KJG-1010 1 2 3 4 5 6 7 8 9 10 1 1 12 13 14 15 16 17 18 19 KV8-M8860-00 KV8-M8883-A0 KV7-M8880-20 KGA-M3801-00 KGA-M3803-00 KV8-M8881-A0 KU4-M8590-00 K48-M3856-00 KV8-M8870-00 K48-M3852-01 K48-M3857-00 K48-M3854-00 KM8-M3…

100%1 / 73
KJG-1011
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KJG-M1780-00 PALLET, FLAT6 ASSY 1 /
39
2 KJG-M1780-10 PALLET, FLAT 8 ASSY 1 /
40
3 41
4 42
5 43
6 44
7 45
8
46
9
47
10
48
11 49
12 50
13 51
14 52
15 53
16 54
17 55
18 56
19
57
20
58
21 59
22 60
23
61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31
69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
15
1
Pallet Assy
Wafer Pallet
KJG-1010
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17 18 19
KV8-M8860-00 KV8-M8883-A0 KV7-M8880-20 KGA-M3801-00 KGA-M3803-00
KV8-M8881-A0 KU4-M8590-00 K48-M3856-00 KV8-M8870-00
K48-M3852-01 K48-M3857-00 K48-M3854-00 KM8-M34E0-B1 KJ3-MY010-00
KJ3-M34E0-XX KV7-M3823-00 KV7-M8890-00KJ3-MJA00-00
KVA-M3802-00
16
1
Tools
Tools
KJG-1010
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
No. Part No. Part Name Uses No. Part No. Part Name Uses
1 KV8-M8860-00 CLEANING KIT Spline shaft cleaner kit 37
2 KV8-M8883-A0 NEEDLE ASSY Nozzle cleaning wire 38
3 KV7-M8880-20 BRUSH, FEEDER Feeder plate cleaning brush 39
4 KGA-M3801-00 CLEANER, LENS Lens cleaner 40
5 KGA-M3803-00 BLOWER Lens blow brush 41
6 KVA-M3802-00 SWAB Cotton swab sticks 42
7 KV8-M8881-A0
NEEDLE CLEANER ASSY Nozzle cleaning wire handle
43
8 KU4-M8590-00
AIR BLOW TOOL
Air blow gun
44
9 K48-M3856-00
GREASE PACK Lithium-based grease (NSL 80g)
45
10 KV8-M8870-00 SYRYNGE OIL Oil syringe applicator for nozzle holder 46
11 K48-M3852-01 GREASE GUN Grease gun (for Cartlidge ) 47
12 K48-M3857-00 GREASE NOZZLE Grease gun nozzle 48
13 K48-M3854-00 GREASE NOZZLE Grease gun nozzle 49
14 KM8-M34E0-B1 FEEDER JIG ASSY Check and adjust pickup position 50
15 KJ3-MY010-00 MASTER JIG Adjust the feeder oating detect sensor 51
16 KJ3-MJA00-00 TOOL CASE ASSY
Tool set for exchanging and adjusting
tape feeders
52
53
17
KJ3-M34E0-01
JIG FEEDER PICK POS
AC100V
Check and adjust the pickup posi-
tion on tape feeders with monitor
54
KJ3-M34E0-10
AC200V 55
18
KV7-M3823-00 FLAT LEVEL 0.1mm/m
Adjust the machine in the horizontal position
56
19 KV7-M8890-00 ULTRAS. CLEANER SET For nozzle cleaning 57
20 58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
16
1
Tools
Tools
