Main Conveyor Sub Assy A
Conveyor Unit (Dual Stage)
KKT-1101
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KKE-M9109-00 BRKT., CONV. MOTOR 1 /
Í
39
91312-04008 BOLT HEX. SOCKET HEAD 2
2
KKE-M9114-00 BRKT. 2, SPLINE
1
/
Í
40
KHY-M9157-00
SHAFT,MOTOR 1
/
Í
3
KHY-M9117-00 SPLINE 1 1
/
Í
41
KKV-M9119-00 SHAFT 1 /
Í
4
KKE-M9118-00 BRACKET, COLLAR 1 /
Í
42
5
KKE-M9119-A0 PULLEY CONV. ASSY. 2 /
43
6
KKE-M9120-A0 PULLEY CONV. ASSY 2 /
44
7
KKE-M9127-00 BELT 1, CONVEYOR 2
1250mm L=1400mm
A
45
8
KKE-M9128-00 BELT 222-3GT-9 1 /
Í
46
9
KG2-M9108-11 COLLAR CONVEYOR 2 /
Í
47
10
KGK-M9170-00 DC MOTOR ASSY. 1 B
Í
48
11
KGT-M9135-00 PULLEY 1, SPLINE 1 /
Í
49
12
KGT-M915U-00 PULLEY DRIVE, F 1 /
Í
50
13
KGT-M9193-00 NUT PLATE 4 /
Í
51
14
KGY-M9140-A0 PULLEY, CONV. ASSY 4 /
52
15
KH2-M9105-11 PULLEY, MOTOR:P30- 2 /
Í
53
16
KH2-M9121-00 BEARING 2 /
Í
54
17
KHY-M912A-01 BRKT., SENSOR 1 /
Í
55
18
KKE-M9135-00 PLATE, EDGE 2 8 /
56
19
KV1-M9140-A0 PULLEY CONV. ASSY. 2 /
57
20
90990-28J070 WASHER, PLAIN 1
58
21
91312-03010
BOLT HEX. SOCKET HEAD 4
59
22
91312-04006 BOLT HEX. SOCKET HEAD 2
60
23
91312-04008 BOLT HEX. SOCKET HEAD 5
61
24
91312-04010 BOLT HEX. SOCKET HEAD 3
62
25
91312-04055 BOLT HEX. SOCKET HEAD 4
63
26
91312-05006 BOLT HEX. SOCKET HEAD 2
64
27
91312-05010 BOLT HEX. SOCKET HEAD 2
65
28
91312-05020 BOLT HEX. SOCKET HEAD 2
66
29
92902-04200 WASHER, PLAIN 6
67
30
92902-05200 WASHER, PLAIN 10
68
31
92902-05600 WASHER, PLAIN 4
69
32
92A08-04303 SCREW, SET 6
70
33
98702-03005 SCREW, FLAT HEAD 16
71
34
KKE-M9109-10 BRKT., CONV. MOTOR 1 L>R /
Í
72
35
KKE-M9127-50 BELT 1, CONVEYOR 2
1540mm L=1710mm
A
73
36
KKE-M9113-00 BRKT.1, SPLINE 1 /
Í
74
37
90990-41J006 COLLAR 1 /
Í
75
38
91312-04005 BOLT HEX. SOCKET HEAD 2
76
7
5
