35.ﾘｰﾙｾｯﾄ台(CSPJ)
35.Feeder setting jig(CSPJ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 WPJ0681 1 BASE ﾍﾞｰｽ FE
2 WPJ0690 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 FE
3 WPJ0700 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 FE
4 WPJ0710 1 CLAMPER ｸﾗﾝﾊﾟ FE
5 WPJ0721 1 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け FE
6 WSD0013 2 CLAMPER ｸﾗﾝﾊﾟ FE
7 WSD0641 2 BOLT ﾎﾞﾙﾄ FE
8 WSD0652 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
9 H4435T 2 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1150ZZ FE
10 R5025T 2 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ 5ﾟX10 OT
11 W1013A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
12 W1012A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L FE
13 W1011A 12 WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L FE
14 H5321A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12 FE
15 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15 FE
16 H5289A 12 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12 ･ FE
CP-643E PARTS LIST
35 - 2
35.ﾘｰﾙｾｯﾄ台(CSPJ)
35.Feeder setting jig(CSPJ)
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
20
21
60
21
21
58
20
22
21
60
59
22
40
37
33
37
31
40
37
45
40
37
45
37
31
40
37
33
49
26
27
27
5
36
39
42
28
66
37
46
13
15
16
9
47
64
30
33
37
40
36
39
42
44
3
29
38
63
23
4
24
25
24
24
11
24
36
39
42
44
32
37
19
32
37
19
61
52
8
14
17
15
16
37
62
45
37
65
18
37
33
2
43
21
60
21
21
60
20
21
20
56
22
57
22
45
37
40
31
37
33
37
40
45
37
40
40
37
33
31
37
48
8
46
32
37
19
66
3732
37
19
28
6
36
39
42
26
27
27
3
24
25
24
24
12
24
44
36
39
42
23
4
51
61
62
37
44
36
39
42
29
38
63
33
37
40
30
64
10
9
33
37
18
65
37
45
17
15
16
14
43
1
x8
C
C
A
C
B
A
B
36 - 1
36.シャッタ(オプション)(CSAF)
36.Shutter(Option)(CSAF)
36.シャッタ(オプション)(CSAF)
36.Shutter(Option)(CSAF)
CP-643E PARTS LIST
36.ｼｬｯﾀ(ｵﾌﾟｼｮﾝ)(CSAF)
36.Shutter(Option)(CSAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 WAF1275 1 BKT, FENCE BKT ﾌｪﾝｽ FE
2 WAF1266 1 BKT, FENCE BKT ﾌｪﾝｽ FE
3 WAF2040 2 BKT BKT FE
4 WAF2050 2 BKT BKT FE
5 WAF2062 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
6 WAF2072 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
8 AWAF8550 2 PLATE ﾌﾟﾚｰﾄ OT
9 WAF1210 2 RAIL ﾚｰﾙ AL
10 WAF1220 1 RAIL ﾚｰﾙ AL
11 WAF1521 1 HOLDER ﾎﾙﾀﾞ AL
12 WAF1531 1 HOLDER ﾎﾙﾀﾞ AL
13 WAF1571 2 BALANCER ﾊﾞﾗﾝｻ FE
14 AWAF8560 2 COVER ｶﾊﾞｰ OT
15 WAF2430 2 WIRE, STAINLESS STEEL ﾜｲﾔ ｽﾃﾝﾚｽ OT
16 K3017A 4 CLIPPER, WIRE ｸﾘｯﾊﾟ ﾜｲﾔ For ﾟ1.5 OT
17 GXZ0230 2 COLLAR ｶﾗｰ FE
18 GXZ0251 2 PLATE ﾌﾟﾚｰﾄ FE
19 GXZ0240 4 PLATE ﾌﾟﾚｰﾄ FE
20 GXZ0350 4 PIN ﾋﾟﾝ FE
21 H4134X 8 BEARING ﾍﾞｱﾘﾝｸﾞ F604ZZ FE
22 GXZ0360 4 COLLAR ｶﾗｰ FE
23 GXZ0300 2 BAR ﾊﾞｰ FE
24 H4282A 8 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ KH1228 FE
25 GXZ0181 2 HOLDER ﾎﾙﾀﾞ AL
26 S2099T 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDM2B-20-D7481-250 OT
27 K5330B 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ SC6-01-B OT
28 GXZ0270 2 BOLT, JOINT ﾎﾞﾙﾄ ｼﾞｮｲﾝﾄ FE
29 GXZ0310 2 WASHER ﾜｯｼｬ FE
30 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L FE
31 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
32 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
33 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
35 H5304A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X25L FE
36 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
37 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
38 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
39 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
40 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
42 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
43 K5207A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X5L FE
44 N4036A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X5L FE
CP-643E PARTS LIST
36 - 2
36.ｼｬｯﾀ(ｵﾌﾟｼｮﾝ)(CSAF)
36.Shutter(Option)(CSAF)
