Glossary ■ Q PS Series Owner’s Manual Glossary—5 back pick position ~ The physical positions where the pick-and -place head pi cks up de vices such as at the input media and at sock ets. PLC Contr oller ~ T aping Module …

Glossary ■ M

Glossary—4 Data I/O • 981-0424-002

back

lead ~

The connection legs that extend from the body of a device.

Leader ~

(Applies to Tape Output System) The length of empty carrier tape required at the

beginning of the finished reel of taped devices.

LED ~

Light Emitting Diode

LED ~

Light Emitting Diode.

Light Tower ~

The pole on top the PS System with colored lights indicating different machine

statuses.

mA ~

milliampere

Main Window

AH500-PS288/PS588 main window. This is the first window to display when the

AH500 starts after clicking RUN in TaskLink. The window title bar simply says

PS288 or PS588.

Marker ~

A system to inscribe identification onto devices, in this case by a laser.

MB ~

Megabyte; 1,048,576 bytes (1,024 x 1,024, or 1024

μBGA

Micro Ball Grid Array. Sometimes written as MBGA.

MCBI ~

Mean Count Between Interruption

menu ~

A screen display that lists available command choices.

NVM ~

Non-Volatile Memory

NVRAM ~

Non-Volatile Random Access Memory

OEM ~

Original Equipment Manufacturer.

OPTIMA Program-

mer

A Flash programmer with many Socket Adapters and Tops making it useful in

programming a large variety of different package types such as logic devices

and older Flash EEPROMs.

Option Bay ~

The cabinet that attaches to the back of any PS Machine, which can house a

Laser Marking System and a Tape Output System.

P&P Head ~

See PNP.

Package File ~

A package file contains information about the physical dimension of a specific

device package and associated Socket Adapter, as well as position information

of each socket on the workspace.

Park Position ~

A place at the back, right corner of the workspace where the PNP Head stops

after a job is stopped.

PC ~

Personal Computer.

PCI ~

Peripheral Component Interconnect. A standard for connecting peripherals to a

personal computer.

Pick and Place

Head

The mechanism that supports the probe that picks up and places devices.

Glossary ■ Q

PS Series Owner’s Manual Glossary—5

back

pick position ~

The physical positions where the pick-and-place head picks up devices such as

at the input media and at sockets.

PLC Controller ~

Taping Module toggle switches

PNP ~

Pick and Place. Also referred to as P&P.

PNP Head ~

The Pick and Place Head controlled by the Gantry for moving devices between

sockets and media.

PNP Taping Head ~

The pick and place head on the Tape Output Module.

pocket tape ~

The pocketed film that carries the devices. This term usually implies that the

cover tape has been removed. Also called device pocket tape.

Power Panel ~

Panel on the back of the PS Machine where AC power and air are connected.

probe ~

A tube attached to the pick and place head that picks up, carries, and releases

devices. Usually a probe has a rubber tip on the end that allows it to create a

good vacuum seal on the device.

Programmer

A FlashCORE or Universal assembly that accepts Socket Adapters and programs

the devices.

programming ~

The process of electronically writing data into a device. (Burning is another term

used to describe this operation.) “Input devices” are usually blank or un-pro-

grammed; “output devices” are usually programmed devices.

programming mod-

ule

Module that contains the programming electronic circuit boards required to pro-

gram a device in the socket.

PSI ~

Pounds per Square Inch; a measurement of pressure. One PSI = 0.07031 kg per

Puff ~

A surge of air through the pick and place probes to release a device.

Pv ~

A designation used to indicate the programmer closest to the vision camera, or

its label.

QFP ~

Quad Flat Pack.

A high-speed memory location in a computer's CPU.

Reject Tray

A tray or box that holds the rejected devices. May also be call a Reject Tray.

Safety Shield ~

One of the plastic, hinged doors that allow access to the workspace. See also,

Access doors.

SCFM ~

Standard Cubic Feet per Minute, a measurement of flow.

SHCS ~

Socket Head Cap Screws

semiconductor ~

A programmable integrated circuit. Also called “devices,” they are made of a

material whose electrical conductivity is between that of a conductor and that of

an insulator.

Servo Motor Ampli-

fiers

SHCS ~

Socket-Head Cap Screw

Glossary ■ T

Glossary—6 Data I/O • 981-0424-002

back

Shuttle Carriage ~

The part of the Shuttle Pedestal that clamps to the belt.

Shuttle Pedestal ~

A small round support, or table top, that holds a device, It is part of the Shuttle

Transfer System.

Shuttle Transfer

System

The belt-driven shuttle system that transports devices to a marker, labeler, or a

Tape Output System.

SNS ~

Serial Number Server

Socket Adapter ~

A part that allows a socket to fit the programmer.

Socket Adapter

Board

A printed circuit board that connects to the Backplane Board to supply the elec-

trical connections for programming devices.

socket module ~

The device-specific part of the programmer that holds a device in place so that it

can be programmed.

SRAM ~

Static Random Access Memory

Start ~

To load and initialize the operating system on a computer. Synonyms: boot.

Tape feeder ~

See Chip Feeder.

Tape Output

Tape Output Sys-

tem

Attached to the back of the Option Bay, the (modified) TM?50 Taping Module

(V-TEK) places programmed devices into device tape.

TaskLink ~

Data I/O’s software for creating programming jobs for PS Series Programmers

(as well as RoadRunner, FlashPAK, FLX500, Sprint™ Family Programmers and

UniSite™ family Programmers). It is a Windows

 based program that simplifies

task management.

teach ~

To communicate your directives to the system via software routines.

throughput ~

The rate at which correctly-programmed devices are produced.

tip ~

A rubber fitting often inserted onto the end of a probe that allows it to achieve

the vacuum seal required to pick and hold a device.

Trailer ~

(Applies to Tape Output System) The length of empty carrier tape required at the

end of the finished reel of taped devices.

Tray Feeder ~

The TF 20 Tray Feeder mounts onto PS Systems to automatically deliver trays of

unprogrammed devices to the work space and return full trays to the stack of

programmed device trays.

TSOP ~

Thin Small Outline Package.

Universal

Programmer

See Optima Programmer

vacuum tool ~

A hand tool that uses suction to manipulate objects. “Handy-Vac” is such a tool.

DAC ~

Voltage Collector Common Digital to Analog Converter. Used to generate the sup-

ply power for the devices to be programmed or verified.

VDC ~

Volts (of) Direct Current

verify ~

A device operation that compares data in a programmed device with data in

RAM or in a disk file. With logic devices, verifying can also include functional

testing.
