Operation ■ Operator Functions
3—2 Data I/O • 981-0424-002
back
Operator Functions
Operator functions include setting up hardware, turning on the
PS System, starting TaskLink, loading a job, and running a job.
Requirements prior to running a job on the PS Machine:
• You have a Task for your target device. This is generally an
administrator function. Refer to Creating a Task in TaskLink on
page 3-31.
• All assemblies needed for the target job, such as the Automatic
Tray Feeder, a Marking System and the Tape Output System, are
installed (or ready to be installed) on the PS System and ready.
See Chapter 2- Set Up.
Operators, please read Safety Symbols on page viii of the Preface and
Precautions for Safe Operation on page 1-23, (if you have not already).
You should generally be familiar with the PS System as described in
Chapter 1.
Running a Job on PS Systems
List of Steps to Run a Job
Operator functions appear in chronological order as follows:
1. Check the System on page 3-2
2. Installing Socket Adapters – FlashCORE on page 3-3
3. (Optional) [PS588 only] Installing Socket Adapters – OPTIMA on
page 3-6
4. Installing the Correct Probe Tip on page 3-7
5. Turning System Power On on page 3-10
6. Starting AH500 via TaskLink (Selecting a Job) on page 3-10
7. (Optional) Preselecting Programmers on page 3-13
8. Adjust Socket Opener Ribs on page 3-14 if you’ve changed Socket
Adapters.
9. Adjust Two Items After Changing Socket Adapters on page 3-15 for
special adapters only
10. Set Media and Options—the Setup Window on page 3-16
11. Install Media and Options—the Workspace on page 3-20
12. Start Programming on page 3-21
13. Stopping the System on page 3-22
14. Light Tower Interpretation on page 3-25
15. (Optional) Changing Programmer Status on page 3-25
16. Turning Off System Power on page 3-27
17. (Optional) Operating the TF20 Automatic Tray Feeder on page 3-29
Check the System
Before you set up for your job, check that:
• All side panels are closed and no one is working on the machine.
PS Machines must be
level and at room tem-
perature before running
a job.
■ Operator Functions ◘ Running a Job on PS Systems
PS Series Owner’s Manual 3—3
back
• The external air line is connected.
• If the air pressure switch is ON, the pressure indicator number is
green.
• If the power is ON, the PNP head is stopped in the Park position.
Installing Socket Adapters – FlashCORE
Socket Adapters can be installed before or after the AH500 Software
has been started. Note that after installing different Socket Adapters,
there are generally three items to adjust: adjusting the socket opener
ribs, adjusting the actuator air pressure, and adjusting the socket
actuator sensors on the air cylinder if necessary.
To install or change a Socket Adapter on a FlashCORE programmer:
Note: To find the correct Socket Adapter part number for your
device/job, 1) Open TaskLink, 2) Select your target job, 3) Click
Edit then Footnotes.
1. If a job is running, click Finish on the Run Window and wait for
the PNP head to empty the sockets, move to the Park position
and stop.
2. Open the safety shield that offers the easiest access to the target
programmer(s).
CAUTION: Electrostatic discharge (ESD) hazard. To prevent
damage to Socket Adapters and devices from ESD, always wear
an antistatic wrist strap.
The wrist strap should be connected to the grounding socket on
the front of the PS Machine and should contain a 1 M-ohm to
10 M-ohm current limiting resistor.
3. [PS588 FlashCORE only] Remove the Actuator Plate—
3a. [Standard sockets only] Type-A (see Figure 3-3): Slide the plate
toward the front of the PS Machine until the notches on the plate
align with the cutouts on the Actuation Bracket. Then lift the
actuator plate up.
Type-B: Slide the plate out toward the front of the PS Machine.
A job can be continued
later even after clicking
Finish.
Operation ■ Operator Functions
3—4 Data I/O • 981-0424-002
back
Figure 3-3: [PS588 FlashCORE only] Actuator Plates for Standard
Sockets. Align Actuator Plate Type-A notches with the Actuation
Bracket notches, and then lift up to remove.
3b. [HIC Adapters only] Slide the plate out toward the front of the
PS Machine. See the figure below.
Figure 3-4: Special Actuation Plate for HIC Adapters.
4. Remove the Socket Adapter—
4a. Unscrew the two captive, SHCS with a 4 mm hex key and open
the Adapter Bracket.
Type-B Type-A
