Index • K+ PS Series Owner’s Manual Index—3 K Keyboard and Touchpad, description 1-15 L Label Printing 3- 60 label type 3-61 setting up 2-28 Languate changing 1-3 Laser Filters determining c ontents 1-26 handling and sto…

Index • F+

Index—2 Data I/O • 981-0424-002

Emergency Stop

Button locations 3-23

description 1-4

function 3-22

Warning 3-22

End a Job 3-24

Environmental Requirements

PS288 & PS388 1-10

PS588 1-9

Errors teaching package file 3-50

ESD

precautions 1-6

Strap connection 1-15

Ethernet address for Laser Marker 2-27

External air 2-3

Facilities Required

PS288 & PS388 1-10

PS588 1-9

Fail Retries 3-18

Feeder Unit

aligning pick point 2-19

setting pitch 2-19

teaching location for package file 3-49

Firmware Update

see TaskLink’s online Help file

First Article Test

after Vision & Pkg files 3-33

before Vision & Pkg files 3-32

on FlashPAK 3-32

on PS Machine 3-33

FlashCORE Programmers

about 1-13

diagnostics 4-29

per PS Model 1-3

removing 4-30

FlashPAK 3-32

Footnotes Dialog 3-11

Frimware updates 4-48

Fume Extractor

replacing pleated filter 4-41

Functional Block Diagram 4-70

Fuses, Gantry 4-65

Gantry

description 1-12

Lead Screw grease fittings 4-27

trouble 4-65

Gantry, fuses 4-65

Get Movetimes 3-51

Goggle rating, laser protection 1-16

Ground connection 1-15

Handler Computer

overview 1-14

Handler Software

main window 1-21

HIC Adapters 3-4

HIC Socket Openers 3-5

ICOS Inspection System 3-17

Ignore Programmers feature 3-18

Input media 3-16

Input/Output Modules

Automatic Tray Feeder 2-10

standard and optional combinations 1-8

tube 2-12

Input/Output Tray 2-7

Inspection system 3-17

Installation 2-1

room size 1-28

Installation of PS Machine 1-28

Installing

Probe tips 3-7

Programmers, contact support

Socket Adapters, FC 3-3

Socket Adapters, Optima 3-6

Interface Cable, Tape Feeder 2-18

Job Statistics 3-53

“I don’t see Kibibit in here. It should be here.”

Let us know about any items you can’t find by e-mailing

userdocs@dataio.com

Index • K+

PS Series Owner’s Manual Index—3

Keyboard and Touchpad, description 1-15

Label Printing 3-60

label type 3-61

setting up 2-28

Languate

changing 1-3

Laser Filters

determining contents 1-26

handling and storage 1-27

replacing pleated filter 4-41

Laser Marking File

creating 3-62

to 3-68

editing 3-64

loading image file 3-65

template.mkh 3-64

verifying laser operation 3-67

Laser Marking System

ethernet address 2-27

safety interlock description 1-25

set up 2-27

specifications 1-25

Laser protection goggle rating 1-16

Laser template settings 3-64

Light colored devices, programming 2-26

Light Tower

colors 3-25

description 1-12

monitoring 3-25

Log Files

collecting 4-59

Log files 4-59

Machine

comparison 1-3

envelope 1-29

Machine envelope 1-29

Main air pressure 2-3

Maintenance, interval table 4-2

Mark devices only 3-18

Marking System

description 1-15

Master Device 3-58

Movetimes

teaching in the package file 3-51

Network Communication

Opener pressure 2-3

Openers vs. Actuators 1-13

Operator Functions 3-2

checking system readiness 3-2

switching on power 3-10

starting TaskLink and loading job 3-10

preselecting programmers 3-13

configuring input/output settings 3-16

checking input/output media 3-20

stopping the system 3-22

shutting down the system 3-27

clearing a disabled socket 3-26

disabling a programmer 3-26

light tower explanation 3-25

Operator Grounding connection 1-15

Operator Mode 3-33

Optima programmers

about 1-13

Optima Support Kit 1-13

Optimize Movetimes 3-51

Options tab 3-16

Output media 3-16

Package File

description 3-40

movetimes 3-51

Reject Bin locations 3-46

Shuttle locations 3-48

Tape Input 3-49

Teaching 3-40

Tray locations 3-44

Tube locations 3-46

Package Statistics 3-54

Part Number

see the part name

part numbers 3-9

Passwords 3-31

Pause programming 3-23

PC Backup system 4-1, 4-68

PC Drive Failure 4-68

Pick and Place Head (PNP)

description 1-12

Pin 1 3-21, 3-43

Index • R+

Index—4 Data I/O • 981-0424-002

Pitch

adjusting on tape input feeder 2-19

Pneumatic Input Requirements 2-2

PNP. See Pick and Place Head (PNP)

Pocket Empty Sensor 4-76

Porbllems

capturing information 4-59

Power

applying first time 2-5

switching on 3-10

Power Cable, connecting 2-3

Preventive Maintenance

interval table 4-2

Printer

label 3-60

laser 3-62

Probe

Breakaway tip 3-7

part numbers 3-7

sizes 3-7

Probe Tips 3-7

Process Errors, yields 3-58

Programmer

diagnostics 4-29

disabling 3-26, 4-63

per PS Model 1-3

replacing FC 4-30

types 1-13

Programming Yields

maximizing 3-57

monitoring statistics 3-52

process errors 3-58

socket issues 3-57

system maintenance 3-58

PS Machine

comparison 1-3

envelope 1-29

Reference Vision File

description 3-34

Teaching 3-34

to 3-40

Reference Vision File Teaching 3-34

to 3-40

Regulator

Red number 2-3

Reject 2 3-21

Reject Bin

installing 2-9

teaching locations 3-46

Removing

Socket Adapters, FC 3-4

Socket Adapters, Optima 3-6

Repair information --x

Requirements

electrical 2-3

pneumatic 2-2

room ventilation 1-28

Restart E-Stop 3-23

Restarting after trouble 4-58

Retries, programming 3-18

Rotation Values 3-43

Run One 3-33

Running a job 3-21

Safety

main precautions 1-23

symbols --x

Safety Interlocks

laser marking system 1-25

Safety Shields

cleaning 1-5

description 1-15

how to use 1-5

Security Profiles 3-31

see TaskLink online Help

Serial number 1-11

Serialization, with marker 3-62

Setting PS Options 3-16

Setup 3-16

Setup Window 3-16

Shutting down 3-27

Shutting Off 4-4

Shuttle Belt

adjusting 4-36

replacing 4-37

Shuttle Cups 3-9

installing 3-9

Shuttle locations

teaching in the package file 3-48

Socket Actuator

setting air pressure 4-8

Socket Actuator Pressure Regulator 2-3

Socket Actuator Sensor

adjusting 4-5

Socket Adapter

cleaning 3-57

installing, FC 3-3

installing, Optima 3-6

part number 3-11

removing, FC 3-4

removing, Optima 3-6
