Version 1 Page 15 / 16 22.11.2021 Pos. Item no. Description Part marking 62 03047489S01 CHANGE FILTER FE 50 WEAR PART 63 00805499-01 CABLE CLIP 64 03012691-01 ISO 7380-M3 X 6-10.9 VERZ.,SCHW.CHROM. STANDARD PARTS 0304917…
Version 1
Page 14 / 16 22.11.2021
Pos. Item no. Description Part marking
33 00352833S10 HEAD-MAINBOARD P+P-HEAD SPARE PART
34 03029034S01 TRICK A. FEATHER UNIT/P+PMODUL SPARE PART
35 03014683-02 DP-UNIT P+P-MODUL
36 03028164-01 SPLINE RECEIVING BUSH /
P&P.MODULE
37 03028144-01 DUAL BEARING WASHER / P&P-
MODULE
38 03028253-01 COUNTERNUT / P&P-MODULE
39 03028291-01 STOP BUSH / P&P-MODULE
40 03025370-01 CRESCENT RING H5-BLS
41 03020699-01 BALL LOCK INTERFACE ZSB /THK
TWIN HEAD
42 00303193-01 DIN912-M3 X 8-A2-70
43 03022652-01 DIN 6912-M4 X 14-A2-50
44 00317136-01 DIN912-M2,5 X 14-A2-70
45 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
46 00318495-01 DIN 7984-M3 X 6-A2
47 00319542-01 DIN 913 - M 2 X 6-A2
48 03012783S02 POWER MEASUREMENT UNIT TWIN
HEAD
SPARE PART
49 00352809-05 FORCE MEASURING BOARD P&P
HEAD
50 03000100-01 FORCE TRANSDUCER MAX. 75N
51 03007542-02 FORCE TRANSDUCER, METAL-
PLASTIC COMBINATION
52 03004579-02 PRESSURE PIECE FOR SENSOR P &
P HEAD
53 00095311-01 DIN 965-M4 X 8-8.8, CU+NI-PLATED
54 03005819-01 ADJUSTMENT WEDGE
55 03045624-01 MOUNT TUBE
56 03046416S01 SILICON HOSE 4,5X2,5X96
57 03046203S01 SILICON HOSE 4,5X2,5X26
58 03045637-01 PIPE BEND
59 03050783-01 FLY WHEEL / DP-UNIT P+P-MODUL SPARE PART
60 03013039-01 DIN EN ISO 7380-M2,5 X
5-10.9,SCHW.VERZ.
61 03051420S01 AIR FILTER COMPLETE SPARE PART
Version 1
Page 15 / 16 22.11.2021
Pos. Item no. Description Part marking
62 03047489S01 CHANGE FILTER FE 50 WEAR PART
63 00805499-01 CABLE CLIP
64 03012691-01 ISO 7380-M3 X 6-10.9
VERZ.,SCHW.CHROM.
STANDARD PARTS
03049175-01 UPGRADE KIT TWIN HEAD X-SERIES
82 03000902S03 HEADADAPTER P+P SPARE PART
03004100-01 AXIS CONTROL FOR TWIN HEAD
AXES
83 00353446-04 SERVO AMPLIFIER SDS60/1.0Z1-01 SPARE PART
84 00353447S03 SERVO AMPLIFIER SDS60/0,5D1 SPARE PART
85 03004332-01 FLAT RIBBON CABLE SET TWIN SPARE PART
88 03005195-01 CABLE SUPP. HEAD ADAP. P+P /
C+P20 CPLT.
SPARE PART
93 03016339S07 COMPONENTS CAMERA STAT. P+P
(TYPE 33) 55
SPARE PART
94 03003049-03 REJECT BOX P & P HEAD
95 03003047-03 WASTE BOX, TWINHEAD SPARE PART
96 03003048-04 MOUNTING PLATE, WASTE BOX SPARE PART
97 03011722-01 FIXING SET TWIN HEAD AT HF
03006778-01 PIPING TWINHEAD HF-/X-SERIES SPARE PART
99 03006779-01 KÜHLLUFTSCHLAUCH P+P RECHTS
100 03006780-01 COOLING AIR TUBE P & P LEFT SIDE
101 03006777-01 COOLING AIR TUBE X-MOTOR
03004626-01 SPACER BOLT, TYPE B I/A-M3X50-AL-
F28
STANDARD PARTS
00308143-01 CABLE CLIP D=12,5MM H 7P
POLYAMID
00845013-01 CHEESE-HEAD SCREW M3*6 DIN912
00095471-01 DIN 125-A 3.2-140
03010908-01 PLUG QSC-8H
107 03015385-02 HOSE 6X1X200
03006597-02 CABLE: HF VISION FLASH SPARE PART
110 03022077-01 CAUL FOR MARK COMPLETE L600 SPARE PART
03050239-01 CAN-BUS: IC CAMERA SPARE PART
03011719-01 SEALING, HEAD MOUNT PLATE / TH *
03019633-01 NOZZLE SET TWIN-HEAD WEAR PART
03011583-02 NOZZLE ADAPTER COMPL./ WEAR PART
