4.2.ｱｳﾄｺﾝﾍﾞｱ(CSQC)
4.2.Out conveyor(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
204 CSQC2461 1 BKT BKT FE
205 CSQC2473 1 BKT BKT FE
206 CSQC2481 1 RAIL ﾚｰﾙ FE
207 CSQC2491 1 RAIL ﾚｰﾙ FE
208 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X6L FE
209 CSQC2430 1 BKT BKT FE
210 CSQC2440 1 BKT BKT FE
211 CSQC0870 1 BKT BKT FE
212 CSQC0880 1 BKT BKT FE
213 CSQC0901 4 LOCATOR 当金 FE
214 N1085A
NUT, HEX
ﾅｯﾄ 六角 M6 FE
215 CSQC1430 1 PIN ﾋﾟﾝ FE
216 CSQC0982 1
BOLT
ﾎﾞﾙﾄ X-No.590∼ FE
217 K5347K 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2301FM-01-06S OT
218 Y3066X 2 UNION ﾕﾆｵﾝ KQ2E06-01 OT
219 K50764 2 CONNECTOR ｺﾈｸﾀ KQ2U06-01S OT
220 H5263C
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X16L FE
221 H5292T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X22L FE
225 CSQC2850 1 LEVER ﾚﾊﾞｰ FE
226 CSQC2860 1 BKT BKT FE
227 CSQC2642 1 HOLDER ﾎﾙﾀﾞ FE
228 CSQC2650 1 HOLDER ﾎﾙﾀﾞ FE
229 CSQC2661 1 RAIL ﾚｰﾙ FE
230 H5299A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
231 S3020Y 1 SPRING ｽﾌﾟﾘﾝｸﾞ WH10-15 FE
232 K1090A 1 CAM FOLLOWER ｶﾑﾌｫﾛｱ CFS04 OT
233 CSQC1460 1 NAMEPLATE 銘板 PL
234 CSQC1560 2 BKT BKT FE .
CP-643E PARTS LIST
4 - 10
4.2.ｱｳﾄｺﾝﾍﾞｱ(CSQC)
4.2.Out conveyor(CSQC)
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
0.5 1 2 10
44
45
46
逆流れ(Option)
Right-to-left
board flow
逆流れ(Option)
可動ストッパ
Movable stopper
(Option)
Right-to-left
board flow
57
68
46
45
68
57
92
66
70
70
70
16
66
48
10
63
69
73
11
63
69
73
66
48
16
49
66
70
25
44
44
49
66
70
70
70
16
12
48
66
63
69
73
26
48
66
16
49
66
70
63
69
73
13
1
67
80
79
67
67
52
76
77
75
77
76
75
47
5
65
28
21
68
58
66
86
88
88
87
84
86
85
91
19
67
52
21
52
67
19
64
74
23
1
68
58
1
68
58
24
35
35
36
36
51
67
38
38
18
29
30
61
69
66
48
27
8
67
51
68
58
23
89
67
55
9
80
79
19
21
51
67
17
36
36
22
56
37
35
35
38
38
37
2
59
68
54
67
21
20
47
5
65
28
4
3
60
68
72
71
67
53
71
67
53
74
64
4
3
60
68
72
6
68
58
C
B
A
A
C
B
X8
89
67
55
89
90
67
55
52
67
68
83
68
83
67
81
14
59
68
72
81
15
82
15
59
68
72
52
5 - 1
5.ローダユニット(CSQL)
5.Loading unit(CSQL)
5.ローダユニット(CSQL)
5.Loading unit(CSQL)
CP-643E PARTS LIST
5.ﾛｰﾀﾞﾕﾆｯﾄ(CSQL)
5.Loading unit(CSQL)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
1 CSQL0010 3 BKT, VALVE BKT ﾊﾞﾙﾌﾞ FE
2 CSQL0022 1 BKT, VALVE BKT ﾊﾞﾙﾌﾞ FE
3 CSQL0361 2 BKT, SENSOR BKT ｾﾝｻ FE
4 CSQL0370 2 BKT, SENSOR BKT ｾﾝｻ FE
5 CSQL0050 2 FIXTURE 固定具 FE
6 CSQL0431 1 DUCT ﾀﾞｸﾄ FE
8 CSQL0320 1 BKT BKT FE
9 CSQL0331 1 PLATE ﾌﾟﾚｰﾄ FE
10 CSQL0110 1 BKT BKT FE
11 CSQL0120 1 BKT BKT FE
12 CSQL0130 1 BKT BKT FE
13 CSQL0141 1 BKT BKT FE
14 CSQL0392 1 BKT BKT FE
15 CSQL0380 2 BKT BKT FE
16 CSQL0171 4 BKT BKT FE
17 CSQL0181 1 BKT BKT FE
18 CSQL0192 1 BKT BKT FE
19 CSQL0200 3 PLATE ﾌﾟﾚｰﾄ FE
20 CSQL0210 1 PLATE ﾌﾟﾚｰﾄ FE
21 CSQL0220 4
BOLT, ADJUSTING
ﾎﾞﾙﾄ ｾﾘ FE
22 ACSQL0230 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL OT
23 ACSQL0240 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL OT
24 ACSQL0250 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL OT
25 CSQL0261 1 CYLINDER, RODLESS ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ OT
26 CSQL0271 1 CYLINDER, RODLESS ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ OT
27 A1038L 2 AMPLIFIER ｱﾝﾌﾟ E3X-NH11 OT
28 H30011 2 FIBER UNIT ﾌｧｲﾊﾞ ﾕﾆｯﾄ E32-D32-25 OT
29 A4063E 1 ELBOW ｴﾙﾎﾞ QMQ6-5M812 OT
30 CSQL0441 1 BKT, PIPING BKT 配管 FE
35 K5338D 8
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1211F-M5-06(ｼﾛ) OT
36 Y3044A 8
UNION
ﾕﾆｵﾝ M-5E OT
37 N2033T 8
NIPPLE
ﾆｯﾌﾟﾙ KQN06-99 OT
38 Y3049L 8
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5(ｼﾛ) OT
44 Y3061W 4
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KJS06-M5(ｼﾛ) OT
45 CSWZ0032 1 PLATE ﾌﾟﾚｰﾄ FE
46 CSWZ0121 1 PLATE ﾌﾟﾚｰﾄ X-No.852∼ FE
47 H5265A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M2X5L FE
48 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X5L FE
49 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
51 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
52 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
CP-643E PARTS LIST
5 - 2
5.ﾛｰﾀﾞﾕﾆｯﾄ(CSQL)
5.Loading unit(CSQL)
