Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 18 MODEL TIM-5200F/R 0307-001 C-1 1 630 122 2257 PLA TE 2 805C--010-001 2 630 1 17 9377 PLA TE 2 805C--010-002 3 630 068 9662 HOLDER 2 805C--010-003 4 630 082 3875 BRACKE…
17
MODEL TIM-5200F/R
0307-001
Sheet-2
2 ビーム XY 部 2-BEAM XY SECTION
Fig. C-1 Y 軸部 Y Axis Section
46
36
38
46
73
74
75
37
35
75
35
46
74
73
46
31
42
42
31
81
82
81
82
86
37
78
77
76
38
97
40
39
41
39
50
45
40
97
43
87
88
89
61
59
58
71
69
68
84
82
81
29
12
83
82
81
71
69
68
29
31
10
84
82
81
29
71
69
68
31
11
84
82
81
29
71
69
68
31
75
74
73
44
61
59
58
42
31
45
39
50
76
77
39
41
40
43
97
47
31
42
81
82
86
81
82
86
87
88
89
40
97
98
12
31
71
59
68
84
82
81
29
11
31
71
69
68
83
82
81
29
10
31
73
74
75
36
98
See Fig.B-1
Key No.2
See Fig.B-1
Key No.3
44
47
78
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
18
MODEL TIM-5200F/R
0307-001
C-1
1 630 122 2257 PLATE 2 805C--010-001
2 630 117 9377 PLATE 2 805C--010-002
3 630 068 9662 HOLDER 2 805C--010-003
4 630 082 3875 BRACKET,LOCATE 2 805C--010-004
5 630 068 4674 PLATE 2 805C--010-005
6 630 068 4681 BLOCK 2 805C--010-006
7 630 068 4650 COLLAR 4 805C--010-007
8 630 068 4667 COLLAR 4 805C--010-008
9 630 120 8718 PLATE 2 805C--010-009
10 630 084 3781 PLATE 2 805C--010-010
12 630 086 8234 PLATE 4 805C--010-012
13 630 120 1115 PLATE 1 805C--010-013
14 630 084 3828 PLATE 1 805C--010-014
15 630 119 4899 BLOCK 4 805C--010-015
16 630 074 9069 BLOCK 2 805C--010-016
17 630 117 9384 BRACKET 4 805C--010-017
18 630 117 9391 BLOCK 4 805C--010-018
19 630 084 3750 BRACKET 1 805C--010-019
21 630 083 5762 GUIDE,LINEAR 1 805C--010-021
22 630 120 6097 BALL SCREW 2 805C--010-022
24 630 069 0576 BEARING,RADIAL 2 7204ATYDBC8P5,PS2S
805C--010-024
25 630 069 0590 SEAL 4 805C--010-025
26 630 069 0583 BEARING,PARTS(LOCK NUT) 2 WBK20L-01 805C--010-026
27 630 069 0453 COUPLING 2 805C--010-027
28 630 120 0736 MOTOR,AC-SERVO 2 -MSVM02(YA),(YB),SGMSH-20ACA21
805C--010-028
29 630 069 0545 SENSOR,PHOTO 6 -BPH021(YA),(YB),-BPH022(YA),(YB),
-BPH023(YA),(YB),EE-SX674
805C--010-029
30 630 000 0252 SENSOR,PHOTO 1 -BPH027,EE-SX671 805C--010-030
31 630 000 0269 SENSOR,PHOTO(CONNECTOR) 11 805C--010-031
34 630 069 0637 PIN,LOCATE 2 805C--010-034
35 630 070 9292 CYLINDER 2 805C--010-035
36 630 070 9315 CYLINDER(JOINT) 2 805C--010-036
37 630 003 5193 AIR LINE EQPT 4 805C--010-037
