CP-742ME-03 - 第77页
14.第1ｽﾃｰｼｮﾝ(ﾊﾟｰﾂ吸着)(DGPL) 14.Station 1(Parts pick up)(DGPL) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 1 DGPL0011 1 BKT BKT 2 DCPL0020 1 LEVER ﾚﾊﾞｰ 3 DCPL0030 1 PIN ﾋﾟﾝ 4 DCP…
14.第1ステーション(ﾊﾟｰﾂ吸着)(DGPL)
14.Station 1(Parts pick up)(DGPL)
14.第1ステーション(ﾊﾟｰﾂ吸着)(DGPL)
14.Station 1(Parts pick up)(DGPL)
CP-743ME,CP-742ME PARTS LIST ver03
14 - 1
Ref.33-7
Ref.13-1
二次元バーコードカメラオプション
2-D Barcode Camera(Option)
x6
63
69
B
40
15
63
75
69
33
31
52
20
19
21
39
38
39
21
32
6
66
71
77
23
87
69
89
71
96
95
86
94
85
107
84
69
62
79
71
79
67
72
59
68
69
61
59
68
75
69
62
58
68
A
A
B
54
54
55
37
17
17
3
9
9
41
41
64
70
76
8
83
68
49
63
69
75
25
108
70
76
75
13
12
10
11
5
46
46
59
68
30
27
79
71
29
28
45
80
79
71
44
47
66
71
26
47
18
16
48
48
43
43
53
53
4
24
50
22
42
22
42
2
1
91
81
56
C
82
70
78
57
74
68
60
75
69
61
34
36
35
14
90
68
68
109
109
0.5 1 2
64
75
69
98
70
76
70
76
101
70
76
100
99
105
97
106
103
104
102
D
C
51
14.第1ｽﾃｰｼｮﾝ(ﾊﾟｰﾂ吸着)(DGPL)
14.Station 1(Parts pick up)(DGPL)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 DGPL0011 1 BKT BKT
2 DCPL0020 1 LEVER ﾚﾊﾞｰ
3 DCPL0030 1 PIN ﾋﾟﾝ
4 DCPL0040 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
5 DGPL0020 1 HOLDER ﾎﾙﾀﾞ
6 DCPL0100 1 HOLDER, JAW ﾎﾙﾀﾞ 爪
8 DCPL0150 1 BKT BKT
9 DCPL0160 2 BKT BKT
10 DCPL0170 1 DOG ﾄﾞｯｸﾞ
11 DGPL0030 1 SHAFT ｼｬﾌﾄ
12 DCPL0140 1 BKT BKT
13 DCPL0130 1 PLATE ﾌﾟﾚｰﾄ
14 DGPL0050 1 HOLDER ﾎﾙﾀﾞ
15 DGPL0040 1 BKT BKT
16 DCPL0070 1 PIN ﾋﾟﾝ
17 DCPL0180 2 PIN, LOCATING ﾋﾟﾝ 位置決め
18 DCPL0080 1 NUT ﾅｯﾄ
19 WPL0310 1 COLLAR ｶﾗｰ
20 WPL0321 1 HINGE ﾋﾝｼﾞ
21 WPL0330 2 COLLAR ｶﾗｰ
22 WPL0040 2 COLLAR ｶﾗｰ
23 WPL0372 1 BKT BKT
24 WPL5012 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
25 GPL0611 1 PLATE, SW ﾌﾟﾚｰﾄ SW
26 WPL0100 1 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ
27 WPL0440 1 PIN ﾋﾟﾝ
28 WPL0410 1 PLATE, ARM ﾌﾟﾚｰﾄ ｱｰﾑ
29 WPL0140 1 PIN ﾋﾟﾝ
30 WPL0130 1 PLATE ﾌﾟﾚｰﾄ
31 DCPL0201 1 SPRING ｽﾌﾟﾘﾝｸﾞ
32 WPL0201 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
33 WPL0191 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
34 MPK1090 1 PIN ﾋﾟﾝ
35 WGZ0320 1 LEVER ﾚﾊﾞｰ
36 WGZ0280 1 BKT BKT
37 H1077T 1
VALVE, SOL
ﾊﾞﾙﾌﾞ SOL PCS-242-M5-D24-SP
38 S1021A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3
39 H4444A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-940ZZ
40 N4020T 1 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止ﾒ M3X5Lﾋﾗｻｷ
41 S40441 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770
42 H4390T 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA1515Z
43 S1023A 2
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-5
44 H4432A 1
BEARING, BALL
ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LM8UU
45 H3167A 1
PLUNGER, BALL
ﾌﾟﾗﾝｼﾞｬ ﾎﾞｰﾙ BST-10
PARTS LIST CP-743ME,CP-742ME ver03
14 - 2
14.第1ｽﾃｰｼｮﾝ(ﾊﾟｰﾂ吸着)(DGPL)
14.Station 1(Parts pick up)(DGPL)
14.第1ｽﾃｰｼｮﾝ(ﾊﾟｰﾂ吸着)(DGPL)
14.Station 1(Parts pick up)(DGPL)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
46 H41148 2
BEARING
ﾍﾞｱﾘﾝｸﾞ R-1450ZZ
47 H4291T 2
BEARING, SLIDE
ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ LM12UU
48 H4401A 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA69Z
49 S3130A 1
SW, PHOTOELECTRIC
SW 光電
PS-47
50 WPL0390 1 PIN ﾋﾟﾝ
51 A10627 1 AMPLIFIER, SENSOR ｱﾝﾌﾟ ｾﾝｻ PS-T2
52 DCPL0190 1 JAW 爪
53 K5332A 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ SS4-M5A
54 A4144A 2 ELBOW ｴﾙﾎﾞ EL4-M5-M
55 Y3079N 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5
56 H3007H 1 FIBER UNIT ﾌｧｲﾊﾞﾕﾆｯﾄ PF-59
57 H3165A 1
PLUNGER, BALL
ﾌﾟﾗﾝｼﾞｬ ﾎﾞｰﾙ BST-4
58 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
59 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
60 H5280A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L
61 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
62 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
63 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
64 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
65 H5305A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X30L
66 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L
67 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L
68 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
69 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
70 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
71 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
72 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
73 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
74 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
75 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
76 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
77 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
78 N4016A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M2X2L
79 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0
80 N1092A
NUT, HEX
ﾅｯﾄ 六角
M10 P=1.5
81 N1081T
NUT, HEX
ﾅｯﾄ 六角
M4 3ｼｭ
82 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
83 K51780
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋 M3X18L
84 DCPA1690 1 BKT BKT
85 S2010K (1) ILLUMINATION LAMP 照明灯 FT1101-GL16(60Hz) 注1.Note.1
86 ADCPA8010 1 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ
87 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
88 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
89 DCWZ0030 1 PLATE ﾌﾟﾚｰﾄ
