Chap ter 2 Inspe ction It ems fo r Main t e nanc e Multi -Func tional Placer SM482PLUS Maintenance Handbo ok 2-3 W eekly Inspections Che ck-up List Maint enance Cycl e Referen ce Time requ ired Per iod No Inspe ction Ite…
Chapter 2
Inspection Items for Maintenance
Multi-Functional Placer
SM482PLUS Maintenance Handbook
2-2
Daily Inspections
Inspection Items for Maintenance
Chapter 2
Inspection Items for Maintenance
Multi-Functional Placer
SM482PLUS Maintenance Handbook
2-3
Weekly Inspections
Check-up List
Maintenance
Cycle
Reference
Time
required
Period No Inspection Item Measures Tools
Weekly
W-1 Head Fly Camera Lens Clean Air spray, Ethyl alcohol, Cotton swab 5 Minutes
W-2 Head Mirror Clean
Air spray, Ultra-fine fiber cloth, Ethyl
alcohol
5 Minutes
W-3 Solenoid Valve Inspect and replace 2 years
Contact C/S for
replacement
20 Minutes
W-4 Head Vacuum Filter Inspect and replace 6 months
Contact C/S for
replacement
30 Minutes
Setting the replacement period for parts
ㆍ The part inspection and replacement interval shall be set up based on the specified operation environment.
ㆍ If the conditions for operation are poor, the part inspection and replacement interval may be reduced.
ㆍ In the above table, C/S means our designated C/S company or our overseas local agents.
ㆍ Consumables should be purchased for a fee, regardless of the warranty period.
Weekly Inspections
Chapter 2
Inspection Items for Maintenance
Multi-Functional Placer
SM482PLUS Maintenance Handbook
2-4
Weekly Inspections
Inspection Items for Maintenance
