sATS30_KMA_mpl - 第9页
KMA-1505 14 15 17 23 29 35 30 31 32 33 34 16 20 39 39 45 21 21 21 21 45 45 18 41 5 13 26 48 25 13 22 22 53 53 40 27 41 27 23 23 19 1 4 21 46 42 43 46 46 46 36 2 46 7 7 3 22 6 6 9 8 27 10 11 44 27 10 11 44 12 12 38 37 37 …
KMA-1505
No. Part No. Part Name Q'ty Remarks Rank
Level
No. Part No. Part Name Q'ty Remarks Rank
Level
1 90440-01J040 CIRCLIP 2 39
2 90990-01J039 BOLT HEX,SOCKET HEAD 4 40
3 90990-33J006 BOLT, STOPPER 2 41
4 90K41-001250 LABEL,WARNING 1 42
5 90K41-001270 LABEL,WARNING 1 43
6 91312-03008 BOLT HEX,SOCKET HEAD 2 44
7 91312-04005 BOLT HEX,SOCKET HEAD 3 45
8 91312-04006 BOLT HEX,SOCKET HEAD 4 46
9 91312-04008 BOLT HEX,SOCKET HEAD 16 47
10 91312-05008 BOLT HEX,SOCKET HEAD 2 48
11 K44-M1354-00 MG. CATCH 1 /
49
12 K46-M1373-00 SHAFT, HINGE 2 /
50
13 KG2-M1372-00 PIECE B, HINGE 2 /
51
14 KGF-M1313-00 CANNEL HINGE 2 /
52
15 KGF-M1335-01 PULL 1 /
53
16 KGS-M1360-00 BOLT 2 / × 54
17 KGS-M1360-10 BOLT 2 / × 55
18 KGX-M1315-00 SPONGE 1 /
56
19 KGX-M13A3-00 GUIDE RACK DOOR 2 /
57
20 KGX-M13A4-00 BRACKET KEY 1 / × 58
21 KGX-M13A5-00 NUT PLATE 1 / × 59
22 KHF-M1316-L0 STAY L 1 /
60
23 KHF-M1316-R0 STAY R 1 /
61
24 KMA-M13A1-00 DOOR 1 /
62
25 KMA-M13A2-00 COVER 2,DOOR-L 1 /
63
26 KMA-M13A3-00 COVER 2,DOOR-R 1 /
64
27 KMA-M13B1-00 DOOR 1 1 /
65
28 KMA-M13B2-00 HANDLE 1 /
66
29 92902-04200 WASHER,PLAIN 8 67
30 98702-03005 SCREW,FLAT HEAD 8 68
31 90990-12J005 SCREW, BIN. HEAD W/W 2 69
32 KMA-M13A0-00 DOOR ASSY. 1 / × 70
33 KMA-M13B0-00 DOOR L ASSY. 1 /
71
34 72
35 73
36 74
37 75
38 76
2
1
Cover
Cover
KMA-1505
14
15
17
23
29
35
30
31
32
33
34
16
20
39
39
45
21
21
21
21
45
45
18
41
5
13
26
48
25
13
22
22
53
53
40
27
41
27
23
23
19
1
4
21
46
42
43
46
46
46
36
2
46
7
7
3
22
6
6
9
8
27
10
11
44
27
10
11
44
12
12
38
37
37
38
24
28
24
28
26
25
40
3
46
39
39
45
47
51
50
52
54
49
3
1
Rack Assy / Pallet Assy
Rack / Pallet
KMA-1505
No. Part No. Part Name Q'ty Remarks Rank
Level
No. Part No. Part Name Q'ty Remarks Rank
Level
1 KGX-M1731-01 PLATE, BOTTOM 1 C × 38 KGX-M1744-00 PLATE HANDLE 2 C ×
2 KGX-M1742-00 FRAME, SIDE R 1 C × 39 KGX-M1745-00 PLATE BLOCK 4 C ×
3 KGX-M1733-01 CARD GUIDE 2 C × 40 KGX-M173T-00 RACK HANDLE 2 C
4 KGX-M1734-00 STOPPER, PALLET 1 C × 41 90990-46J001 BOLT,THIN HEAD 4 C
5 KGX-M1735-01 DOOR, RACK 1 C
42
KGX-M17B0-04 RACK ASSY 2 S.T.D C
6 KGX-M1736-00 HINGE ASSY 1 C
KGX-M17B0-A1 RACK ASSY 2 IT O/P C
7
KGX-M1737-00 LABEL, PALLET POSI. 1 (1~15) C
43
KGX-M17B1-01 PALLET ASSY 30 S.T.D C
KGX-M1737-10 LABEL, PALLET POSI. 1 (16~30) C
KGX-M17B1-A0 PALLET ASSY 30 IT O/P C
8 KGX-M173A-L0 LATCHE 1 C
44 91312-03006 BOLT HEX. SOCKET HEAD 4
9 KGX-M173A-R0 LATCHE 1 C
45 91312-03008 BOLT HEX. SOCKET HEAD 16
10
KGX-M173B-00 BRKT. LATCHE 2 C
46 98702-03008 SCREW, FLAT HEAD 16
11 KGX-M173C-00 STOPPER BRKT. 2 C
47 KGX-M173D-L0 LATCHE L ASSY 1 /
12 KGX-M173H-00 HANDLE 2 C
48 KGX-M173D-R0 LATCHE R ASSY 1 /
13 KGX-M173J-00 SPRING 2 C × 49 KGF-M5542-00 BARCODE LABEL,PL 1 C
14 90990-31J012 BOLT,SHOULDER 1 C
50 98902-03006 SCREW,HEAD 4
15 KGX-M173L-00 SHAFT 1 C
51 KGX-M173S-02 PLATE,SEAL 1 C
16 KGX-M173M-00 SHAFT CLIP 1 C
52 KGS-M5552-00 BARCODE LABEL,MZ 1 C
17 KGX-M173N-00 BRACKET 1 C
53 92903-03100 WASHER SPRING 4
18 KGX-M173P-01 DOOR, RUBBER 2 C
54 KGX-M173R-01 LAMINATE 1 1 C
19 K93-M1392-00 SPACER (TM-180-303) 4 C
55
20 90115-2AJ008 BOLT HEX. SOCKET HEAD 2 56
21 91312-03005 BOLT HEX. SOCKET HEAD 6 57
22 98902-03004 SCREW BINDING HEAD 20 58
23 98902-03006 SCREW BINDING HEAD 6 59
24 98902-04006 SCREW,BINDING HEAD 8 60
25
98902-05006 SCREW BINDING HEAD 4 61
26 98702-05010 SCREW, FLAT HEAD 2 62
27 92903-03600 WASHER PLAIN 8 63
28 92903-04600 WASHER PLAIN 8 64
29 KGX-M1751-01 PALLET 1 C
65
30 KGX-M1752-00 SHEET 1 C
66
31 KGX-M1753-00 PLATE MAGNET 1 C
67
32 KV4-M1755-00 PLATE 1 1 C × 68
33 KGX-M1755-00 MAGNET 2 C
69
34 90990-46J005 BOLT,THIN HEAD 2 C × 70
35 KGX-M1756-00 SEAT 1 C
71
36 KGX-M1741-00 FRAME SIDE L 1 C × 72
37 KGX-M1743-00 FRAME TOP 2 C × 73
3
1
Rack / Pallet
Rack Assy / Pallet Assy
