Warning The machine should be moved wrapped in durable packing
materials and with covers for electrical protection.
The operator could be injured or the equipment could be damaged
if proper safety measures are not taken or the equipment is
operated at an improper location.
If the door switch was removed artificially, since the equipment
does not stop even though the door opens during operation, the
user may get injured. Do not remove the door switch artificially.
Never attempt to modify the equipment without prior consent of
Samsung Techwin Co., Ltd. or repairs it in a manner not stated in
this manual. Samsung Techwin Co., Ltd. is not responsible for
problems caused by machine repairs performed in a manner not
mentioned in this manual, or any modifications carried out without
prior approval
Be sure to turn off the power switch and then close the air-valve
before maintenance or repair. If it is not followed, personal
injuries could occur.
Checking the sensor or correcting an error while the equipment
status is 'READY' could result in personal injury.
Press the 'EMG' switch to release the 'READY' and perform
sensor adjustment and take measures against the error after
pressing the 'STOP' button.
The system infected by a virus could make the machine
malfunction and the damage by malfunction could occur.
We do not take responsibility for any damage to the data due to
infection by a virus. Therefore, perform a virus check periodically
to prevent the data from being infected by a virus.
Observe the cautions when using the USB memory. (Refer to "2.3
PC Specification" of the Introduction Manual)
Page
SAMSUNG TECHWIN
1
SM471
Contents
Mechanical Part
Feeder Base Ass’y - ST................................................................ 4
Feeder Base Ass’y - DC ............................................................... 6
Conveyor Ass’y........................................................................... 14
Backup Table Ass’y .................................................................... 34
Base Frame Ass’y ...................................................................... 36
Head Ass’y ................................................................................. 38
Air Ass’y...................................................................................... 54
X-Y Frame Ass’y......................................................................... 68
Fixed ANC Ass’y......................................................................... 76
Cover Ass’y ................................................................................ 78
Control Rack Ass’y ..................................................................... 86
Electric Panel Ass’y .................................................................... 88
Electric Device Ass’y .................................................................. 90
Electric Control Part
SM471 Harness Wiring Diagram .............................................. 100
Camera IO Board .................................................................... 104
Front Feeder Board Interface ................................................... 106
Rear Feeder Board Interface.................................................... 110
Conveyor Board Interface ........................................................ 112
Conveyor Sensor IF Board ...................................................... 122
Conveyor Sub IF Board............................................................ 124
Head IF Board .......................................................................... 126
Axis Sensor Board Interface..................................................... 130
Axis IO Board ........................................................................... 136
FR Motor IF Board ................................................................... 162
Vision IF Board ........................................................................ 168
Safety Control Board Interface ................................................. 172
Electric Circuit Diagram............................................................ 180
Articles of Consumption
Articles of Consumption ........................................................... 195
