158 MODEL TIM-5200F/R 0307-001 ドライバ部 DRIVER SECTION Fig. BD-2 ドライバＡパネルレイアウト Driver A Panel Layout A 171 171 159 167 165 171 143 142 141 157 174 143 142 141 157 168 . 170 163 162 151 169 164 166 153 152 . 170 153 154 161 …
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
157
MODEL TIM-5200F/R
0307-001
BD-1
15 630 001 0220 WASHER 6 BW5
17 411 141 6705 WASHER SPR 5 6 SW5
19 630 000 7756 BOLT,HEX-SCT 6 M5X12
36 411 119 1909 WASHER V 3X7X0.5 6 FW3 F
37 411 086 4408 WASHER SPR 3 6 SW3 F
38 411 113 0809 SCR PAN 3X25 6 M3X25 PAN
41 411 119 2104 WASHER V 4X9X0.8 2 FW4F
42 411 008 1706 WASHER SPR 4 2 SW4F
43 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
46 411 088 1702 WASHER V 5X10X1 17 FW5 F
47 411 008 2109 WASHER SPR 5 17 SW5 F
48 411 043 6803 SCR PAN 5X12 17 M5X12 PAN
51 630 119 8927 UNIT,DRIVER 1 -ASMD02(YA),SGDM-20ADA-R
805BD-010-051
52 630 119 8910 UNIT,DRIVER 1 -ASMD01(XA),SGDM-08ADA-R
805BD-010-052
53 630 119 8934 UNIT,DRIVER 2 -ASMD11(LA1),-ASMD12(LA2),
SGDM-01ADA-R 805BD-010-053
54 630 120 0231 P.C.B,MOUNT 3 UB10*003*0000
61 630 119 8941 UNIT,DRIVER 1 -ASMD21(BPC),SGDM-02ADA-R
805BD-010-158
62 402 083 5505 WIRE WOUND 25 KA 220W 1 R200 805BD-010-162
71 630 120 1801 BRACKET 1 805BD-010-071
72 630 120 1818 BRACKET 1 805BD-010-072
73 630 122 6484 PLATE 1 805BD-010-252
91 630 121 5716 WIRE PARTS 9 805BD-010-255
92 630 121 4184 WIRE PARTS(CLAMP) 1 805BD-010-256
96 411 114 7807 SCR PAN+SW+W 4X10 21
158
MODEL TIM-5200F/R
0307-001
ドライバ部 DRIVER SECTION
Fig. BD-2 ドライバＡパネルレイアウト Driver A Panel Layout
A
171
171
159
167
165
171
143
142
141
157
174
143
142
141
157
168
.
170
163
162
151
169
164
166
153
152
.
170
153
154
161
See Fig.B-1
Key No.1
118
117
116
A
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
159
MODEL TIM-5200F/R
0307-001
BD-2
116 630 001 0220 WASHER 3 BW5
117 411 141 6705 WASHER SPR 5 3 SW5
118 630 000 7756 BOLT,HEX-SCT 3 M5X12
141 411 119 2104 WASHER V 4X9X0.8 6 FW4 F
142 411 008 1706 WASHER SPR 4 6 SW4 F
143 411 043 5004 SCR PAN 4X8 6 M4X8 PAN
151 630 083 5472 TERMINAL 4 805BD-010-151
152 630 083 5519 ACCESSORY,WIRING 1 805BD-010-152
153 630 049 3672 BRACKET,WIRING 2 805BD-010-153
154 630 083 5564 ACCESSORY,WIRING 1 805BD-010-154
157 630 089 6732 RAIL,WIRING 2 805BD-010-157
159 630 119 2277 CIRCUIT PROTECTOR 1 Q351A 805BD-010-159
161 630 114 7772 COVER 1 805BD-010-161
162 630 071 3343 COVER 2 805BD-010-062
163 630 071 3350 COVER 2 805BD-010-063
164 630 108 3520 CIRCUIT PROTECTOR 1 Q302A 805BD-010-061
165 630 119 6480 CIRCUIT PROTECTOR 1 Q311 805BD-010-055
166 630 106 7193 CIRCUIT PROTECTOR 1 Q301A 805BD-010-056
167 630 119 2260 CIRCUIT PROTECTOR 2 Q303A,Q304A 805BD-010-057
168 630 114 7734 EM-CONTACTOR 1 KM115A 805BD-010-058
169 630 053 8588 EM-CONTACTOR 3 KM103A,KM104A,KM151A
805BD-010-059
170 630 100 1357 COMP,CR 4 805BD-010-060
171 630 000 1051 BRACKET,WIRING 3 805BD-010-251
174 630 120 1900 PANEL 1 805BD-010-074
