Maintenance 4.1.4 Performing Maintenance Ta sks Maintenance Tasks for Vacuum Pump Vacuum Pump Vakuumpumpe 123 4.1.4.1 4 . 1 . 4 . 1 C h e c k in g / R e p la c in g t h e F ilt e r I n s e r t Checking/Replacing the Filt…
Maintenance
Maintenance Tasks for Vacuum Pump 4.1.3 Recommended maintenance intervals
122 Vacuum Pump Vakuumpumpe
4.1.3
4.1.3 Recommended maintenance intervals
Recommended maintenance intervals
4.1.4
4.1.4 Performing Maintenance Tasks
Performing Maintenance Tasks
SXDX12V2
Maintenance inter-
val
Spare part Task
Every 6 months Filter insert [03077677-xx] Check the filter insert and replace if necessary.
NOTICE
Working life
The filter insert has a working life of at minimum 7500 hours up to 25000 hours. For more infor-
mation about the product life, refer to the manufacturer's documentation (see http://www.beck-
er-international.com – Vacuum pump rotary vane pumps, dry running, type VX4.25)
NOTICE
Observe the manufacturer's instructions
► For more information about maintenance intervals and about how to perform the individual
maintenance tasks, read the manufacturer's instructions for your vacuum pump.
NOTICE
Observe the assembly instructions
► For these tasks, also read the "Assembly instructions SX1/SX2/DX1/DX2" [00196614-xx].
Maintenance
4.1.4 Performing Maintenance Tasks Maintenance Tasks for Vacuum Pump
Vacuum Pump Vakuumpumpe 123
4.1.4.1
4.1.4.1 Checking/Replacing the Filter Insert
Checking/Replacing the Filter Insert
► Open the edgewise retaining clamp of the filter casing
and remove the cap.
► Remove the vacuum filter (1).
► Check the vacuum filter and replace it, if necessary
(filter insert [03077677-xx]).
Maintenance
Maintenance Tasks for Vacuum Pump 4.1.5 Final work
124 Vacuum Pump Vakuumpumpe
4.1.5
4.1.5 Final work
Final work
► Installation is performed by following the above instructions in the reverse order. Also observe the
following instructions:
Compone nt Supply - Manual Tables - Fitting Pr otections - SW Version
SXDX12V1V2 – Tape Cutter – Waste Tape Chute – Pay Attention to the Plastic Strips – SW Version
Manual tables only:
WARNING! There is a risk of injury on manual
tables without the two protections.
► Fit the two protections.
CAUTION!
Make sure that the plastic strips (1) (if present) are locat-
ed behind the plate (2) when you hook up the used tape
chute.
The black-yellow hatched label must be completely visi-
ble.
