SAFETY (EDISON)
Overview
1022330_6 7
Section B:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Labeling
Overview
Introduction Safety labels attached to the printer in specific locations alert users to potential
hazards. It is important to understand the meaning of these labels.
Classification of
Hazards
The following Signal words are used on safety labels and are defined by SEMI S13-
0298 as follows:
Signal Word Description
Caution Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury. It
may be used to identify unsafe practices.
Warning Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
Danger Indicates a potentially hazardous situation which, if
not avoided, will result in death or serious injury.
SAFETY (EDISON)
Overview
8 Safety (Edison)
Pictographs The following label pictographs are used on the printer to call attention to cautionary
or other important information:
Part Number Pictograph Description
002213 CE certified
P10389 ROHS certified
P12273 Left fork here
P12274 Do not use forklift
P12289 Right fork here
P12400 Lock Out
P12976 High voltage (risk of electric
shock)
P12997 Risk of hand crush (from force
from above)
P13000 Risk of hand cut (from moving
parts)
P13001 Risk of hand entanglement
(from notched belt drive)
. . . . .
SAFETY (EDISON)
Overview
1022330_6 9
P13008 Wear protective gloves
P13011 Wear eye protection
P13012 Protective earth, electrical
P13014 Electrostatic sensitive device
Part Number Pictograph Description
