2 3 . 1 . D e v i c e t a b l e ( D G S D ) 2 3 . 1 . デバイステーブル( D G S D ) 2 3 . 1 . D e v i c e t a b l e ( D G S D ) 2 3 . 1 . デバイステーブル( D G S D ) CP-743ME,CP-742ME P ARTS LIST ver03 2 3 - 1 A 1 3 9 3 9 4 8 6 0 5 2 5 8 …
22.ﾊﾟﾚｯﾄ連結部(DGSD)
22.Pallet couplings(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
45 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
46 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
47 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
48 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
49 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
50 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5
PARTS LIST CP-743ME,CP-742ME ver03
22 - 3
22.ﾊﾟﾚｯﾄ連結部(DGSD)
22.Pallet couplings(DGSD)
23.1.Device table(DGSD)
23.1.デバイステーブル(DGSD)
23.1.Device table(DGSD)
23.1.デバイステーブル(DGSD)
CP-743ME,CP-742ME PARTS LIST ver03
23 - 1
A
139
39
48
60
52
58
35
52
48
58
59
59
57
25
57
36
36
15
34
16
19
24
K
J
L
J
K
D
C
F
D
B
E
K
L
G
A
X11
54
43
54
55
54
43
50
44
51
46
48
37
49
38
55
47
54
41
56
40
54
42
54
43
42
54
43
56
39
41
54
51
46
53
38
38
53
51
46
54
41
56
39
54
42
56
40
54
41
55
47
49
38
51
46
48
37
50
44
42
26
26
33
33
20
17
32
27
31
7
12
29
13
14
4
29
12
6
10
11
1
26
26
2
23
21
8
22
5
32
28
22
9
30
30
9
22
28
5
32
22
8
21
23
1
11
10
6
12
29
14
13
29
12
7
31
27
17
32
4
20
33
33
26
26
26
26
3
M
E
F
C
B
G
A
H
H
M
18
18
36
36
23.1.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.1.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DGSD0120 2 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
2 DGSD0180 1 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ
3 DGSD0190 1 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ
4 DGSD0031 2 BKT, MOTOR BKT ﾓｰﾀ
5 DGSD0131 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
6 DGSD0200 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
7 DGSD0210 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
8 DGSD0460 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
9 DGSD0470 2 PIN 押え ﾍﾞｱﾘﾝｸﾞ
10 DGSD0481 2 STOPPER ｽﾄｯﾊﾟ
11 DGSD0490 8 COLLAR ｶﾗｰ
12 DGSD0500 4 COLLAR ｶﾗｰ
13 DGSD0510 2 COLLAR ｶﾗｰ
14 DGSD0520 2 COLLAR ｶﾗｰ
15 DGSD0980 1 GUIDE ｶﾞｲﾄﾞ
16 DGSD0970 1 GUIDE ｶﾞｲﾄﾞ
17 DGSD0720 2 COVER ｶﾊﾞｰ
18 DGSD0930 2 GUIDE 蓋
19 DGSD0761 2 RETAINER, RAIL 押え ﾚｰﾙ
20 SAM1730 2 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ
21 DCSD0481 2 STOPPER ｽﾄｯﾊﾟ
22 DCSD0490 4 COLLAR ｶﾗｰ
23 DCSD0510 8 COLLAR ｶﾗｰ
24 WSD4030 37 RETAINER, RAIL 押え ﾚｰﾙ
25 GPT0792 43 RETAINER 押え
26 DGSD0770 8 SPACER ｽﾍﾟｰｻ t=1.0 注1.Note.1
27 K10017 2 COUPLING ｶｯﾌﾟﾘﾝｸﾞ LCS-65B 20X22
28 H4159A 2 BEARING ﾍﾞｱﾘﾝｸﾞ 20TAC47BDB
29 H4161A 2 BEARING ﾍﾞｱﾘﾝｸﾞ 25TAC62BDB
30 N1126A 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR20
31 N10216 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR25
32 H2087A 8 PIN, TAPER ﾋﾟﾝ ﾃｰﾊﾟ ﾟ8X50 ﾀｯﾌﾟﾄｳｼ
33 DGSX0260 4 BOLT ﾎﾞﾙﾄ
34 K4150B 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ TKP0130-06R20 65L
35 H5269A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X5L
36 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
37 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
38 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
39 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
40 H5304A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X25L
41 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
42 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
43 H5332T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X55L
44 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
PARTS LIST CP-743ME,CP-742ME ver03
23 - 2
23.1.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.1.Device table(DGSD)
