43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF) 43.Noise redaction seal(743ME)(DGPZ)(DGAF) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 79 ADGAF8170 2 COVER 蓋 80 DGAF0460 2 COVER 蓋 81 DGAF1260 2 S…
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 ADGPZ8052 1 COVER ｶﾊﾞｰ
2 DGPZ0023 1 COVER ｶﾊﾞｰ
3 DGPZ0532 1 SEAL ｼｰﾙ
4 ADGPZ8062 1 COVER ｶﾊﾞｰ
5 DGPZ0032 1 COVER ｶﾊﾞｰ
6 DCPZ0220 1 SEAL ｼｰﾙ
7 DGPZ0522 1 SEAL ｼｰﾙ
8 ADGPZ8072 1 COVER ｶﾊﾞｰ
9 DGPZ0042 1 PIN ｶﾊﾞｰ
10 DGPZ0510 1 SEAL ｼｰﾙ
11 ADGPZ8130 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME
12 DGPZ1540 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
13 DGPZ2130 1 SEAL ｼｰﾙ 743ME
14 DGPZ2120 3 SEAL ｼｰﾙ 743ME
15 DGPZ1490 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME Use only when no external parts monitor.
16 DCPZ1860 1 SEAL ｼｰﾙ 743ME Use only when no external parts monitor.
17 DGPZ2010 1 SEAL ｼｰﾙ
18 DGPZ2150 2 GUIDE ｼｰﾙ 743ME
19 ADGPZ8091 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
20 DGPZ1171 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
21 DGPZ2080 1 SEAL ｼｰﾙ
22 ADGPZ8102 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
23 DGPZ1182 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
24 DGPZ2040 1 SEAL ｼｰﾙ
25 DGPZ2050 1 SEAL ｼｰﾙ
26 DGPZ2060 1 SEAL ｼｰﾙ
27 DGPZ2070 1 SEAL ｼｰﾙ
28 ADGPZ8111 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
29 DGPZ1192 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ
30 DGPZ2031 1 SEAL ｼｰﾙ
31 ADGAF8100 1 COVER ｶﾊﾞｰ
32 DCAF0120 1 COVER ｶﾊﾞｰ
33 DCAF1160 1 SEAL ｼｰﾙ
34 DCAF1170 1 SEAL ｼｰﾙ
35 ADGAF8110 1 COVER, REAR ｶﾊﾞｰﾘﾔ-
36 DGAF0160 1 COVER ｶﾊﾞｰ
37 DGAF1060 2 SEAL ｼｰﾙ
38 DGAF1040 1 SEAL ｼｰﾙ
39 DGAF1160 1 SEAL ｼｰﾙ
PARTS LIST CP-743ME,CP-742ME ver03
43 - 2
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
40 ADGAF8120 1 COVER, REAR ｶﾊﾞｰﾘﾔ-
41 DGAF0170 1 COVER ｶﾊﾞｰ
42 DGAF1170 1 SEAL ｼｰﾙ
43 DGAF1050 1 SEAL ｼｰﾙ
44 DGAF1070 2 SEAL ｼｰﾙ
45 ADGAF8210 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
46 DGAF0950 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
47 DGAF1030 1 SEAL ｼｰﾙ
48 DGAF1090 1 SEAL ｼｰﾙ
49 DGAF1110 1 SEAL ｼｰﾙ
50 DGAF1120 1 SEAL ｼｰﾙ
51 DGAF1150 1 SEAL ｼｰﾙ
52 DGAF1220 1 SEAL ｼｰﾙ
53 ADGAF8220 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
54 DGAF0940 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
55 DGAF1030 1 SEAL ｼｰﾙ
56 DGAF1090 1 SEAL ｼｰﾙ
57 DGAF1080 1 SEAL ｼｰﾙ
58 DGAF1100 1 SEAL ｼｰﾙ
59 DGAF1130 1 SEAL ｼｰﾙ
60 DGAF1180 1 SEAL ｼｰﾙ
61 ADGAF8150 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
62 DGAF0100 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
63 DGAF1230 1 SEAL ｼｰﾙ
64 DGAF1240 1 SEAL ｼｰﾙ
65 DGAF1250 1 SEAL ｼｰﾙ
66 DGAF1140 1 SEAL ｼｰﾙ
67 DCAF1080 1 SEAL ｼｰﾙ
68 DCAF1090 1 SEAL ｼｰﾙ
69 DCAF1100 1 SEAL ｼｰﾙ
70 ADGAF8160 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
71 DGAF0090 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ
72 DGAF1190 1 SEAL ｼｰﾙ
73 DGAF1200 1 SEAL ｼｰﾙ
74 DGAF1210 1 SEAL ｼｰﾙ
75 DGAF1140 1 SEAL ｼｰﾙ
76 DCAF1080 1 SEAL ｼｰﾙ
77 DCAF1090 1 SEAL ｼｰﾙ
78 DCAF1100 1 SEAL ｼｰﾙ
PARTS LIST CP-743ME,CP-742ME ver03
43 - 3
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
79 ADGAF8170 2 COVER 蓋
80 DGAF0460 2 COVER 蓋
81 DGAF1260 2 SEAL ｼｰﾙ
82 ADGAF8180 2 COVER 蓋
83 DGAF0470 2 COVER 蓋
84 DCAF1290 2 SEAL ｼｰﾙ
85 H1466K 4 PACKING ﾊﾟｯｷﾝ 5X30X300CR25ﾟﾘｮｳﾒﾝ500
86 H1468Z 2 PACKING ﾊﾟｯｷﾝ 5X95X230CR25ﾟﾘｮｳﾒﾝ500
87 H1466Z 3 PACKING ﾊﾟｯｷﾝ 5X45X70CR25ﾟﾘｮｳﾒﾝ500
88 H14680 1 PACKING ﾊﾟｯｷﾝ 5X95X355CR25ﾟﾘｮｳﾒﾝ500
89 DGPV1010 1 SEAL ｼｰﾙ
90 DGPV0280 1 DOOR 扉
91 ADGPV8150 1 DOOR 扉
92 DGAB1050 1 SEAL ｼｰﾙ
93 DGAB0560 1 COVER ｶﾊﾞｰ
94 ADGAB8110 1 COVER ｶﾊﾞｰ
95 DGAB0590 1 COVER ｶﾊﾞｰ
96 DGAB1071 1 SEAL ｼｰﾙ
97 ADGAB8160 1 COVER ｶﾊﾞｰ
98 DGAB0570 1 COVER ｶﾊﾞｰ
99 DGAB1060 1 SEAL ｼｰﾙ
100 ADGAB8120 1 SEAL ｼｰﾙ
101 ADGPZ8170 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743ME Use only when no external parts monitor.
PARTS LIST CP-743ME,CP-742ME ver03
43 - 4
43.防音ｼｰﾙ(743ME)(DGPZ)(DGAF)
43.Noise redaction seal(743ME)(DGPZ)(DGAF)
