Page SAMSUNG TECHWIN 163 SM471 FR Motor IF Board (1/3) NO. Lev . P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference 1 AM03-0056 01A CABLE ASSY -Z1_MOTOR 1 SM471_M D019 2 AM03-0056 02A CABLE ASSY -Z2_MOTOR…
Page
SAMSUNG TECHWIN
162
SM471
FR Motor IF Board (1/3)
^8`
^4`
^5`
^7`
^6`
^9`
^:`
^;`
^<`
^43`
Page
SAMSUNG TECHWIN
163
SM471
FR Motor IF Board (1/3)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-005601A CABLE ASSY-Z1_MOTOR 1 SM471_MD019
2 AM03-005602A CABLE ASSY-Z2_MOTOR 1 SM471_MD020
3 AM03-005603A CABLE ASSY-Z3_MOTOR 1 SM471_MD021
4 AM03-005604A CABLE ASSY-Z4_MOTOR 1 SM471_MD022
5 AM03-005605A CABLE ASSY-Z5_MOTOR 1 SM471_MD023
6 AM03-005606A CABLE ASSY-Z6_MOTOR 1 SM471_MD024
7 AM03-005607A CABLE ASSY-Z7_MOTOR 1 SM471_MD024-1
8 AM03-005608A CABLE ASSY-Z8_MOTOR 1 SM471_MD024-2
9 AM03-005609A CABLE ASSY-Z9_MOTOR 1 SM471_MD024-3
10 AM03-005610A CABLE ASSY-Z10_MOTOR 1 SM471_MD024-4
Page
SAMSUNG TECHWIN
164
SM471
FR Motor IF Board (2/3)
^8`
^4`
^5`
^7`
^6`
