※ Warnings and cautions for safety
For the safe use of this machine, the label for safety related cautions is attached at
the following position.
Inside of the machine
For more details about the label for cautions about safety, refer to the
Administrator's Guide.
※ Warnings and cautions for safety
Safeguard override key
This is a key switch that can be operated artificially to prevent
the door switch from operating. It should be used limitedly only
when performing initial setting or maintenance of the machine.
Danger
The Safeguard override key switch must be used by the designated
responsible personnel. It must be carefully used for machine operation.
Failure to do so may result in death or serious personal injury if the
operator approached the drive with the safety cover Open.
ㆍ If the key is in ‘I’ direction (3 o’clock) Safeguard override function is turned On.
ㆍ If the key is in ‘O’ direction (12 o’clock) Safeguard override function is turned Off.
SM482PLUS Maintenance Handbook
Table of Contents
Chapter 1
Conditions for Maintenance
Common Working Procedure before Maintenance ..1-1
Common Working Procedure before Maintenance . 1-5
Working Environment and Condition ...................... 1-7
Tools for Maintenance .............................................. 1-9
Chapter 2
Inspection Items for Maintenance
Daily Inspections ........................................................ 2-1
Weekly Inspections....................................................2-3
Monthly Inspections (1/2) .........................................2-5
Monthly Inspections (2/2) .........................................2-7
Chapter 3
Daily Inspection
Checking and cleaning the nozzle ........................... 3-1
Cleaning the Dump Box ...........................................3-5
Cleaning the feeder and feeder base .......................3-6
Cleaning the Backup Table .......................................3-9
Checking and replacing the Air Filter ......................3-11
Checking and replacing the Mist Separator Filter .. 3-13
Multi-Functional Placer
SM482PLUS Maintenance Handbook
Chapter 4
Weekly Inspection
Cleaning the Head Fly Camera Lens ......................... 4-1
Cleaning the Head Mirror ......................................... 4-2
Checking and replacing the Solenod Valve .............. 4-3
Checking and Replacing the Head Vacuum Filter ....4-5
