Adjustment Instructions SIPLACE HS -50 4 Overview Voltages Edition 05/00 4.4 Main Dist ributor 75 0DLQ 'LVWULEXWRU Switchi ng on the plac ement sys tem you ca n meas ure the foll owing voltages on the term inal…
4 Overview Voltages Adjustment Instructions SIPLACE HS-50
4.3 Control Unit Edition 05/00
74
&RQWURO8QLW
Switching on the main switch , the DC / DC - converter in the control unit will be supplied with 50
VDC from the power supply unit. The following voltages will be generated in the control unit:
+ 5 VDC supplying the digital electronic.
± 12 VDC supplying the digital electronic.
± 15 VDC supplying the analog electronic.
+ 24 VDC supplying the control circuits, relay etc.
The measuring points are found in the detailed circuit diagram "Control unit HS-50, front view, in
chapter 3.
Adjustment Instructions SIPLACE HS-50 4 Overview Voltages
Edition 05/00 4.4 Main Distributor
75
0DLQ'LVWULEXWRU
Switching on the placement system you can measure the following voltages on the terminal strip
of the main distributor: (See detailed circuit diagram "Main distributor in chapter 3"):
5HJXODWHG9ROWDJHV
5 VDC, ± 12 VDC, ± 15 VDC, 24 VDC
8QVDWXUDWHG9ROWDJHV
8 VDC, 38 VDC, 50 VDC
4 Overview Voltages Adjustment Instructions SIPLACE HS-50
4.5 Servo Unit Edition 05/00
76
6HUYR8QLW
Switching on the main switch the servo unit will be supplied with the following voltages:
You find the test sockets in your detailed circuit diagram "Servo unit HS-50, item number 111050-
01, chapter 2, page 29".
Supply voltages ± 15 VDC for the servo unit electronic will be generated by the ± 15 V -power
supply which is installed in the servo unit. They can be measured at the measuring points of the
power supply. (See detailed circuit diagram "Servo unit HS-50, chapter 2, page 30).
0HDVXULQJSRLQW PHDVXUHGDJDLQVW;9
X4 0 VDC for the servo amplifier of the x-/y - axes
X3 6 VDC for the servo amplifier of the star - axis
X2 30 VDC for the servo amplifier of the z- and dp - axes
