Introduction ■ System Description
1—8 Data I/O • 981-0424-002
back
•ID check
•Erase
•Blank check
•Program
• Verify programming
•Read
• Illegal-bit check
• Functional verification operations
• Secure device
• Verify options such as voltage
3. (Optional) ICOS System device inspect
Inspection system by ICOS detects bent leads on devices prior to fur-
ther processing.
4. (Optional) Mark devices—
When marking is selected, devices that pass the programming and
verification operations are moved to a pedestal on the Shuttle
Transfer Assembly which delivers them to a Label Marker or Laser
Marker where they are marked for identification.
5. Load devices into the output media—
Devices are moved by the PNP head from the programming socket or
the marking pedestal and placed in output media: trays, tubes, or
tape. Devices that failed the programming operation or subsequent
verification are delivered to a dedicated Reject Bin or other reject
module where they are held for failure analysis or other disposition.
Input and Output Options
PS System input and output options are: static tray (manual), tray
feeder (automatic), tube, and tape.
Any combination of input and output options may be used. For
example, the PS System can be configured with input as static tray
and output as tube, or input as tape and output as static tray.
■ System Description ◘ PS588 Specifications
PS Series Owner’s Manual 1—9
back
PS588 Specifications
Specifications are without optional equipment.
1
Since the monitor arm rotates, length and width dimensions can be
adjusted inversely, up to 13 cm (5 inches). For example, if you sub-
tract 13 cm from length, then add 13 cm to width.
FACILITIES
Air Pressure clean, dry, oil-free air at 621-827
kilopascals (90 to 120 PSI)
Air Flow 85 liters/minute (3 SCFM) constant
AC Input Voltage 208–240 VAC, single phase
AC Input Frequency 50–60 Hz
AC Input Power (max) 10 Amps
PS588 DIMENSIONS
Length (including monitor)
1
178 cm (70 inches)
Width (including monitor)
1
114 cm (45 inches)
Height + [light tower] 163 cm (64 inches) [56 cm, 22 in.]
Weight 600 kg (1330 lbs)
ENVIRONMENT
Operating Temperature +13° to +30° C (+55° to +86° F)
Relative Humidity 35% to 90% non-condensing
Introduction ■ System Description
1—10 Data I/O • 981-0424-002
back
PS288 & PS388 Specifications
Specifications are without optional equipment.
1
Since the monitor arm rotates, length and width dimensions can be
adjusted inversely, up to 13 cm (5 inches). For example, if you sub-
tract 13 cm from length, then add 13 cm to width.
FACILITIES
Air Pressure clean, dry, oil-free air at 621-827
kilopascals (90 to 120 PSI)
Air Flow 85 liters/minute (3 SCFM) constant
AC Input Voltage 208-240 VAC, single phase
AC Input Frequency 50–60 Hz
AC Input Power (max) 10 Amps
PS288/PS388 DIMENSIONS
Length (including monitor)
1
127 cm (50 inches)
Width (including monitor)
1
112 cm (44 inches)
Height + [light tower] 163 cm (64 inches) [56 cm, 22 in.]
Weight 364 kg (800 lbs)
ENVIRONMENT
Operating Temperature +13° to +30° C (+55° to +86° F)
Relative Humidity 35% to 90% non-condensing
