YHP-2D_mpl_e - 第24页
KJG-1010 Rev . :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering. Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev . Rank Level No. Part…
KJG-1010
8
9
19
15
10
11
7
7
7
7
12
13
14
16
17
18
31
15
20
21
22
2
2
1
1
3
5
7
6
6
4
4
29
27
30
25
26
28
7
32
5
1
4M Head
Head
KJG-1010
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KV7-M8171-00 PLATE, SPLING
16 E
39
2
90115-02J006 BOLT HEX. SOCKET HEAD
8 E
40
3
90K63-001J07 AC SERVO MOTOR
1 B
Í
41
4
KGV-M7148-00 BELT, HEAD R
2 A
Í
42
5
KGV-M711S-A0 STD SHAFT 1, SPARE
1 /
Í
43
6
KGV-M711H-A0 ROLLER LOCK, SPARE
1 E
44
7
91317-03010 BOLT HEX. SOCKET HEAD
24 45
8
90K55-3U07GA AC SERVO MOTOR
1 B
Í
46
9
90K55-3U073B AC SERVO MOTOR
1 B
Í
47
10
90K55-3U07GF AC SERVO MOTOR
1 B
Í
48
11
90K55-3U073S AC SERVO MOTOR
1 B
Í
49
12
KV7-M8159-00 SHAFT, HANDLE
1 /
50
13
KV7-M2256-00 GRIP
1 /
51
14
KGV-M7186-00 COVER 2, HEAD
1 /
52
15
91317-04006 BOLT HEX. SOCKET HEAD
12 53
16
KM1-M7163-30 VALVE
4 B
54
17
KM1-M7163-20 VALVE
4 B
55
18
KGB-M71G2-00 EJECTOR
4
BIT Type
B
56
KGB-M8C04-30 EJEC.SET BIT 4
1
4 SET of parts numbers
B
57
19
$TL10-01 JOINT
1 /
58
20
K46-M8527-C0 FILTER
4 E
59
21
90990-17J010 O-RING
4 E
60
22
KM5-M7174-G0 FILTER CAP
4 /
61
25
KGK-M66F4-00 C. CABLE ASSY: 1. 7M
1 B
Í
62
26
KGV-M71K1-00 COUPLING, CZ MOTOR
1 B
Í
63
27
KGV-M71K3-00 COVER, SCREW CZ
1 /
64
28
90K55-3U0745 AC SERVO MOTOR
1 B
Í
65
29
KV7-M7165-00 SEAL, DON’T TOUCH
1 66
30
91317-04008 BOLT HEX. SOCKET HEAD
4 67
31
KHW-M7162-00 BIT
4
BIT type
E
68
KGB-M8C06-00 BIT SET 4 1
4 SET of parts numbers
E
69
32 KGV-M71G1-00 EJECTOR,RESIN 1 BIT type
/
Í
70
33 71
34 72
35 73
36 74
37 75
38 76
5
1
4M Head
Head
KJG-0911
2
NOZZLE 61A ASSY 31 54 NOZZLE 63A
6
2
NOZZLE 64B ASSYNOZZLE 62A ASSY
6
1
4M Head Nozzle Selection
Nozzle
