YS24X_mpl_je - 第95页
KKT -1204 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…
KKT-1101
14
15 (13 backside)
21
10
8
22
6
7
1
2
2
9
24
1
11
23
19
3
20
16, 17
16, 17
18
3
12
4, 5
14
13
25
27
26
27
26
13
1
Exterior, etc
Exterior, etc.
KKT-1204
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KGT-M5106-B0 SMT OPE.PANEL ASSY 2 STD (12V)
A
24
KKE-M669V-20 HNS, SWITCH START 1 for STD B
Í
KGT-M5119-03 SMT OPE.T.PANEL ASSY
2
Touch Panel A
KKE-M669V-30 HNS, SWITCH STOP 1 for STD B
Í
2 KKE-M1390-00 LCD STAY ASSY. 2 A
KKE-M669V-40 HNS, SWITCH ERR.CLR. 1 for STD B
Í
3 KGB-M3992-00 SWITCH SELECT 4 B
Í
KKE-M669V-50 HNS, SWITCH RESET 1 for STD B
Í
4 KW3-M5150-50 KEYBOARD J 1 A
KKE-M669V-00 HNS, SWITCH ACTIVE 1 for CE B
Í
5 KW3-M5150-60 KEYBOARD E 1 A
KKE-M669V-10 HNS, SWITCH READY 1 for CE B
Í
6 KW3-M5169-04 MOUSE 1 A
KKE-M669V-20 HNS, SWITCH START 1 for CE B
Í
7 KHY-M13B1-B0 BRKT. KEYBOARD ASSY. 1 /
KKE-M669V-60 HNS, SWITCH STOP 1 for CE B
Í
8 KGA-M13B5-00 MOUSE POCKET ASSY 1 /
KKE-M669V-70 HNS, SWITCH ERR. CLR. 1 for CE B
Í
9
KKE-M4899-00 LIGHT 1 (L=404) 1 R.Y.G A
Í
KKE-M669V-50 HNS, SWITCH RESET 1 for CE B
Í
KKE-M4899-10 LIGHT 1 (L=455) 1 R.Y.G A
Í
25 KJJ-M4580-24 I/O CONV. BOARD ASSY 1 B
Í
KKE-M4899-20 LIGHT 1 (L=555) 1 R.Y.G A
Í
26 KKE-M4570-01 I/O HEAD BOARD ASSY 2 B
Í
KKE-M4899-30 LIGHT 1 (L=654) 1 R.Y.G A
Í
27 KKE-M5802-01 HEAD SERVO UNIT ASSY 2 B
Í
KKE-M4899-40 LIGHT 1 (L=755) 1 R.Y.G A
Í
28
KKE-M4899-50 LIGHT 1 (L=854) 1 R.Y.G A
Í
29
KKE-M4899-60 LIGHT 1 (L=404) 1 W.B.G A
Í
30
KKE-M4899-70 LIGHT 1 (L=455) 1 W.B.G A
Í
31
KKE-M4899-80 LIGHT 1 (L=555) 1 W.B.G A
Í
32
KKE-M4899-90 LIGHT 1 (L=654) 1 W.B.G A
Í
33
KKE-M4899-A0 LIGHT 1 (L=755) 1 W.B.G A
Í
34
KKE-M4899-B0 LIGHT 1 (L=854) 1 W.B.G A
Í
35
10 KKE-M6554-00 MAIN SWITCH 1 B
Í
36
11 KGK-M6680-20 HNS, USB-MEMORY 2M AS 1 A
Í
37
12 KKE-M6185-20 FAN MOTOR ASSY 2 A
Í
38
13 KKE-M6185-60 FAN MOTOR ASSY 1 A
Í
39
14 KKE-M6185-00 FAN MOTOR ASSY 2 A
Í
40
15
KKE-M6185-70 FAN MOTOR ASSY 1 A
Í
41
16 KGS-M4896-01 LIGHT, ERR ASSY 1 for STD A
Í
42
17 KHG-M4896-01 LIGHT, ERR ASSY 1 for CE A
Í
43
18 KGK-M5138-00 SWITCH. EMG ASSY 2 B
Í
44
19 KHY-M8596-00 PRESSURE GAUGE 2 B
Í
45
20
KGY-M4268-00 USB MEMORY 1 YAMAHA /
46
KGY-M4268-10 USB MEMORY 1
ASSEMBLEON
/
47
21 KKE-M6185-10 FAN MOTOR ASSY 1 A
Í
48
22 KJJ-M4554-00 TERMINAL BOARD ASSY 1 B
Í
49
23 KKE-M6185-50 FAN MOTOR ASSY 2 A
Í
50
24
KKE-M669V-00 HNS, SWITCH ACTIVE 1 for STD B
Í
51
KKE-M669V-10 HNS, SWITCH READY 1 for STD B
Í
52
13
1
Exterior, etc
Exterior, etc.
KKT-100514
3
2
3
2
1
4
14
1
Head accessories
Head accessories
