• Using This Manual •• Symbols for Spec ific Models/Equipment PS Series Owner’s Manual ix back S ymbols for Specific Models/Equipment The following symbols appear in the side bar next to paragraphs or procedural steps th…
Preface • Using This Manual
viii Data I/O • 981-0424-002
back
Safety Symbols
Safety symbols in this manual mean this:
—Crush Hazard
—Electric Shock Hazard
—General Hazard Warning
—Eye Protection Warning
—Hazardous Materials Warning
—Laser Hazard Warning
—Electrostatic Discharge Warning
• Using This Manual •• Symbols for Specific Models/Equipment
PS Series Owner’s Manual ix
back
Symbols for Specific Models/Equipment
The following symbols appear in the side bar next to paragraphs or
procedural steps that are limited to a specific model or piece of
optional equipment. If the symbol is next to a heading, the entire con-
tent under that heading is limited to the equipment indicated.
Jump Right In
Thanks for reading about the safety symbols, notes, and icons. If your
PS System is already set up and you want to skip ahead:
Be safe —see Safety Systems on page 1-4
Where’s the _____? —see Machine Components on page 1-11
How to run a job —see Running a Job on PS Systems on page 3-2
What if it stops? —see Troubleshooting on page 4-58
What info is needed when I request service? -see next page.
For a description of any
PS model or optional
equipment, see
Chapter 1.
. . . adjacent information is limited to the:
PS288 Machines only.
PS388 Machines only.
All PS588 Machines only (regardless of type of
programmers installed)
Only PS588 Machines with (at least one) FlashCORE
Programmers
Only PS588 Machines with (at least one) OPTIMA
(Universal) Programmers
Only Laser Marking Systems, or PS Machines with
Marking Systems
Only Tape Output Systems, or PS Machines with
Tape Output Systems
Only TF20 Tray Feeders, or PS Machines with Tray
Feeders
Only Label Marking Systems, or PS Machines with
Label Marking Systems.
A lead, 3D inspection system by ICOS detects bent
leads on devices. It includes a PC and hardware.
This symbol
means . . .
Preface • Contacting Data I/O
x Data I/O • 981-0424-002
back
Contacting Data I/O
Contact Data I/O for technical assistance by visiting the Data I/O Web
site and completing a Web form, by sending an e-mail, or by calling.
To help us give you quick and accurate assistance, please provide the
following information:
• PS Machine serial number
• TaskLink and AH500 software version numbers
• Detailed description of the problem you are experiencing
• The event log from the FlashCORE programmer site
• Error messages (if any)
• Device manufacturer and part number (if device related)
Data I/O Customer Support
Worldwide: www.dataio.com
China: www.dataio.cn
Germany: www.dataio.de
Other Countries
Data I/O Customer Support offices around the world are staffed with
factory-trained technicians to provide prompt, quality service. For
warranty service, contact Data I/O Customer Support at the numbers
listed at our Rep Search on our Web site.
For Serial Number location
see page 1-11
Data I/O Corporation
Redmond, WA USA 98052
Telephone: +1 425-881-6444
in USA: 1-800-3-DATAIO
Fax: +1 425-867-6972
E-mail: support@dataio.com
Data I/O Co. Ltd E-mail: support@dataio.com
Data I/O GmbH E-mail: support@dataio.com
To find your local Data I/O representative, use the Representative
Search feature at:
www.dataio.com/contact/repsearch.asp
The best way to contact technical support is by using our online
form: at www.dataio.com click on the Technical Support button.
Want to contact Sales?
USA–
salesDIOAmerica
@dataio.com
China–
ChinaSales@dataio.com
Germany–
salesgmbh@data-io.de