38 630 070 9308 VALVE 2 YSV01A,01B,YSV02A,02B
805C--010-038
39 630 003 6534 AIR LINE EQPT 4 805C--010-039
40 630 006 8795 BEARING,RADIAL 4 6202ZZ 805C--010-040
41 630 070 9285 WASHER 4 805C--010-041
42 630 000 0245 SENSOR,PHOTO 4 BPH028,BPH029,BPH030,BPH031,
EE-SX670 805C--010-042
43 630 120 3195 BLOCK 2 805C--010-043
44 630 070 9360 LEVER 2 805C--010-044
45 630 070 9339 SHAFT 2 805C--010-045
46 630 082 3660 PLATE 2 805C--010-046
47 630 117 9476 PLATE 2 805C--010-047
48 630 122 1090 BOLT 4 805C--010-048
49 630 073 0197 BOLT 4 805C--010-049
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
19
MODEL TIM-5200F/R
0307-001
C-1
51 411 141 5203 WASHER V 16X30X3 16 FW16
52 411 141 3407 WASHER SPR 16 16 SW16
53 630 000 8364 BOLT,HEX-SCT 8 M16X100
54 630 000 8357 BOLT,HEX-SCT 8 M16X80
55 411 141 4800 WASHER V 12X24X2.5 4 FW12
56 411 141 3308 WASHER SPR 12 4 SW12
57 630 000 8227 BOLT,HEX-SCT 4 M12X30
58 411 141 4701 WASHER V 10X21X2 20 FW10
59 411 141 3209 WASHER SPR 10 20 SW10
60 630 000 8173 BOLT,HEX-SCT 4 M10X60
61 630 000 8166 BOLT,HEX-SCT 8 M10X50
62 630 000 8142 BOLT,HEX-SCT 8 M10X35
63 411 141 4305 WASHER V 6X12.5X1.6 64 FW6
64 411 141 3001 WASHER SPR 6 64 SW6
65 630 000 7909 BOLT,HEX-SCT 16 M6X25
66 630 000 7893 BOLT,HEX-SCT 64 M6X20
67 630 000 7886 BOLT,HEX-SCT 48 M6X16
68 411 141 4107 WASHER V 5X10X1 20 FW5
69 411 141 6705 WASHER SPR 5 28 SW5
70 630 000 7770 BOLT,HEX-SCT 8 M5X20
71 630 000 7763 BOLT,HEX-SCT 14 M5X16
72 630 000 7756 BOLT,HEX-SCT 6 M5X12
73 411 141 4008 WASHER V 4X9X0.8 8 FW4
74 411 141 2905 WASHER SPR 4 8 SW4
75 630 000 7664 BOLT,HEX-SCT 8 M4X20
76 411 141 3902 WASHER V 3X7X0.5 4 FW3
77 411 141 2806 WASHER SPR 3 4 SW3
78 630 000 7565 BOLT,HEX-SCT 4 M3X20
81 411 119 1909 WASHER V 3X7X0.5 22 FW3 F
82 411 086 4408 WASHER SPR 3 22 SW3 F
83 411 041 8908 SCR PAN 3X6 4 M3X6 PAN
84 411 042 0703 SCR PAN 3X8 8 M3X8 PAN
85 411 040 7803 SCR PAN 3X12 2 M3X12 PAN
86 411 040 6202 SCR PAN 3X10 8 M3X10 PAN
87 411 088 1702 WASHER V 5X10X1 4 FW5 F
88 411 008 2109 WASHER SPR 5 4 SW5 F
89 411 140 4900 BOLT HEX 5X12 4 M5X12 HEX
90 411 141 4602 WASHER V 10X21X2 4 FW10 F
91 411 086 0103 WASHER SPR 10 4 SW10 F
92 630 000 8791 BOLT,HEX 4 M10X40 HEX
93 630 000 8784 BOLT,HEX 2 M10X30 HEX
97 411 051 1708 SCR TRS 4X6 8 M4X6 TRS
98 630 000 8999 SET SCREW 2 M6X16 SET
99 630 000 8920 SET SCREW 8 M4X6 SET
