SAFETY (EDISON)

Overview

1022330_6 11

Section C:

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Label Placement

Overview

Introduction Safety labels are placed throughout the printer to warn of risks when exposed to

specific areas. It is important that these labels remain intact. Refer to the following for

locations of these labels.

In this Section Refer to the following:

Topic See Page

Label Placement (Inside Front) 12

Label Placement (Wiper) 13

Label Placement (Outside Front) 14

Label Placement (Left and Right Sides) 16

Label Placement (Back) 17

Label Placement (Inside Door) 18

Label Placement (Solvent System) 19

Label Placement (Pneumatics Panel) 20

SAFETY (EDISON)

Label Placement (Inside Front)

12 Safety (Edison)

Label Placement (Inside Front)

Description Refer to the following:

Designator P/N Text

A 1008769 CAUTION. Falling hood can cause injury. Replace

hood gas struts yearly or if struts exhibit wear.

B P13001 N/A

C P13014 N/A

D P13000 N/A

Vision System

. . . . .

SAFETY (EDISON)

Label Placement (Wiper)

1022330_6 13

Label Placement (Wiper)

Description Refer to the following:

Designator P/N Text

A 1023236 Wiper Paper Path

Front Of Machine
