23.4.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.4.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
114 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
115 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
116 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H
118 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
119 W1051A WASHER, FLAT ﾜｯｼｬ 平 6M/MX1.6X125(1W-6)
120 N4031A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X10L
121 K52565
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L
122 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
123 N1089A
NUT, HEX
ﾅｯﾄ 六角
M8 P=1.25
124 N1092A
NUT, HEX
ﾅｯﾄ 六角
M10 P=1.5
125 ADGSD8023 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
126 DCSD0970 1 PLATE ﾌﾟﾚｰﾄ
127 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
128 K5359E
SCREW, HEX SOCKET COUNTERSUNK
ﾈｼﾞ 六角穴皿 M4X8L
129 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
130 WWM0152 6 SEAL ｼｰﾙ
131 DCWM0100 1 SEAL ｼｰﾙ
132 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
注1.(仕様選択部品)DCSD0901(t=7.01),DCSD0911(t=7.02),DCSD0921(t=7.03),DCSD0931(t=6.99),DCSD0941(t=6.98),DCSD0951(t=6.97),
DCSD1040(t=6.95),DCSD1050(t=6.96),DCSD1060(t=7.04),DCSD1070(t=7.05)
PARTS LIST CP-743ME,CP-742ME ver03
23 - 14
23.4.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.4.Device table(DGSD)
312
310
A
139
111
294
255
233
256
266
229
228
266
242
258
249
259
N
112
219
142
143
225
165
220
307
93
256
259
284
240
251
269
267
232
238
267
232
268
244
258
243
237
257
258
245
270
246
234
256
283
256
234
257
237
257
237
252
260
282
261
261
282
265
260
253
265
260
272
265
260
253
265
260
253
248
259
267
233
251
270
252
260
264
250
259
250
259
264
269
247
190
189
223
222
221
201
200
199
198
196
308
192
191
195
194
194
L
114
154
116
R
17
183
153
2
183
157
23
153
119
182
182
33
33
118
147
1
146
147
19
205
G
60
57
49
H
224
92
13
15
14
F
29
149
83
141
148
11
148
80
149
83
148
148
10
29
79
79
78
82
77
x15
286
237
250
259
264
269
247
282
261
243
258
268
244
238
174
174
259
249
259
250
269
247
210
209
239
267
232
234
256
256
234
232
267
257
237
255
228
N
C
183
62
3
157
183
23
153
153
34
E
24
24
156
156
140
33
33
158
158
117
120
48
120
115
202
119
182
182
61
188
56
53
29
D
41
84
81
83
149
148
148
12
16
6
4
6
4
9
5
7
8
M
A
B
22
257
237
277
297
296
311
295
P
P
293
293
233
233
233
274
248
259
270
249
258
241
249
271
271
248
259
227
255
235
256
233
267
227
255
275
275
258
241
267
233
275
275
255
227
A
L
160
26
50
69
27
30
162
51
K
C
161
32
31
38
162
161
40
39
39
J
J
25
52
159
71
30
52
70
73
73
72
72
66
64
67
159
68
65
72
72
66
67
159
68
G
20
21
R
M
H
B
D
187
187
187
F
E
K
234
256
239
37
36
85
309
234
256
232
256
255
228
164
255
228
164
100
6
6
28
24.1.カムボックス(DCPA)
24.1.Cam box(DCPA)
24.1.カムボックス(DCPA)
24.1.Cam box(DCPA)
24 - 1
CP-743ME,CP-742ME PARTS LIST ver03
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DCPA1121 1 PULLEY ﾌﾟｰﾘ
2 DCPA0221 1 PULLEY ﾌﾟｰﾘ
3 DCPA0201 1 PULLEY ﾌﾟｰﾘ
4 DCPA0211 2 PULLEY ﾌﾟｰﾘ
5 DCPA0190 1 PULLEY ﾌﾟｰﾘ
6 DCPA0290 4 RING, LOCKING ﾘﾝｸﾞ 締結
7 DGPA0011 1 INDEX ｲﾝﾃﾞｯｸｽ
8 DGPA0021 1 INDEX ｲﾝﾃﾞｯｸｽ
9 H30762 1 RING, LOCKING ﾘﾝｸﾞ 締結 ETP-K-17
10 DCPA0230 1 PULLEY ﾌﾟｰﾘ
11 DCPA0240 1 PULLEY ﾌﾟｰﾘ
12 DCPA1260 1 PULLEY ﾌﾟｰﾘ
13 H4578A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 580-5GT-15
14 H4579A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 710-5GT-55
15 H4577A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 360-5GT-25
16 H4580A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 960-5GT-40
17 DCPA1080 1 SCALE ﾒﾓﾘ
18 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
19 DCPA0421 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
20 DCPA1100 1 NAMEPLATE, ARROW 銘板 矢印
21 DCPA1110 1 NAMEPLATE, ARROW 銘板 矢印
22 K5209A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X8L
23 DCPA0480 2 COLLAR ｶﾗｰ
24 DCPA1070 1 DOG ﾄﾞｯｸﾞ
25 DCPA1620 1 COLLAR ｶﾗｰ
26 DCPA1600 1 COLLAR ｶﾗｰ
27 DCPA1590 1 COLLAR ｶﾗｰ
28 ADCPA8051 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
29 DCPA0370 3 BOLT ﾎﾞﾙﾄ
30 DCPA1490 2 KEY ｷｰ
31 DCPA1551 1 HOUSING ﾊｳｼﾞﾝｸﾞ
32 DCPA1561 1 COVER ｶﾊﾞｰ
33 DCPA0070 4 PIN, LOCATING ﾋﾟﾝ 位置決め
34 ADCPA8012 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
36 DCPA1170 1 RING ﾘﾝｸﾞ
37 DCPA1060 2 DOG ﾄﾞｯｸﾞ
38 DCPA1430 1 BKT BKT
39 DCPA1480 2 COVER 蓋
40 DCPA1470 1 GEAR ｷﾞﾔ
41 DCPA1281 1 BKT BKT
48 DCPA0460 2 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め
49 DCPA0270 1 KEY ｷｰ
50 DCPA1540 1 SHAFT ｼｬﾌﾄ
51 DCPA1570 1 GEAR ｷﾞﾔ
PARTS LIST CP-743ME,CP-742ME ver03
24 - 2
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
