Shaft Head Sub Assy
Head
KKT-1204
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KKE-M7107-B0 HEAD SHAFT 2B ASSY.
4 /
Í
39
2
KKE-M7107-A0 HEAD SHAFT 2 ASSY.
4 /
Í
40
3
KKT-M7107-B0 HEAD SHAFT 2B ASSY.
1 /
Í
41
4
KKT-M7107-A0 HEAD SHAFT 2 ASSY.
1 /
Í
42
5
KKT-M712S-A0 SHAFT 2, SPARE
1 /
Í
43
6
KKE-M712K-00 GUIDE, SPRING
10 /
Í
44
7
KKE-M7111-00 HOLDER, BEARING
10
/
Í
45
8
KKE-M7112-00 PLATE 1, BRG.
10
/
Í
46
9
KKE-M7115-01 BRACKET, JOINT
10
/
Í
47
10
KHY-M7121-00
PULLEY, SHAFT
10 /
Í
48
11
KHY-M7122-00 NUT, SHAFT
10 /
Í
49
12
KHY-M7123-00 COLLAR, SHAFT
10 /
Í
50
13
KG7-M7137-A0 LEAF SPRING
20 E
51
14
90990-02J005 SET SCREW M3X2
20 52
15
90990-08J016 SCREW, PAN HEAD
40 53
16
90990-15J003 NUT, HEXAGON
10 54
17
KKE-M712C-01 COLLOR SPRING
10 /
Í
55
18
90990-22J009 PACKING
10
56
19
90933-02J104 BEARING
10
57
20
KKE-M7113-00 JOINT
10
/
Í
58
21
$PF-M3 PLUG
10 C
59
22
91312-03006 BOLT HEX. SOCKET HEAD
20
M3X6
60
23
91312-03030 BOLT HEX. SOCKET HEAD
20
M3X6
61
24
91312-03008 BOLT HEX. SOCKET HEAD
10
M3X6
62
25
91312-03010 BOLT HEX. SOCKET HEAD
10
M3X30
63
26
KHY-M712S-A0 SHAFT 2, SPARE
1 /
Í
64
27
KKE-M712B-00 SPRING, RETURN
10 A
Í
65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
