32 MODEL TIM-5200F/R 0307-001 ノズルストッカ部 NOZZLE ST OCKER SECTION Fig. F-1 ノズルスッカ Nozzle Stocker 68 67 66 80 30 14 77 76 29 73 72 71 73 72 71 74 72 71 16 16 24 1 18 78 77 76 80 77 76 27 73 72 76 77 78 13 76 77 7 78 71 73 72…
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
31
MODEL TIM-5200F/R
0307-001
E-1
1 630 122 1984 PLATE 1 805B--010-510
5 630 056 9070 VACUUM PUMP 1 M1,#3-040437-2 805E--010-005
5 -10 630 031 8593 AIR LINE EQPT(FILTER) 1 #3-037940
5 -11 630 012 1230 AIR LINE EQPT(FLT ELEM) 1 #XB401379743 4-410A302-4
5 -20 630 055 2171 VACUUM PARTS 1 #4-400A302-1
6 630 003 6787 MECH PARTS(RUBBER DAMPER) 4 805E--010-006
8 630 034 9290 PIPE FITTINGS 1 805E--010-008
9 630 058 4752 PIPE FITTINGS 1 805E--010-009
10 630 058 4738 PIPE FITTINGS 1 805E--010-010
11 630 055 3437 NAME PLATE,PARTS 1 805E--010-011
12 630 001 0220 WASHER 2 805E--010-012
13 630 003 8224 PIPE FITTINGS 4 805E--010-013
14 630 003 8231 PIPE FITTINGS 1 805E--010-014
15 630 003 8248 PIPE FITTINGS 1 805E--010-015
16 630 003 8088 PIPE FITTINGS 1
17 630 003 8187 PIPE FITTINGS 1
18 630 003 7845 PIPE FITTINGS 1
19 630 003 8187 PIPE FITTINGS 1
20 630 003 8033 PIPE FITTINGS 1
21 630 003 7388 PIPE FITTINGS 1
56 411 141 4503 WASHER V 8X17X1.6 4 FW8
57 411 141 3100 WASHER SPR 8 4 SW8
58 411 141 0901 NUT HEX 8 4 M8
61 411 141 4305 WASHER V 6X12.5X1.6 8 FW6
62 411 141 3001 WASHER SPR 6 8 SW6
63 630 000 7879 BOLT,HEX-SCT 8 M6X12
66 411 141 4107 WASHER V 5X10X1 4 FW5
67 411 141 6705 WASHER SPR 5 4 SW5
68 630 000 7749 BOLT,HEX-SCT 4 M5X10
32
MODEL TIM-5200F/R
0307-001
ノズルストッカ部 NOZZLE STOCKER SECTION
Fig. F-1 ノズルスッカ Nozzle Stocker
68
67
66
80
30
14
77
76
29
73
72
71
73
72
71
74
72
71
16
16
24
1
18
78
77
76
80
77
76
27
73
72
76
77
78
13
76
77
7
78
71
73
72
71
13
73
72
71
26
73
10
81
79
81
79
72
71
25
28
17
68
67
66
7
73
72
71
11
22
61
62
63
15
15
12
2
71
72
74
71
12
11
2
72
73
79
77
76
88
87
86
6
66
66
67
69
21
68
67
5
66
69
67
8
1
70
67
66
63
62
31
61
61
63
62
19
4
3
20
38
33
32
23
82
VACUUM NOZZLE
78
77
76
73
72
71
34
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
33
MODEL TIM-5200F/R
0307-001
F-1 2 unit/1 machine
1 630 006 9211 BEARING,RADIAL 4 RF-1760ZZ 805F--010-001
2 630 001 1838 BEARING,RADIAL 2 R-1240ZZ 805F--010-002
3 630 069 8183 CYLINDER 1 805F--010-003
4 630 003 5162 AIR LINE EQPT 2 805F--010-004
5 630 000 0245 SENSOR,PHOTO 2 -BPH062(A1),(B1),-BPH063(A1),(B1),
EE-SX670 805F--010-005
6 630 000 0269 SENSOR,PHOTO(CONNECTOR) 2 805F--010-006
7 630 069 8220 SENSOR,PELEC 1 -BPH061(A1),(B1) 805F--010-007
8 630 069 8237 SENSOR,PELEC 1 -BPH061(A1),(B1) Amp
805F--010-008
10 630 002 9260 SPRING,TENSION 1 6673 805F--010-010
11 630 071 2292 BOLT,HEX 2 805F--010-011
12 630 069 7810 COLLAR 2 805F--010-012
13 630 120 2013 BRACKET 2 805F--010-013
14 630 120 1993 PLATE 1 805F--010-014
15 630 118 2704 LEVER(L) 2 805F--010-015
16 630 118 2711 LEVER(R) 2 805F--010-016
17 630 120 2020 SHAFT 2 805F--010-017
18 630 082 1727 PLATE 1 805F--010-018
19 630 082 1734 PLATE 1 805F--010-019
20 630 069 7551 PLATE 1 805F--010-020
21 630 120 2228 BRACKET 1 805F--010-021
22 630 122 1236 SUPPORT 1 805F--010-022
23 630 122 1229 PLATE 1 805F--010-023
24 630 122 1335 SUPPORT 1 805F--010-024
25 630 120 1979 COVER 1 805F--010-025
26 630 122 0840 PLATE 1 805F--010-026
27 630 073 8704 PLATE 1 805F--010-027
28 630 076 5076 NAME PLATE,INDEX 1 805F--010-028
29 630 078 4640 PLATE 1 805F--010-029
30 630 120 2006 PLATE 1 805F--010-030
31 630 070 9308 VALVE 1 -YSV12A,12B(A1),(B1)
805F--010-031
32 630 003 6534 AIR LINE EQPT 2 805F--010-032
33 630 003 7265 PIPE FITTINGS 1 805F--010-033
34 630 122 0833 PLATE 1 805F--010-101
38 630 120 2235 BRACKET 1 805F--010-028
61 411 141 4305 WASHER V 6X12.5X1.6 8 FW6
62 411 141 3001 WASHER SPR 6 8 SW6
63 630 000 7909 BOLT,HEX-SCT 8 M6X25
66 411 141 4107 WASHER V 5X10X1 11 FW5
67 411 141 6705 WASHER SPR 5 11 SW5
68 630 000 7770 BOLT,HEX-SCT 6 M5X20
69 630 000 7763 BOLT,HEX-SCT 4 M5X16
70 630 000 7756 BOLT,HEX-SCT 1 M5X12
71 411 141 4008 WASHER V 4X9X0.8 18 FW4
72 411 141 2905 WASHER SPR 4 18 SW4
73 630 000 7626 BOLT,HEX-SCT 16 M4X10
74 630 000 7657 BOLT,HEX-SCT 2 M4X16
76 411 141 3902 WASHER V 3X7X0.5 14 FW3
