Introduct ion ■ Room Considerations 1—30 Data I/O • 981-0424-002 back

■ Room Considerations ◘ Access Space

PS Series Owner’s Manual 1—29

back

For example, a PS588 with laser marking equipment (Option Bay)

requires a minimum area of 3.5 meters long x 3.1 meters wide for

easy access.

Figure 1-14: Maximum envelope of PS388 with Option Bay and Tape

Output (approximate; to scale).

Envelope, L x W 

PS Machine 

PS only PS + Option Bay PS + Tape Out

PS288 / PS388

Use min. ventilation

size; see previous

heading Ventilation.

3.0 x 3.1 m 3.3 x 3.5

PS588

Use min. ventilation

size; see previous

heading Ventilation.

3.5 x 3.1 m 3.8 x 3.5

Keyboard

PS288 / PSS388

Option Bay

Tape Out

(max. size)

Introduction ■ Room Considerations

1—30 Data I/O • 981-0424-002

back

PS Series Owner’s Manual 2—1

Chapter

2Setup

This chapter covers setting up the PS machine as well as set-

ting up equipment on the machine. This includes optional

equipment such as the Option Bay and Tape Output equip-

ment, as well as the various device media choices for running

jobs, such as setting up Static Trays or an Automatic Tray

Feeder.

Installation of the PS Machine is performed by Data I/O service per-

sonnel or an authorized distributor. After the PS Machine arrives,

ensure that there is no damage to the exterior of the crate. Remove the

PS machine from the crate and inspect for damage that may have

occurred during shipping. If no damage is evident, unbolt the

PS machine from the shipping pallet.

The intended area for PS installation must:

• allow at least one meter (36 inches) of clearance on all sides of

the PS machine for opening access panels as well as repairing

and replacing subassemblies,

• provide a solid foundation (for example, a concrete floor). The

PS machine contains a fast-moving gantry with much mass. The

area for it must be stable, solid, and mostly level prior to installa-

tion. If this is not achievable, consider installing the system at

another location.

When at the desired location, adjust the feet to level the PS Machine.

WARNING: Possible machine damage or personal injury. Instabil-

ity such as vibrating, walking, or rocking, may occur if fewer than

four of the installed feet make suitable contact with the floor, or if

the leg locknuts are not tightened against the frame.

Only the adjustable feet provided on the PS machine should be

used for leveling. Do not use shims to assist in leveling.

The information in this

Manual applies to the

PS288, PS388 and

the PS588, (referred

to as PS System)

unless otherwise noted.
