11.2.Z ｽﾗｲﾄﾞﾊﾞｷｭｰﾑ式ﾊﾞｯｸｱｯﾌﾟﾋﾟﾝ(ｵﾌﾟｼｮﾝ)(DGSZ)
11.2.Z slide vacuum back up pins(Option)(DGSZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 ADGSZ8010 4 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
2 DGSZ0060 4 PULLEY, TIMING ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ
3 DGSZ0050 4 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
4 SAM1720 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ
5 DGSZ0011 1 BASE ﾍﾞｰｽ
6 DGSZ0020 1 PLATE, BACKUP ﾌﾟﾚｰﾄ ﾊﾞｯｸｱｯﾌﾟ
7 DGSZ0070 1 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ
8 DGSZ0080 1 COLLAR ｶﾗｰ
9 DGSZ0090 6 COLLAR ｶﾗｰ
10 DGSZ0100 2 COLLAR ｶﾗｰ
11 DGSZ0160 2 COVER ｶﾊﾞｰ
12 DGSZ0170 2 COVER ｶﾊﾞｰ
13 DGSZ0030 1 BKT BKT
14 DGSZ0110 7 PIN ﾋﾟﾝ
15 DGSZ0120 2 PIN ﾋﾟﾝ
16 DGSZ0041 1 BKT, MOTOR BKT ﾓｰﾀ
17 DGSZ0210 1 BKT, SENSOR BKT ｾﾝｻ
18 DGSZ0130 4 STOPPER ｽﾄｯﾊﾟ
19 DGSZ0140 4 STOPPER ｽﾄｯﾊﾟ
20 DGSZ0150 4 COLLAR ｶﾗｰ
21 DGSZ0180 1 BKT BKT
22 DGSZ0190 1 DOG ﾄﾞｯｸﾞ
23 DGSZ0200 1 DOG ﾄﾞｯｸﾞ
24 DGSZ0221 1 BKT BKT
25 DGSZ0230 1 DOG ﾄﾞｯｸﾞ
26 DGSZ0240 1 DOG ﾄﾞｯｸﾞ
27 DGSZ0250 1 DOG ﾄﾞｯｸﾞ
28 CSSZ0650 2 PULLEY, INTERMEDIATE ﾌﾟｰﾘ 中間
29 DCSZ0210 1 BKT BKT
30 WSZ4131 4 NUT ﾅｯﾄ
31 DCSZ0290 7 ROLLER ﾛｰﾗ
32 WSZ4101 9 COLLAR ｶﾗｰ
33 WSZ4800 4 PLATE ﾌﾟﾚｰﾄ
34 DCSZ0240 1
BOLT, ADJUSTING
ﾎﾞﾙﾄ ｾﾘ
35 DCSZ0250 1 BKT BKT
36 S4045F 4 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX871A
37 R2069A 1
RING, LOCKING
ﾘﾝｸﾞ 締結         
ETP-D-12
38 H4202Z 18
BEARING
ﾍﾞｱﾘﾝｸﾞ 6900ZZ
39 H4509S 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 2340-3GT-12
40 K5357T
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿       
M3X8L
41 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X8L
42 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X6L
43 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X10L
44 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L
PARTS LIST CP-743ME,CP-742ME ver03
11 - 5
11.2.Z ｽﾗｲﾄﾞﾊﾞｷｭｰﾑ式ﾊﾞｯｸｱｯﾌﾟﾋﾟﾝ(ｵﾌﾟｼｮﾝ)(DGSZ)
11.2.Z slide vacuum back up pins(Option)(DGSZ)
11.2.Z ｽﾗｲﾄﾞﾊﾞｷｭｰﾑ式ﾊﾞｯｸｱｯﾌﾟﾋﾟﾝ(ｵﾌﾟｼｮﾝ)(DGSZ)
11.2.Z slide vacuum back up pins(Option)(DGSZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
45 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X10L
46 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X12L
47 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X15L
48 H5292A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X20L
49 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X12L
51 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X15L
52 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
53 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
54 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
55 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
56 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
57 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
58 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
59 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L
60 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-3-L
61 N4018A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X3L
62 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
