2: Machine center to wall 2838 mm
63
Technical Data
Maneuvering Radii for the X Component Trolleys
SIPLACE SIPLACE X-Series
Maneuvering radius R 600 mm
Distance L1: Machine center to outer edge of X component
trolley
1470 mm
Distance L2: Machine center to wall 2070 mm
64
Technical Data
Maneuvering Radii for MTC
Maneuvering radius R 900 mm
Distance L1: Machine center to outer edge of MTC 1938 mm
Distance L2: Machine center to wall 2838 mm
65
Technical Data
Spacing Distances for Single Conveyor
Fixed conveyor side at maxi-
mum right position
a
.
a) The value depends on the position of the fixed side. All dimensions in millimeters.
Fixed conveyor side at maximum left
position
a
.
