CP-643E-08 - 第43页
6.1.基板ｸﾗﾝﾌﾟ(CSSS) 6.1.Board clamping unit(CSSS) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 82 DCSS0390 1 JAW 爪 注1. Note.1 FE 83 W10012 2 WASHER ﾜｯｼｬ 70W-1000 FE …
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
4 WSS4640 2 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
12 H1162T 2
PACKING
ﾊﾟｯｷﾝ MY-7 OT
13 H1167H 2
PACKING
ﾊﾟｯｷﾝ MY-24 OT
14 S2147A 2
JOINT
ｼﾞｮｲﾝﾄ BF6 OT
15 H3119A 2 PLUG ﾌﾟﾗｸﾞ PF OT
23 S1023A 6
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-5 FE
24 WSS5380 2 SHEET, RUBBER ｼｰﾄ ｺﾞﾑ OT
25 YSS0540 2 WASHER ﾜｯｼｬ FE
26 YSS0570 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
35 CSSS0791 1 RAIL ﾚｰﾙ AL
36 CSSS0801 1 BLOCK ﾌﾞﾛｯｸ AL
37 CSSS0812 1 BLOCK ﾌﾞﾛｯｸ AL
39 CSSS0820 1 BKT BKT FE
40 CSSS0071 2 BKT BKT FE
42 CSSS0863 1 BKT BKT FE
43 CSSS0111 3 BOLT ﾎﾞﾙﾄ FE
44 CSSS0121 3 PIN ﾋﾟﾝ FE
45 CSSS0130 1 WASHER ﾜｯｼｬ FE
46 CSSS0141 4 WASHER ﾜｯｼｬ PL
47 CSSS0150 1 WASHER ﾜｯｼｬ FE
48 CSSS0160 1 COLLAR ｶﾗｰ FE
49 CSSS0170 40 COLLAR ｶﾗｰ FE
50 CSSS0180 1 COLLAR ｶﾗｰ FE
51 CSSS0191 2 WASHER ﾜｯｼｬ PL
52 CSSS0200 1 WASHER ﾜｯｼｬ FE
53 CSSS0210 1 WASHER ﾜｯｼｬ FE
54 CSSS0934 1 SHAFT ｼｬﾌﾄ FE
55 CSSS0270 1 COLLAR ｶﾗｰ FE
56 CSSS0280 4 CLAMPER ｸﾗﾝﾊﾟ FE
57 CSSS0291 2 COLLAR ｶﾗｰ FE
59 CSSS0321 2 SEAL ｼｰﾙ PL
61 CSSS0851 1 LEVER ﾚﾊﾞｰ FE
67 CSSS0925 1 RAIL ﾚｰﾙ AL
68 CSSS1311 1 LEVER ﾚﾊﾞｰ FE
69 CSSS1023 1 SHAFT ｼｬﾌﾄ FE
75 CSSS1411 3 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
76 CSSS1261 1 LEVER ﾚﾊﾞｰ FE
77 CSSS1010 1 BKT BKT X-No.1087∼ FE
78 CSSS0620 1 PIN, PIVOT ﾋﾟﾝ 支点 FE
80 CSSS0612 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
81 W1001Y 1 WASHER ﾜｯｼｬ 70W-0815 FE
CP-643E PARTS LIST
6 - 3
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
82 DCSS0390 1 JAW 爪 注1. Note.1 FE
83 W10012 2 WASHER ﾜｯｼｬ 70W-1000 FE
84 DCSS0400 1 JAW 爪 注2. Note.2 FE
85 H4128R 2
BEARING
ﾍﾞｱﾘﾝｸﾞ L-1790 FE
86 DCSS0410 42 JAW 爪 注3. Note.3 FE
87 K5075A 2
CONNECTOR
ｺﾈｸﾀ KQU06-00 OT
88 R2074C 1 RING, LOCKING ﾘﾝｸﾞ 締結 UM-6X18 OT
89 H3253T 4 ELBOW ｴﾙﾎﾞ BBM5-M5 OT
90 WSS4612 2 PISTON ﾋﾟｽﾄﾝ OT
91 H4402D 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA79Z FE
92 H4386A 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA0815Z FE
93 N2031A 4
JOINT
ｼﾞｮｲﾝﾄ M-5H-6 OT
94 A40682 5 ELBOW ｴﾙﾎﾞ M-5HL-6 OT
99 N1067A NUT U ﾅｯﾄ U M6 FE
100 CSSS1480 2
BOLT, HEX
ﾎﾞﾙﾄ 六角 OT
101 N1081T
NUT, HEX
ﾅｯﾄ 六角 M4 P=0.7 3ｼｭ FE
102 N1085A BKT, CYLINDER BKT ｼﾘﾝﾀﾞ M6 P=1.0 OT
103 CSSS0892 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
104 CSSS1090 1 BKT BKT FE
105 CSSS1470 1 BKT BKT R→L(Option) FE
106 A4090A 2
ELBOW, UNIVERSAL
ｴﾙﾎﾞ ﾕﾆﾊﾞｰｻﾙ M-5UL OT
108 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
109 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X10L FE
110 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X12L FE
111 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
113 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
115 H5293A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X25L FE
116 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X10L FE
118 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X15L HRC34-44 FE
120 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
121 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
122 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
123 K5359E
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X8L FE
124 .
