SAMSUNG TECHWIN
126
SM471
Head IF Board (1/2)
^7`
^4`
^5`
^6`
^8`
Page
SAMSUNG TECHWIN
127
SM471
Head IF Board (1/2)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-005524A CABLE ASSY-HEAD1_PWR_J2R 1 SM471_SC103-1
2 AM03-005434A CABLE ASSY-BD_PW_SC_J2R 1 SM471_SC202
3 AM03-005703A CABLE ASSY-HD_VAC-BLOW_H1-H8 1 SM471-VI006
4 AM03-005590A CABLE ASSY-FLY_SIDE_1 1 SM471_HD010-3
5 AM03-005593A CABLE ASSY-FLY_OUT_1 1 SM471_HD010-6
Page
SAMSUNG TECHWIN
128
SM471
Head IF Board (2/2)