63 CSWM0311 4 SEAL ｼｰﾙ ･
74 DGSZ3011 1 PLATE, VACUUM ﾌﾟﾚｰﾄ ﾊﾞｷｭｰﾑ Vacuum Back Up Pins(Option)
75 DGSZ3020 1 PLATE, BLIND ﾌﾟﾚｰﾄ 盲 Vacuum Back Up Pins(Option)
76 DCSZ3031 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ Vacuum Back Up Pins(Option)
77 DCSZ3040 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ Vacuum Back Up Pins(Option)
78 H5056M 1 HOLDER ﾎﾙﾀﾞ TM-06 Vacuum Back Up Pins(Option)
79 DGSZ3040 1 BKT BKT Vacuum Back Up Pins(Option)
80 DCSS0370 1 BKT BKT Vacuum Back Up Pins(Option)
81 DCSZ3071 1 GENERATOR, VACUUM 発生器 真空 Vacuum Back Up Pins(Option)
82 K51693 1 SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M2.5X8L Vacuum Back Up Pins(Option)
83 Y30860 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQ2S08-01S Vacuum Back Up Pins(Option)
84 Y3079S 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L08-01S Vacuum Back Up Pins(Option)
85 DCSS3090 1 PLATE ﾌﾟﾚｰﾄ Vacuum Back Up Pins(Option)
86 DCSS3030 1 COVER ｶﾊﾞｰ Vacuum Back Up Pins(Option)
87 ADGSS8021 10 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ Vacuum Back Up Pins(Option)
88 DGSS0411 10 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ Vacuum Back Up Pins(Option)
89 DGSS3040 10 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ Vacuum Back Up Pins(Option)
90 DGSS3060 10 BOLT ﾎﾞﾙﾄ Vacuum Back Up Pins(Option)
91 DGSS3051 10 COLLAR ｶﾗｰ Vacuum Back Up Pins(Option)
92 N1086A 10
NUT, HEX
ﾅｯﾄ 六角         
M6 P=1.0 3ｼｭ Vacuum Back Up Pins(Option)
93 ADGSS8032 10 PIN, VACUUM ﾋﾟﾝ ﾊﾞｷｭｰﾑ Vacuum Back Up Pins(Option)
94 DGSS3010 10 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ Vacuum Back Up Pins(Option)
95 DGSS3020 10 PIN, VACUUM ﾋﾟﾝ ﾊﾞｷｭｰﾑ Vacuum Back Up Pins(Option)
96 DGSS3060 10 BOLT ﾎﾞﾙﾄ Vacuum Back Up Pins(Option)
97 DGSS3051 10 COLLAR ｶﾗｰ Vacuum Back Up Pins(Option)
98 DGSS3081 20 TUBE ﾁｭｰﾌﾞ Vacuum Back Up Pins(Option)
99 A4067A 10
ELBOW
ｴﾙﾎﾞ M-3ALU-4 Vacuum Back Up Pins(Option)
PARTS LIST CP-743ME,CP-742ME ver03
11 - 6
11.2.Z ｽﾗｲﾄﾞﾊﾞｷｭｰﾑ式ﾊﾞｯｸｱｯﾌﾟﾋﾟﾝ(ｵﾌﾟｼｮﾝ)(DGSZ)
11.2.Z slide vacuum back up pins(Option)(DGSZ)
11.2.Z ｽﾗｲﾄﾞﾊﾞｷｭｰﾑ式ﾊﾞｯｸｱｯﾌﾟﾋﾟﾝ(ｵﾌﾟｼｮﾝ)(DGSZ)
11.2.Z slide vacuum back up pins(Option)(DGSZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
100 A4067H 10
ELBOW
ｴﾙﾎﾞ M-3AU-4 Vacuum Back Up Pins(Option)
101 A5130A 20
O RING
Oﾘﾝｸﾞ S6 Vacuum Back Up Pins(Option)
102 H1194F 10 PAD, VACUUM ﾊﾟｯﾄ ﾊﾞｷｭｰﾑ KP-15-S Vacuum Back Up Pins(Option)
103 N4018T 20
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M3X3Lﾋﾗｻｷ Vacuum Back Up Pins(Option)
104 A4067T 10 ELBOW ｴﾙﾎﾞ M-5ALHU-4 Vacuum Back Up Pins(Option)
105 H1037E 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動 HV6-6 Vacuum Back Up Pins(Option)
106 H3146A 55
PLUG
ﾌﾟﾗｸﾞ M-5P Vacuum Back Up Pins(Option)
107 W1003Y 10 PUSHER ﾌﾟｯｼｬ TM-137-5 Vacuum Back Up Pins(Option)
108 ADGSZ8020 PLATE, VACUUM ﾌﾟﾚｰﾄ ﾊﾞｷｭｰﾑ Vacuum Back Up Pins(Option)
111 H5293A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X25L
112 H5280A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L
113 H5266A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L .
PARTS LIST CP-743ME,CP-742ME ver03
11 - 7