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X10L FE
125 W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4 FE
126 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
127 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
128 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
129 K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L FE
130 WSS5300 2 STOPPER ｽﾄｯﾊﾟ OT
131 CSSS1081 1 RETAINER 押え FE
CP-643E PARTS LIST
6 - 4
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
132 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
133 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X6L FE
134 CSSS1320 42 JAW 爪 注3. Note.3 FE
135 CSSS1330 44 RETAINER 押え FE
136 AWSS8710 2 PISTON ﾋﾟｽﾄﾝ OT
137 CSSS1440 1 BKT, SENSOR BKT ｾﾝｻ FE
138 CSSS0730 1 SPACER ｽﾍﾟｰｻ FE
139 CSSS1450 1 DOG ﾄﾞｯｸﾞ FE
140 CSSS0830 1 BKT BKT FE
141 CSSS0840 1 BKT BKT FE
142 CSSS0900 1 BKT BKT FE
143 CSSS0942 1 LEVER ﾚﾊﾞｰ FE
144 CSSS0951 1 WASHER ﾜｯｼｬ PL
145 CSSS0960 1 WASHER ﾜｯｼｬ FE
146 CSSS0970 1 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ FE
147 CSSS1001 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
148 CSSS1040 1 COLLAR ｶﾗｰ FE
149 CSSS1051 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
150 CSSS1240 1 JAW 爪 注1. Note.1 FE
151 CSSS1250 1 JAW 爪 注2. Note.2 FE
152 CSSS1270 1 BKT BKT FE
153 CSSS1291 1 BKT, HOLDER BKT ﾎﾙﾀﾞ FE
154 CSSS1302 1 BKT BKT FE
155 CSSS1400 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動 OT
156 H4401A
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA69Z OT
157 S4045C SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX870A OT
158 H5281A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X25L FE
159 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
160 K51780 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X18L FE
161 W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5 FE
162 N1080A
NUT, HEX
ﾅｯﾄ 六角 M4 FE
163 A4068T 1 ELBOW ｴﾙﾎﾞ M-5ALU-6 OT
164 N2030A 1 ELBOW ｴﾙﾎﾞ M-5ALHU-6 OT .
注1.(仕様選択部品)CSSS1240(標準),DCSS0390(爪先にｺﾞﾑ溶着ﾀｲﾌﾟ)
Note.1:(Specified parts selection)CSSS1240(Standard),DCSS0390(With rubber)
注2.(仕様選択部品)CSSS1250(標準),DCSS0400(爪先にｺﾞﾑ溶着ﾀｲﾌﾟ)
Note.2:(Specified parts selection)CSSS1250(Standard),DCSS0400(With rubber)
注3.(仕様選択部品)CSSS1320(標準),DCSS0410(爪先にｺﾞﾑ溶着ﾀｲﾌﾟ)
Note.3:(Specified parts selection)CSSS1320(Standard),DCSS0410(With rubber)
CP-643E PARTS LIST
6 - 5
6.1.基板ｸﾗﾝﾌﾟ(CSSS)
6.1.Board clamping unit(CSSS)
