Chap ter 2 Inspe ction It ems fo r Main t e nanc e Multi -Func tional Placer SM482PLUS Maintenance Handbo ok 2-1 Daily Inspections Che ck-up List Maint enance Cycl e Referen ce Time requ ired Per iod No Inspe ction Item …
MEMO
Multi-Functional Placer
SM482PLUS Maintenance Handbook
1-16
Conditions for Maintenance
Chapter 2
Inspection Items for Maintenance
Multi-Functional Placer
SM482PLUS Maintenance Handbook
2-1
Daily Inspections
Check-up List
Maintenance
Cycle
Reference
Time
required
Period No Inspection Item Measures Tools
Daily
D-1 Nozzle Inspect and clean
Recommended Cleaning solution:
Ethyl alcohol, Air gun, Lubricating oil
for nozzle: Tri-Flow, Spray straw, Bore
through-pin, Ultrasonic cleaner
2 years
After use of the
machine
10 Minutes
D-2 Dump Box Clean
After use of the
machine
5 Minutes
D-3 Feeder, Feeder Base Clean Brush
After use of the
machine
10 Minutes
D-4 Backup Table Clean Ultra fine fiber cloth, Cleaning liquid
After use of the
machine
5 Minutes
D-5 Air Filter Inspect and replace 1 year Frequent inspection 30 Minutes
D-6 Mist Separator Filter Inspect and replace 1 year Frequent inspection 30 Minutes
Setting the replacement period for parts
ㆍ The part inspection and replacement interval shall be set up based on the specified operation environment.
ㆍ If the conditions for operation are poor, the part inspection and replacement interval may be reduced.
ㆍ In the above table, C/S means our designated C/S company or our overseas local agents.
ㆍ Consumables should be purchased for a fee, regardless of the warranty period.
